Summary of Contents for D-Link DCS-6410

  • Page 2: Table Of Contents

    Image Setup ............ 33 Audio and Video ..........34 Warranty ..............63 Motion Detection ..........35 Time and Date ..........36 Registration ..............69 Recording ............37 Snapshot ............38 Digital Output ........... 39 RS-485 ............. 40 D-Link DCS-6410 User Manual...
  • Page 3: Product Overview

    Section 1 - Product Overview Product Overview Package Contents • D-Link DCS-6410 Fixed Dome Network Camera • CAT5 Ethernet Cable • Power Adapter • Manual and Software on CD • Quick Install Guide • Camera Stand Note: Using a power supply with a different voltage than the one included with the package will cause damage and void the warranty for this product.
  • Page 4: Introduction

    Nothing herein represents a warranty or representation that the D-Link product provided herein is suitable for the end-user’s intended use under the applicable laws of his or her state. D-Link disclaims any liability whatsoever for any end-user use of the D-Link product, which fails to comply with applicable state, local, or federal laws.
  • Page 5: Features

    • Broad Range of Applications: With today’s high-speed Internet, the Network Camera provides the ideal solution for remotely monitoring live video images over the Intranet and Internet. The DCS-6410 allows remote access using Internet Explorer or other web browser for live image viewing with audio and allows the administrator to manage and control the Network Camera anywhere and anytime.
  • Page 6: Hardware Overview

    Section 1 - Product Overview Hardware Overview DC Power Connector The DC power input connector is located on the DCS-6410 Network Camera’s back panel and is labeled 12V DC with a single socket to supply power to the Network Camera.
  • Page 7: Hardware Overview

    The DCS-6410 provides a general I/O Microphone Connector terminal block. The I/O connectors provide The DCS-6410 Fixed Dome Newtwork Camera has an the physical interface to send and receive internal microphone built-in. However, you have the digital signals to and from a variety of option of using an external microphone by plugging it external devices.
  • Page 8: Hardware Installation

    Find a suitable place to install the camera using the alignment stencil. Place the camera at the desired operating location and insert the screws through the two holes located at the base of the camera. Use a screwdriver to tighten and secure. D-Link DCS-6410 User Manual...
  • Page 9: Network Deployment

    Connect the supplied power cable from the camera to a power outlet. Connection with a PoE Switch If using a PoE switch, connect the network camera to the switch via an Ethernet cable, which will provide both power and data transmission over a single cable. D-Link DCS-6410 User Manual...
  • Page 10: Software Installation

    Section 2 - Installation Software Installation Turn on the computer and insert the D-Link DCS-6410 Driver CD into the CD-ROM drive. The following step-by-step instructions will be shown in Windows XP. Similar steps and screens will also be shown for other Windows operating ®...
  • Page 11 Section 2 - Installation Click Next to continue. Click Next Click Yes to accept the License Agreement. Click Yes D-Link DCS-6410 User Manual...
  • Page 12 Section 2 - Installation To start the installation click Next. Note: The installation may take several minutes to complete. Click Next D-Link DCS-6410 User Manual...
  • Page 13 Section 2 - Installation Click Finish to complete the installation. Click Finish D-Link DCS-6410 User Manual...
  • Page 14 Section 2 - Installation Now, click on ffdshow from the autorun screen. This will install the proper codecs that will allow you to playback video taken by the DCS-6410. Click ffdshow Click I Agree D-Link DCS-6410 User Manual...
  • Page 15 Section 2 - Installation Click Next Click Install D-Link DCS-6410 User Manual...
  • Page 16 Start > Programs > ffdshow > Configuration. At the ffdshow properties window, scroll to the bottom and click Miscellaneous. Be sure Autodetect is checked, and Error resilience and Error concealment are set to “none”. Click OK and close the window. Click OK D-Link DCS-6410 User Manual...
  • Page 17: Configuration

    Section 3 - Configuration Configuration This section will show you how to configure your new D-Link Network Camera using the Setup Wizard. Setup Wizard Configuration Click on the icon that has been created in your Windows Start menu. Click D-Link Setup Wizard SE...
  • Page 18 Section 3 - Configuration The Setup Wizard will appear and show the MAC address of your DCS-6410 and an IP Address (which may or may not be correct, depending on what you have your DCS-6410 connected to). If you have a DHCP server on your network, there will be a valid IP Address displayed here.
  • Page 19 Section 3 - Configuration Select DHCP if you want to obtain a new IP address every time the camera boots up. Click Next Select static IP to use the same IP address at each boot up. Click Next D-Link DCS-6410 User Manual...
  • Page 20 Click the button labeled Link to access the web configuration page. The Setup Wizard will automatically open your web browser with the IP address of your DCS-6410. For example, the IP address is: http://192.198.0.20. Note: Your DCS-6410 may have a different IP Address.
  • Page 21: Web-Based Configuration Utility

    Section 3 - Configuration Web-based Configuration Utility This section will show you how to configure your new D-Link Network Camera using the Web-based Configuration Utility. To access the configuration utility, open a web-browser such as Internet Explorer and enter the IP address of your Network Camera (http://192.168.0.20)
  • Page 22: Live Video

    Video Profile 1 Video Profile 2 Video Profile 3 Video Profile 4 Full screen mode Taking a Snapshot Recording a Video Clip Set a Storage Folder Listen/Stop Listening Talk/Stop Talking Start/Stop Digital Output D-Link DCS-6410 User Manual...
  • Page 23: Setup

    Manual Motion Detection Setup and skip to page 30. Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera and connect the camera to the Internet. Click Next to continue. Click Next...
  • Page 24 Enter the accurate information for your static IP setting. Click Next to continue. Click Next If you are using PPPoE, select Enable and enter your user name and password. Click Next to continue. Click Next D-Link DCS-6410 User Manual...
  • Page 25 If you have a Dynamic DNS account and would like your camera to update its IP address automatically, Select Enable and enter your host information. Click Next to continue. Click Next Enter a name for your camera and click Next to continue. Click Next D-Link DCS-6410 User Manual...
  • Page 26 Click Next You will see a summary of your camera’s settings. Please note down all this information as you will need it for accessing your camera within the network. Click Apply to activate your settings. Click Apply D-Link DCS-6410 User Manual...
  • Page 27: Motion Detection Setup Wizard

    Section 3 - Configuration Motion Detection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera motion detection functions. Click Next to continue. Click Next This section will allow you to enable or disable motion detection as well as control the camera’s sensitivity...
  • Page 28 This step allows you to specify how you will receive the events notification of your camera, either via using email or FTP. You will need to enter all the relevant information for your email account or FTP settings. Then, click Next to continue. Click Next D-Link DCS-6410 User Manual...
  • Page 29 Section 3 - Configuration You have completed the Motion Detection Wizard. Click Apply to activate your settings. Click Apply D-Link DCS-6410 User Manual...
  • Page 30: Network Setup

    Enable this setting to allow your camera to be configured as an UPnP device in your network. Enable UPnP port Enable this setting to allow your camera to add port forwarding entries into the router automatically. forwarding: D-Link DCS-6410 User Manual...
  • Page 31 The password of your account. You may obtain this information from your ISP. HTTP Port: The default value is 80. RTSP port: The port number that you use for RTSP streaming to mobile devices, such as mobile phones or PDAs. The default port number is 554. D-Link DCS-6410 User Manual...
  • Page 32: Dynamic Dns

    Host Name: Enter your user name or e-mail used to connect User name: to the DDNS. Enter your password used to connect to the DDNS Password: server. Indicate the connection status, automatically Status: determined by the system. D-Link DCS-6410 User Manual...
  • Page 33: Image Setup

    An adjustable setting to compensate for backlit Brightness: scenes. Saturation: This setting controls the strength of color from black and white to bold colors. Contrast: Allows for the measurement of color intensity or strength. Hue: This setting controls the color tone. D-Link DCS-6410 User Manual...
  • Page 34: Audio And Video

    (Bits Per Second): BPS will affect the bit rate of the video recorded by the camera. A higher bit rate will increase the video quality. RTSP URL: Is the URL name used to connect to the camera when viewing from a mobile device or PDA. D-Link DCS-6410 User Manual...
  • Page 35: Motion Detection

    Select this option to draw out the motion detection area: area by dragging your mouse in the window (indicated by the red-colored box). Erase motion Use this option to erase your motion detection area: area by dragging your mouse in the window. D-Link DCS-6410 User Manual...
  • Page 36: Time And Date

    NTP server: automatically from the NTP server. NTP Server: Network Time Protocol (NTP) synchronizes the DCS-6410 with an Internet time server. Choose the one that is closest to your location. Set the date and This option allows you to set the time and time manually: date manually.
  • Page 37: Recording

    A preset amount of time before motion recording is triggered. Postrecord: A preset amount of time after motion recording is triggered. Scheduled: Select this option to manually configure the starting and ending time for the recording. D-Link DCS-6410 User Manual...
  • Page 38: Snapshot

    The prefix that will be added to the filename of each file. Port: The port of the FTP server. The default port is 25. Passive mode: Some FTP servers allow clients to use passive mode when connecting to an FTP, which uses random ports for transfers. D-Link DCS-6410 User Manual...
  • Page 39: Digital Output

    This enables the D/O to send a signal when there signal: is a triggered event. Trigger Event: You can choose from one or up to three events, such as Motion Detection, D/I Signal 1, and D/I Signal 2 for the sources of the triggered events. D-Link DCS-6410 User Manual...
  • Page 40: Rs-485

    For example, if the data is 011, for even parity, the parity bit is 0 to keep the number of logic-high bits even. If the parity is odd, the parity bit is 1, resulting in 3 logic-high bits. D-Link DCS-6410 User Manual...
  • Page 41: Maintenance

    Camera Name: Create a unique name for your camera to access the camera in your web-browser. For example: DCS-6410 (By default). Enable OSD: Select this option to enable the On-Screen Display feature for your camera.
  • Page 42: Backup And Restore

    Load Configuration. Restore To Factory You may reset your camera and restore the Default: factory settings to your camera by clicking Restore Factory Defaults. Reboot Device: This will restart your camera. D-Link DCS-6410 User Manual...
  • Page 43: Firmware Upgrade

    Section 3 - Configuration Firmware Upgrade Your current firmware version and date will be displayed on your screen. You may go to the D-Link Support Page to check for the latest firmware version available. To upgrade the firmware on your DCS-6410, please download and save the latest firmware version from the D-Link Support Page to your local hard drive.
  • Page 44: Status

    Section 3 - Configuration Status Device Info This page displays all the details about your device and network connection. D-Link DCS-6410 User Manual...
  • Page 45: Log

    Section 3 - Configuration This page displays the log information of your camera. You may also download the information by clicking Download. D-Link DCS-6410 User Manual...
  • Page 46: Help

    Section 3 - Configuration Help D-Link DCS-6410 User Manual...
  • Page 47: D-Viewcam Installation

    Section 4 - D-ViewCam Installation D-ViewCam Installation D-ViewCam software is included for the administrator to manage up to 32 D-Link IP cameras remotely. You may now use the software to configure all the advanced settings for your cameras. D-ViewCam is a comprehensive management tool for IP surveillance.
  • Page 48 Section 4 - D-ViewCam Installation Click Next to continue. Click Next Click Browse if you would like to choose a specific folder for the installation, otherwise click Next to continue. Click Next D-Link DCS-6410 User Manual...
  • Page 49 Section 4 - D-ViewCam Installation Click Next to start the installation. Note: The D-ViewCam installation process may take several minutes to complete. Click Next Click Finish to complete the installation. Click Finish D-Link DCS-6410 User Manual...
  • Page 50: Add A Camera

    Add a Camera This section will show you how to start and add a camera to the D-ViewCam system. To start D-ViewCam, select Start > All Programs > D-Link > D-Link D-ViewCam. Enter Admin as the default user name and leave the password blank.
  • Page 51 Section 4 - D-ViewCam Installation Welcome to the Add Camera Wizard. Use this wizard to add your cameras to the D-ViewCam system. Note: Use the left or right arrow to navigate the wizard. Click / Next to continue. Click Next D-Link DCS-6410 User Manual...
  • Page 52 If you choose Add Manually, enter the IP address or domain name, http port, model name, camera ID and password. Click the “?” button to auto detect the camera’s model name, then the model name will appear in the Model Name box. Click Next to continue. D-Link DCS-6410 User Manual...
  • Page 53 • Non-Office Hours Only: Continuously monitoring during non-office hours (06:00 PM to 08.00 AM) and ONLY recording when motion is detected. Note: Excluding 24/7 Continuous Recording, other schedule recording types can ONLY do recording when motion is detected. Please refer to page 35 for more information. Click Next to continue. D-Link DCS-6410 User Manual...
  • Page 54 Click Next to continue. The Add Camera wizard is now complete. Click Close to access the D-ViewCam’s main screen. Your D-ViewCam Installation is Complete! Note: Please refer to the D-ViewCam user manual for information about using D-ViewCam. D-Link DCS-6410 User Manual...
  • Page 55: Troubleshooting

    Internet from a Web browser. 2. What is the maximum number of users that can be allowed to access DCS-6410 simultaneously? The maximum number of users that can log onto the Network Camera at the same time is 10. Please keep in mind the overall performance of the transmission speed will slow down when many users are logged on.
  • Page 56 10. Why am I unable to access the DCS-6410 from a Web browser? If a router or firewall is used on the network, the correct ports for the DCS-6410 may not be configured on the router or firewall. To correct the problem, you need to determine if the DCS-6410 is behind a router or firewall and if the router or firewall is properly configured for the ports the DCS-6410 is using.
  • Page 57 The configuration on the Network Camera image display is incorrect. Through the Advanced > Image Setting section of the Web management you need to adjust the image related parameters such as brightness, contrast, hue and power line frequency for fluorescent light. D-Link DCS-6410 User Manual...
  • Page 58: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.
  • Page 59: Statically Assign An Ip Address

    2000 - From the desktop, right-click My Network Places > Properties. ® Step 2 Right-click on the Local Area Connection which represents your D-Link network adapter and select Properties. Step 3 Highlight Internet Protocol (TCP/IP) and click Properties. Step 4 Click Use the following IP address and enter an IP address that is on the same subnet as your network or the LAN IP address on your router.
  • Page 60: Technical Specifications

    • CAMERA SPECIFICATIONS 1/3” SONY CCD SENSOR, INTERLACE SCAN MODE • VIDEO BIT RATE • 0.1 lux @ F1.6, IR / 0 lux • 20K to 2M • 4.3mm, F1.6 MIC Input Impedance 4.4k Ohm • D-Link DCS-6410 User Manual...
  • Page 61 • C-Tick • Remote management/control of up to 32 cameras • Viewing of up to 32 cameras on one screen • Supports all management functions provided in web interface • Scheduled motion triggered, or manual recording options D-Link DCS-6410 User Manual...
  • Page 62: Contacting Technical Support

    • Hardware Revision (located on the label on the bottom of the Network Camera (e.g. rev A1)) • Serial Number (s/n number located on the label on the bottom of the Network Camera). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.
  • Page 63: Warranty

    Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement hardware need not be new or have an identical make, model or part. D-Link may, at its option, replace the defective Hardware or any part thereof with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.
  • Page 64 Warranty Period and is subject to the same limitations and exclusions. If a material non-conformance is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to replace the non-conforming Software, the price paid by the original licensee for the non-conforming Software will be refunded by D-Link;...
  • Page 65 • The customer is responsible for all in-bound shipping charges to D-Link. No Cash on Delivery (“COD”) is allowed. Products sent COD will either be rejected by D-Link or become the property of D-Link. Products shall be fully insured by the customer and shipped to D-Link Systems, Inc., 17595 Mt.
  • Page 66: Limitation Of Liability

    D-LINK FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
  • Page 67: Ce Mark Warning

    The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. D-Link DCS-6410 User Manual...
  • Page 68 This device has been designed to operate with an antenna having a maximum gain of 2 dB. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms. D-Link DCS-6410 User Manual...
  • Page 69: Registration

    Appendix E - Registration Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.1 August 25, 2009 D-Link DCS-6410 User Manual...
