  • Page 1 Table of Contents Flail Mowers FM2060 & FM2072 17962 309-100M Operator’s Manual Read the Operator’s manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! ©...

  • Page 2: Table Of Contents

    Copyright 2008 All rights Reserved Land Pride provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been taken in the preparation of this manual, Land Pride assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Land Pride reserves the right to revise and improve its products as it sees fit.

  • Page 3: Important Safety Information

    This could result in injury Detach and store implements in a or equipment damage. area where children normally do not play. Secure implement by using blocks and supports. 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...
  • Page 4 Lower the implement to the debris. ground, put tractor in park, turn off Remove all tools and unused engine, and remove key before preforming maintenance. parts from implement before operation. Allow implement to cool completely. FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...
  • Page 5 Avoid wearing radio headphones while operating machinery. Keep Riders Off Machinery Riders obstruct the operator’s view, they could be struck by foreign objects or thrown from the machine. Never allow children to operate equipment. 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...

  • Page 6: Safety Labels

    Replace all damaged or missing labels. To order new Squeeze out air bubbles with the edge of a credit card. labels go to your nearest Land Pride dealer. Some new equipment installed during repair requires safety labels to be affixed to the replaced component as specified by Land Pride.
  • Page 7 Table of Contents Land Pride Important Safety Information Beneath Guard 818-543C 17962 17962 Danger: Guard Missing ROTATING DRIVELINE 818-552C KEEP AWAY! 17962 17965 Danger: Rotating Driveline 818-552C ROTATING DRIVELINE Danger: Rotating Driveline KEEP AWAY! 13314 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...
  • Page 8 Table of Contents Land Pride Important Safety Information 818-558C 17962 17964 Warning: General 818-556C 17962 17964 Danger: Thrown Object 838-079C 17962 17964 Danger: Rotating Knives Both sides FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 9: Introduction

    Table of Contents Land Pride Introduction Introduction Land Pride welcomes you to the growing family of new Definitions product owners. NOTE: A special point of information that the This Flail Mower has been designed with care and built operator must be aware of before continuing.

  • Page 10: Section 1: Assembly And Set-Up

    (#5) and (#6) for either a left offset or right tractor’s operator manual. offset. 7. Tighten all hardware. Hitch Assembly 17966 Figure 1-1 FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 11: Tractor Hook-Up

    3. Driveline should now be moved back and forth to insure that it is secure on the PTO shaft of the tractor and mower gearbox. 17967 Tractor Hook-Up Figure 1-2 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...

  • Page 12: Section 2: Operating Instructions

    2. Grass is best cut when it is dry. Mowing wet grass Land Pride FM2060 or FM2072 Flail Mower. can cause plugging resulting in grass clumps behind It’s now time to do a running operational safety check. If the mower.
  • Page 13 With a little practice you will be pleased with what you and your Land Pride Flail mower can do. Dense growth will require more horsepower and will cause you to slow down especially if you are encountering material up to 1"...

  • Page 14: Section 3: Adjustments

    Figure 3-1 Excessive tension on the belt may lead to premature failure of belt and drive components. Excessive tension on the belt may also lead to a safety hazard to the operator or bystanders. FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 15: Section 4: Maintenance And Lubrication

    5. Store unit inside if possible for longer life. and roller (#3). Repaint parts where paint is worn or scratched to prevent 3. With tension relieved from belt remove old belt from rust. Ask your dealer for aerosol Land Pride Beige touch- pulleys. up paint #821-011C. 3/25/08...

  • Page 16: Lubrication

    Hours Driveline Shaft U-Joints Type of Lubrication: Multi-purpose Grease 13545 Hours Roller Bearing (Both Ends) Type of Lubrication: Multi-purpose Grease 17964 Hours Cutter Rotor Bearing (Both Ends) Type of Lubrication: Multi-purpose Grease 17962 FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 17: Gearbox

    LAND PRIDE dealer. NOTE: Mower should be level when checking oil in gearbox! Inner Tube Hours Driveline Profiles Type of Lubrication: Multi-purpose Grease 13648 Hours Extension Shaft Bearing Type of Lubrication: Multi-purpose Grease 17964 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...

  • Page 18: Section 5: Specifications & Capacities

    Hitch Type Category I Offset Hitch 6 1/4” PTO Speed 540 RPM Driveline Cat 4 w/Over-running Clutch Gearbox Rating 55 HP Drive Belts (2) - “B” Section Belts Rear Roller Diameter 5 1/2” FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 19: Section 6: Features And Benefits

    Keeps the cut material from clumping together, ensuring an even distribution of clippings. deck Height adjusting roller Rear height adjusting roller with greaseable bearings and tapered ends to prevent gouging during turns. Scrapers Standard scrapers on rear height adjusting roller. 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...

  • Page 20: Section 7: Troubleshooting

    Reduce speed turns. Uneven cut Shift to a lower gear. Level mower. Replace missing knives. Tractor loaded down by mower Mow at full throttle (540 PTO rpm). Shift to a lower gear. Clean mower. FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 21: Section 8: Appendix

    = nominal thread diameter in millimeters x thread pitch 1 1/2" - 12 1330 2970 2190 4820 3560 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. 3/25/08 FM2060 & FM2072 Flail Mowers 309-100M...

  • Page 22: Notes

    Table of Contents Land Pride Section 8: Appendix Notes: FM2060 & FM2072 Flail Mowers 309-100M 3/25/08...

  • Page 23: Warranty

    This Warranty does not apply to any part or product which in Land Pride’s judgment shall have been misused or damaged by accident or lack of normal...
  • Page 24 Corporate Office: P.O. Box 5060 Salina, Kansas 67402-5060 USA www.landpride.com...
