Engine from vehicle
Exhaust assy. Removal
- Remove the 2 fixing nuts from the manifold to the
head
- Unscrew the 2 screws fixing the muffler to the
housing; then remove the whole muffler paying at-
tention to the interference between its supporting
bracket and the cooling cover.
Removal of the engine from the vehicle
- Remove the left and right side fairings
- Remove the helmet compartment
Remove the full muffler assembly.
- Remove the 3 rear brake transmission fixing
screws indicated in the photograph
- Disconnect the rear brake transmission unscrew-
ing the set screw
- Disconnect the belt cooling tube and the swinging
arm retaining spring shown in the photograph
- Disconnect the spark plug tube
