Track
2
3
5
6
Sound
Number
48
46
44
07
07
64
Sound
Name
Bass Drum
Snare Drum
Clav Bass
Fast Leslie
Fast Leslie
High Josef
With Song 2 selected, press the Track switches to display the sound assignments
in Demo Song 2:
Track
1
2
3
4
5
6
Sound
Number
77
79
79
78
70
52
Sound
Name
Space Chimes II
Alien Wind
Alien Wind
Alien
Wind
Pulse Width Mod I
If a track has not been recorded, when you press its switch, the display
continues to show the current sound selection. This demonstrates that
unrecorded tracks (which are available for live playing) use the current sound
number.
5. TO ADJUST PLAYBACK SPEED: USE THE SPEED SWITCHES.
a. With the desired song selected (whether started or stopped), hold the upper or
lower Speed switches. When you press either Speed switch, a speed value 01 - 61
is displayed.
b. To raise or lower by one speed increment, tap either Speed switch.
The song always plays at the speed to which it was last adjusted (unless you
have switched power off).
For example, select Song 1. Press the upper Speed switch. The display counts up
from 04. 04 is the initial speed value of Demo Song 1. If the song is running, it
gets faster. To reduce speed, hold the lower Speed switch.
Now select Demo Song 2 and adjust its speed. Notice that it has an initial speed
value of 06.
6. TO ADJUST A TRACK VOLUME: HOLD DESIRED Track SWITCH WHILE TAPPING
OR HOLDING EITHER Track Volume SWITCH.
a. Start playback.
b. Hold one of the lit Track switches.
c. Use the upper or lower Track Volume switches. When you press either track
volume switch, the MAX displays a volume value 00-15. When you release the
Track Volume switch, the MAX displays the track's sound number.
d- To raise or lower by one volume increment, tap the Track Volume switches.
CM620A 10/84 9
