  • Page 1 Unit 6, 5 Stone Street Kaiapoi, Canterbury New Zealand +64 3 741 1339 www.gowifi.co.nz EnGenius ECB-1221R WDS Setup Guide By Daniel Allin, Technician (DipCN, MTCNA) Go Wireless NZ Ltd...
  • Page 2 Step 1: Connect the first EnGenius AP to your computer, log into the Web Management Page and Navigate to the Operation Mode tab, change to AP Mode and Apply Changes: Step 2: Navigate to the LAN Interface Tab and change the IP Address of the Router to a unique unused IP Address on your network.
  • Page 3 Step 3: Navigate to the Wireless Basic Settings Tab and configure your SSID and Channel, Apply Changes. Step 4: Navigate to the Security Tab and set your Encryption Type and Wireless Security Key, Apply Changes: Go Wireless NZ Ltd...
  • Page 4 Step 5: On the WDS Settings Tab, Enable WDS Mode and add the Wireless MAC Address and a description of the other WDS AP, Apply Changes: Place this router in the desired location and connect it to your network. Delete your Internet Explorer Temporary Internet Files and Cookies before Proceeding.
  • Page 5 Step 7: On the Wireless Basic Settings Tab configure the exact settings as set in Step 3: Step 8: On the Wireless Security Tab, configure the exact settings as set in Step 4: Go Wireless NZ Ltd...
  • Page 6 Step 9: On the WDS Settings Tab, Enable WDS Mode and enter the Wireless MAC Address of the Main AP and include a description: Place the Second AP in the desired location; this device does not connect to your LAN as it is a WDS Repeater. Go Wireless NZ Ltd...
  • Page 7 Testing: Move to the room with the second (Remote) WDS AP and connect to the network. Ping all devices at the same time to ensure you have a reliable connection throughout the whole network. Open three command prompts and ping each device: Ping 192.168.1.201 (Remote WDS AP) Ping 192.168.1.200 (Main WDS AP) Ping 192.168.1.254 (Gateway/ADSL Modem)
  • Page 8 Log into the Remote WDS Repeater and check that you are connected to it by checking the associated clients on the status page: Note: If you unplug this device whilst connected you should lose connectivity and drop a couple of pings before auto-transitioning to the Main WDS AP. Go Wireless NZ Ltd...
