Installation
ProSAFE 8-Port and 16-Port Gigabit Click Switch
GSS108E
GSS116E
Hardware Overview
Notch
Locking tab
Mount the Switch
Wall mount
Note:
Peel the plastic cover off of the adhesive squares on the rear of the
backplate to help hold the backplate in place when mounting the switch to a wall..
3
1
2
Note:
You must screw the backplate into a wall stud when wall mounting the switch.
Table leg mount
Notch
1
Hook
Cable Devices and Connect to Power
3
OR
GSS108E
Check the Status
2
Port LEDs
3
3
OR
2
2
Computer
Server
Internet
Optional modem
Optional router
Power LED
1000 Mbps link (left LED)
10/100 Mbps link (right LED)
1000 Mbps activity (left LED blinking)
10/100 Mbps activity (right LED blinking)
No link (off)
On
Off
