SET-UP DIAGRAM
NARNIN6! Switch power off to all equipment in use before connecting or disconnecting anything
TO
INSTRUMENT TO
AMP HEADPHONES
TRANSFORMER
(included)
Connect to correct power source
U.87Japan: 11SV. Europe: 230V.
4. OBSERVE INITIAL TUNING.
When you apply power, the LEDs for Tracks 1-6 light in sequence as the
numbers 1 through 6 appear in the Sound Selection display. This indicates that
the synthesizer voices are tuning. This takes about 20 seconds. You can't play
the MAX and the recorder will not operate during tuning.
When initial tuning is done, 00 appears in the Sound Selection display. This
indicates that the MAX is ready to play, and that sound number 00 (Full Organ)
is selected.
Song 1 and Stop are also lit. This means that the multi-track recorder is ready.
5. IF DESIRED TO ADJUST MASTER TUNE, HOLD Record AND PRESS THE LOWER
OR UPPER Track Volume SWITCHES.
The pitch will change very slowly. Use this "hidden function11 to tune the MAX
to an acoustic piano, for example.
CAUTION! To protect speakers (and ears!), first lower Master Volume all the way, then,
while playing, gradually raise it to the desired level.
NOTE; For best signal-to-noise ratio when using external amplifiers, raise Master
Volume and lower the amplifier level.
CM620A 10/8*
