Display Formats and Output Usage
Graphics Output Flexibility
Because there are two separate graphics controllers, each
output channel is completely independent of the other. Both
channels can support either VGA or DVI outputs, and in fact,
one could provide VGA while the other supplies DVI.
Please contact the factory if you have a special configuration
requirement. Also, refer to the User's Manual, which provides
comprehensive information about connectors and cabling.
Video Mode
Analog Non-Interlaced
Digital DVI
Standard Argus VGA Display Resolutions
Video Input Capabilities
The ArgusPMC has two NTSC/PAL Conexant Fusion 878A
video digitizers which operated independently of each other.
Using the built-in DMA engine, it is even possible to transfer
the video data from both digitizers into one of the on-board
display channels, thus providing two independent live-video
windows.
Video Mode Resolution
NTSC SQ Pixel 640x480
NTSC CCIR601 720x480
PAL CCIR 601 720x576
PAL SQ Pixel 768x576
SECAM SQ Pixel 768x576
S-Video SQ Pixel 640x480
S-Video CCIR601 720x480
Pixel Size
Resolution
(bits)
up to 1920x1200 8,16,32
up to 1600x1200 8,16,32
Resolution Windows and RTOS
Format
640 x 480 VGA
800 x 600 SVGA
1024 x 768 UVGA
1152 x 864 Sun
1280 x 1024 SXGA
1600 x 1200 UXGA
1920 x 1080 HDTV
1920 x 1200 WUXGA
Refresh
Scan Lines
Freq. (Hz)
30 525
30 525
25 625
25 625
25 625
30 525
30 525
The Argus supports dual VGA (analog) outputs up to
1920x1200x32 bpp with a programmable composite sync on
green.(SOG) mode. DVI capability includes resolution up to
1600x1200 and operates in single-link mode only.
The display outputs are supplied on the 68-pin front-panel
connector, which requires a breakout cable that splits out into
two standard DVI and two standard VGA connectors. Note
that the same data is supplied on both the VGA and the DVI
ports for a given display channel.
Windows Refresh Freq.
Format (Hz)
150 Hz at VGA,
WUXGA max
77 Hz at WUXGA
UXGA max 60 Hz
Vertical Scan Rate
Solaris
Maximum Index Frequency
8
150+ Hz
9
6
150+ Hz
7
0
142 Hz
1
2 [default]
126 Hz
3
4
107 Hz
5
91 Hz C
83 Hz n/a
77 Hz D
The front panel connector provides access to the S-Video
input for each digitizer. With pin sharing, it can instead support
up to three composite video inputs per digitizer: two inputs use
the S-Video pins (but not in S-Video mode) and the third input
uses the Audio Input pin. The standard breakout cable could
be used for this but connector adaptation would be needed.
Input Effective Rate
Multiplexer MPixels/Sec
1 of 3 12.27
1 of 3 13.50
1 of 3 14.20
1 of 3 14.75
1 of 3 14.75
no 12.27
no 13.50
page 4
Output
Channels
Ch1, Ch 2
Ch1, Ch 2
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
n/a
60 Hz
Input Clip and Capture to
Channels Scale? Frame Buffer
Ch A, Ch B yes YUV or RGB
Ch A, Ch B yes YUV or RGB
Ch A, Ch B yes YUV or RGB
Ch A, Ch B yes YUV or RGB
Ch A, Ch B yes YUV or RGB
Ch A, Ch B yes YUV or RGB
Ch A, Ch B yes YUV or RGB
Notes
Also supports
Sync On Green
single link only
