SPECIFIC SERVICE INSTRUCTIONS

DISASSEMBLY PROCEDURE

REMOVING THE REAR COVER
1. Unplug the power plug.
2. As shown in the Fig. 1, remove the
3. Withdraw the rear cover toward you.
REMOVING THE CHASSIS
" After removing the rear cover.
1. Slightly raise the both sides of the chassis by hand and remove
the 2 claws under the both sides of the chassis from the front
cabinet.
2. Withdraw the chassis backward.
(If necessary, detach the wire clamp, connectors etc.)
REMOVING THE AV TERMINAL BOARD
" After removing the rear cover.
1. As shown in Fig. 1, remove the
2. As shown in Fig. 2, remove the 2 claws marked
CHASSIS.
3. As shown in Fig. 2, remove the AV TERMINAL BOARD slightly in
F
the direction of the arrow .
REMOVING THE SPEAKER
" After removing the rear cover and chassis.
1. As shown in the Fig. 1, remove the
NOTE : When removing the screws marked
remove the lower side screw first. Then remove the upper
one.
C
2. Remove the 2 screws attaching the speaker.
3. Follow the same steps when removing the other hand speaker.
8
14 A
screws marked .
3 B
screws marked .
E
under the
2 D
screws marked .
D
of the speaker,
CHECKING THE PW BOARD
To check the back side of the PW Board.
1) Pull out the chassis. (Refer to REMOVING THE CHASSIS).
2) Erect the chassis vertically so that you can easily check the back
side of the PW Board.
[CAUTION]
" When erecting the chassis, be careful so that there will be no
contacting with other PW Board.
" Before turning on power, make sure that the wire connector is
properly connected.
" When conducting a check with power supplied, be sure to confirm
that the CRT EARTH WIRE (BRAIDED ASS'Y) is connected to
the CRT SOCKET PW board.
WIRE CLAMPING AND CABLE TYING
1. Be sure to clamp the wire.
2. Never remove the cable tie used for tying the wires together.
Should it be inadvertently removed, be sure to tie the wires with a
new cable tie.
D
AV TERMINAL BOARD
C
No.51818
AV SW PWB
C
Fig. 2
