CONTROLS AND FUNCTIONS
SEE FIGURE 1
1. MAIN POWER SWITCH:
2. VACUUM SWITCH: TURNS VACUUM MOTOR ON.
OPENS AND CLOSES SOLUTION VALVE.
3. SOLUTION SWITCH:
4. SCRUB DECK SWITCH:
INDICATES AMOUNT OF BATTERY CHARGE .
5. BATTERY GAUGE:
6. POWER LIGHT (GREEN):
7. DOWN PRESSURE GAUGE:
SEE FIGURE 2
8. EMERGENCY STOP (OPTIONAL):
9. KEY SWITCH (OPTIONAL):
10. CIRCUIT BREAKER: 2 AMP RESETABLE CIRCUIT BREAKER (ACTUATOR).
11. CIRCUIT BREAKER: 25 AMP RESETABLE CIRCUIT BREAKER (VACUUM MOTOR).
30 AMP RESETABLE CIRCUIT BREAKER (SCRUB MOTOR).
12. CIRCUIT BREAKER:
13. SPRAY JET (OPTIONAL):
14. HOUR METER: INDICATES HOW MANY HOURS THE MACHINE HAS BEEN RUN.
15. SERIAL NUMBER PLATE:
SEE FIGURE 3
USED FOR FLUSHING OUT RECOVERY TANK AREA WITH FRESH WATER.
16. RECOVERY LID:
17. DRIVE BUTTON: DEPRESS TO DRIVE FORWARD, RELEASE TO STOP. (STARTS & STOPS THE SCRUB MOTOR)
18. "DRAIN SAVER" STRAINER:
PROTECTS VAC MOTOR FROM DEBRIS.
19. VAC SCREEN:
20. CASTER: TWIN CASTERS FOR STABILITY.
21. MAIN TIRE: NON-MARKING TIRES.
CONTROLS SOLUTION FLOW RATE, WHEN SOLUTION SWITCH IS ON.
22. SOLUTION VALVE:
23. SPLASH CURTAIN: HELPS CONTAIN WATER INSIDE SCRUB AREA.
HELPS PROTECT MACHINE WHEN SCRUBBING NEAR WALLS.
24. WALL ROLLERS:
25. "PAD ASSIST" DRIVE ADJUSTMENT KNOB:
SOLUTION/RECOVERY TANK(18 GALLON CAPACITY EACH).
26. TANK-IN-TANK:
FILL PORT FOR FILLING SOLUTION TANK.
27. SOLUTION FILL LID:
SEE FIGURE 4
FOR VIEWING INSIDE RECOVERY TANK AREA.
28. CLEAR COVER:
29. CONTROL PANEL: MACHINE CONTROLS.
30. RECOVERY DRAIN HOSE:
31. RECHARGE PLUG: RED 50 USED TO RECEIVE CHARGER INPUT. NOTE: ONLY USE CHARGER PROVIDED.
YOUR MACHINE IS EQUIPPED WITH TWO (12 VOLT DEEP CYCLE 140 AMP HOUR BATTERIES).
32. BATTERIES:
33. SQUEEGEE BLADE: RECOVERS DIRTY WATER FROM FLOOR TO BE RECOVERED BY THE VACUUM HOSE.
VACUUMIZES SQUEEGEE. NOTE: KEEP FREE AND CLEAR OF BLOCKAGE.
34. VACUUM HOSE:
35. SQUEEGEE PITCH ADJUSTMENT:
36. SQUEEGEE LIFT POST:
37. SOLUTION FILTER: HELPS CLEAN WATER IN PREPERATION FOR SCRUBBING.
38. SOLUTION LEVEL INDICATOR & DRAIN TUBE:
SEE FIGURES (1-4) ON PAGE 7
TURNS THE MACHINE ON AND OFF.
RAISES AND LOWERS SCRUB DECK (PROVIDES AJDUSTMENT +/- FOR PRESSURE).
INDICATES POWER "ON"
INDICATES AMOUNT OF PAD/BRUSH PRESSURE.
SHUTS OFF POWER TO THE MACHINE .
TURNS POWER ON TO THE MACHINE.
TURNS ON THE SPRAY JET PUMP (BLUE).
MACHINE IDENTIFICATION
HELPS PREVENT CLOGGING OF DRAIN PORTS.
ADJUSTS AMOUNT OF OFFSET BEING APPLIED TO BRUSH.
ALLOWS FOR CONTROLLED DRAINING OF RECOVERY TANK.
ADJUSTS PITCH OF SQUEEGEE. DEFLECTION SHOULD BE EVEN ACROSS ENTIRE BLADE.
LIFT TO RAISE SQUEEGEE AND PUSH DOWN TO LOWER SQUEEGEE
SHOWS PRECISE LEVEL OF CLEANING SOLUTION IN TANK & DRAIN PORT.
.
.
