Summary of Contents for Viking VWH 10’ Series
Page 1
Installation Guide Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, Professional Indoor and call 1-888-(845-4641) or visit the Viking Web site at vikingrange.com Outdoor Hoods F21287A EN (071514)
Dimensions & Specifications IMPORTANT– Please Read and Follow! (VWH 10” H./12”H. Wall Hoods w/Standard Ventilator 30”, & 36”) W A R N I N G C A U T I O N For general ventilating use only. Do not use to To reduce the risk of injury to persons in the exhaust hazardous or explosive materials and event of a rangetop grease fire, observe the...
NOTE: Maximum amp rating for hoods includes recommended ventilator kit rating; All products must be hard wired with 2- Any combustible material used for this purpose must be covered with locally-supplied stainless wire with ground. An interior- or exterior-power ventilator kit must be purchased for installation with all 18”H. hoods. steel. Viking also recommends using a backsplash.
Built-In Wall Custom Ventilator Planning Information System Dimensions (VBCV Models Proper installation of ducting is extremely important to ensure maximum performance 300 or 600 CFM Roof cap single blower from any ventilation product. interior-power 5-1/2” 7” round duct typical ductwork •...
Installation (VWH 10” H./12”H. Wall Hoods w/Standard Ventilator) CAUTION: Secure vent hood to wall using screws CAUTION: If not using a duct cover, using screws Check damper for unrestricted movement, adjust if Attach transition to damper. Seal with aluminum tape. provided.
Duct Cover Option Installation (VWH 10” H./12”H. Wall Hoods w/Standard Ventilator) (VWH 10” H./12”H. Wall Hoods w/Recirculating Kit) Attach with screws and lock washers provided. Attach with screws. W A R N I N G Measure distance from ceiling to canopy. Slide the duct cover in place and fasten from inside To reduce the risk of fire, electric shock, or injury canopy using the sheet metal screws provided.
Duct Cover Option Duct Cover Option (VWH 18”H. Wall Hoods) (VCWH Chimney Wall Hoods) Measure distance from ceiling to canopy. Tape to avoid scratching. Measure distance from ceiling to canopy. Slide the duct cover in place and fasten from inside canopy using the sheet metal screws provided.
Installation Installation (VCIH Island Hoods) (VCIH Island Hoods) Check framing where cutout will be. Cut appropriate size hole in ceiling. Either 7” or 10” Run duct work down to bottom edge of duct Attach canopy to duct cover/soffit. Seal top of hood to cover/soffit and secure in place.
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at1-888-(845-4641), online at vikingrange.com or write to:...
