Microsoft Window Keys
There are two special Windows keys on the keyboard as described bellow:
The key with the Windows logo activates the Start menu located at the bottom left of the
Windows desktop.
The other key, that looks like a Windows menu with a small cursor, activates the properties
menu and is equivalent to pressing the right mouse button on a Windows object.

Keyboard as a Numeric Keypad

The numeric keypad is embedded in the keyboard and consists of 15 Keys that
make number intensive input more convenient. These dual-purpose keys are
labeled in Blue on the key caps. Numeric assignments are located at the upper
right hand corner of each key as shown in the figure. When the numeric keypad is
engaged by pressing (Num LK/ Scr LK), the number lock LED lights up. If an
external keyboard is connected, pressing the (Num LK/ Scr LK) on the external
keyboard enables/disable the NumLock on both keyboards simultaneously. To
disable the numeric keypad while keeping the keypad on an external keyboard
activated, press the (Num LK/ Scr LK) keys on the Notebook PC.

Keyboard as Cursors

The keyboard can be used as cursors while Number Lock is ON or OFF in order to
increase navigation ease while entering numeric data in spreadsheets or similar
applications.
With Number Lock OFF, press (Fn) and one of the cursor keys shown. For example
(Fn) (8) for up, (Fn) (K) for down, (Fn)(U) for left, and (Fn) (O) for right.
