Page 1: Administrator Guide
ST2030 SIP Administrator Guide Thomson Telecom S.A.S with a capital of 130 037 460 €...
Page 2 Copyright Notice & Trademarks © Thomson 2009. All rights reserved. Thomson Telecom reserves the right to alter material or technical specification of its products without prior notice. SpeedTouch and Thomson are registered trademarks. Various elements (including but not limited to trademarks, service marks, designs, logos and copyrighted material) shown on this Admin Guide are protected by intellectual property or other rights.
Page 3: Table Of Contents
Contents ........................1 AFETY NFORMATION PERATING CONDITIONS ............................1 OCATION SAFETY INSTRUCTIONS ONNECTIONS UALIFIED SERVICE ..................3 RODUCT OVERVIEW AND CONNECTIONS NTRODUCTION OTE AND AUTION ACKAGE CONTENTS 2.1 IP P ........................3 IGURE HONE ABLE ONNECTIONS Connecting to the Network and the PC ..........................4 Powering up the Phone ................................
Page 4 ENU LIST 5.1 O LCD D ........................34 IGURE PERATION ISPLAY .............................. 35 PERATION MENU DISPLAY Home operation menu display ..............................35 Config Menu Display ................................. 35 Admin Menu Display ................................. 36 Option Menu Display ................................37 Detailed LCD menu settings ..............................38 ...................
Page 5 Via WebGui ................................107 Via APS................................... 108 Via Telnet ................................109 HTTPS APS ........................... 110 MPROVE FEATURE Feature Activation ................................110 Via WebGui ................................110 APS ....................111 UPPORT NCRYPTION OF ONFIGURATION FILES IN Feature Activation ................................113 Via WebGui ................................113 Via APS...................................
Page 6 Feature Activation ................................165 ST20XX SIP N .62) ........................169 EATURES VERVIEW PBX- ....................169 ECOND DIAL TONE FOR LIKE ENVIRONMENTS Feature Activation ................................171 ........................173 EW SPECIFIC KEYS IN THE Feature Activation ................................174 ....................176 EW ERROR MESSAGE DISPLAY FOR RESPONSE Feature Activation ................................
Page 7 Feature Activation ..............................234 ............................... 235 OFT KEYS REORDERING Feature Activation ..............................235 ............................ 236 ARLY EDIA YPE PARAMETER Feature Activation ..............................236 ST2030 SIP N 1.56) ........................238 EATURES VERVIEW OGIN OGOUT Feature activation ................................239 ........................240 ROADSOFT...
Page 8 ADDRESS SOURCE CONFIGURATION Feature activation ................................267 Keyword definition and usage ..........................267 ” -“M ......................268 NFORMATION SHORTCUT LONG PRESS ST2030 SIP M (BLF) 1.47 ..................269 ONITORING XTENSION EATURE 1 SUBSCRIBE/NOTIFY ............269 SUPPORT FOR MONITORING EXTENSION STATES...
Page 9: Part 1 Safety Information
ST2030s VoIP Business Phone Part 1 Safety Information Operating conditions This telephone is to be operated on a local area network. The telephone must be equipped with the appropriate software version. This guide is written for the actual version of firmware v2.69, you can download the latest on: http://www.thomsonbroadbandpartner.com Read these instructions carefully before connecting the SIP phone to its power source.
Page 10: Qualified Service
No repair can by performed by the customer, if you experience trouble with this equipment for repair or warranty information, please contact your administrator. Thomson disclaims all responsibility in the event of use that does not comply with the present instructions.
Page 11: Part 2 Product Overview And Connections
Part 2 Product overview and connections Introduction This administrator guide describes how to set up, connect cables, and configure your ST2030 SIP Phone. It also provides information on how to configure the Network settings and change the settings of your IP Phone. The administrator guide also includes the way to view and upgrade the firmware.
Page 12: Connecting To The Network And The Pc
ST2030s VoIP Business Phone Connecting to the Network and the PC The SIP Phone has 2 RJ-45 ports that each support 10/100 Mbps full duplex Ethernet connection to external devices- Network port and access port (one for PC and one for LAN). ...
Page 13: Main Features
Note Supported Features In addition to the physical features illustrated in Figure 3.1 and table 3.1, your Thomson ST 2030 also provides the following: Technical specifications:  An integrated 2 Ethernet ports switch that allows the telephone and a computer to share a single Ethernet jack.
Page 14: Supported Protocols
 Redial, Mute, Call log, phone book (30 entries), 10 Speed dial memory keys  Hands free (full-duplex) Supported Protocols Your Thomson ST 2030 SIP Phone supports the following standard Internet protocols:  Internet Protocol (IP) IP is a network layer protocol that sends datagram packets between nodes on the Internet.
Page 15 ST2030s VoIP Business Phone  Network Time Protocol (NTP) NTP is an Internet standard protocol that assures accurate synchronization to the millisecond of computer clock times in a network of computers. NTP sends periodic time requests to servers, obtaining server time stamps and using them to adjust the client's clock.
Page 16: Abbreviations
ST2030s VoIP Business Phone Abbreviations Session Initiation Protocol. An IP telephony signalling text-based protocol developed by the IETF Domaine Name Server DHCP Dynamic Host Control Protocol File Transfer Protocol H323 An ITU standard for realtime voice and videoconferencing over packet networks, including LANs, WANs and the Internet Local Area Network MGCP...
Page 17: Part 3 Phone Operations
ST2030s VoIP Business Phone Part 3 Phone operations General appearance The general appearance of the ST2030 is as below: ST2030 front view ST2030 side view ST2030 with his extension module ST2030s SIP Administrator Guide v3.0 Page 9 of 308...
Page 18: Physical Features
ST2030s VoIP Business Phone Physical Features Figure 3.1 and Table 3.1 illustrate physical features of the ST2030 SIP Phone: Volume keys 3 Soft Keys Clear key Menu Move & Scrolling keys Functions keys(*) Handset Dialing Memory keys * Keys from left to right: phone book/ headset/ speaker/ mute and redial.
Page 19 ST2030s VoIP Business Phone Display keys Confirmation key: Clear key: Clear characters in editing mode or exit to standby display (long click) or return back to the previous page. Menu key: Enables access to menu Phone book key: Enables to access the phonebook and view the names and phone numbers the user wants to dial.
Page 20: The Ip Phone Physical Features
ST2030s VoIP Business Phone Audio keys Volume keys: Adjust the volume of the handset, headset, speaker phone, ringer phone. Speaker key: Activates/disables hands free or group-listing function and switch on/off the microphone Headset key: Activates headset mode during a call Mute key: Activates/deactivates mute function.
Page 21: Display
The product has a full dot matrix LCD screen with a resolution of 128*64 pixels. Its screen is monochrome and not backlighted. The viewing area of the screen is 70.7x38.8 mm (active area: 66.52x33.24 mm). It is able to display characters defined by “Thomson-CharDisplayRequirement-Ed01- 03November2004.doc”. Definitions of Soft Keys The table 3.2 describes the main functions of each soft keys you can use on the SIP phone.
Page 22 ST2030s VoIP Business Phone DNDst Do Not Disturb Down Contrast adjustment Shortcut to “Dial Subscriber” Dsub EndCal Terminate active call Edit Edit parameter content Exit Return to previous menu Format Change display format of specific parameter, such like Date and Time etc. Hold Hold current active line Join...
Page 23: Table 3.2 Definitions Of Soft Keys
ST2030s VoIP Business Phone Transf Transfer a call TrMail Transfer call to voice mail system UnHold Unhold a held line Contrast adjustment User Enter to user submenu View Show details when data item content is more than LCD can display in one line Table 3.2 Definitions of soft keys Icons &...
Page 24: Definitions Of Led
ST2030s VoIP Business Phone Definitions of LED LED Indicator Condition Color Status Default Speaker During FW boot Loudspeaker is activated during a call Default Headset During FW boot Headset or Headset group-listing mode is activated during call Default Mute During FW boot Mute is active Default During FW boot...
Page 25: Extension Module
ST2030s VoIP Business Phone Extension module The extension module features 28 keys. One can plug up to 2 extension modules in a row, leading to a total of 10 + 2x28 = 66 possible “multiline” keys. Memory The ST2030 has 4MB of Flash, and 16MB of RAM Power supply The ST2030 could be powered by either a main power unit or PoE.
Page 26: Part 4 Call Services
ST2030s VoIP Business Phone Part 4 Call Services Talking Mode & Operations 5 kinds of communication mode  Handset mode  Hands free mode  Headset mode  Handset group listening  Headset group listening Operation of off hook There are four ways supported for Off Hook operation ...
Page 27: Main Call Functions
ST2030s VoIP Business Phone Main Call Functions Make a call On-hook dialing In standby mode, there are several ways to show dial number.  Press after / before pressing digital keys directly  In standby mode, press “”, ”” or “Redial” key to display the last 30 phone numbers you called Key Pressed LCD display...
Page 28: Last Number Redial
ST2030s VoIP Business Phone  Use the call log Key Pressed LCD display Date Time Icons Press CalLog to show M i s s e d C a l l L o G Call Log messages R e c e i v e d C a l l L o g D i a l e d...
Page 29: Answer A Call
ST2030s VoIP Business Phone Speed dialing – on-hook dialing  Press any one of F1 – F10 in standby mode  On-hook dialing : go off-hook, re-press the feature key, or press OK key Speed dialing – off-hook dialing  Perform off-hook action ...
Page 30: Call Forward
ST2030s VoIP Business Phone You can do modifications by pressing Change to enter the phone number you want to auto call back, the time of the call and the status. Operation of Call Completion to Busy Subscriber (CCBS)  Place a call and you hear busy tone ...
Page 31: Call Functions During Conversation
ST2030s VoIP Business Phone Call functions during conversation Hold and Retrieve a call  Hold During a call, press to put a call on hold.  Press Unhold to retrieve a held call. Call Transfer During conversation mode, you can press the soft key to activate Call-Transfer service.
Page 32: Conference Call
ST2030s VoIP Business Phone When the callee picks up 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Date Time Icons T a l k i n g . . . T r a n s f B a c k Conference call...
Page 33: Options During A Call
ST2030s VoIP Business Phone When a call/conference is active 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Date Time Icons N u m b e r / N a m e C o n f D u r a t i o n N u m b e r / N a m e...
Page 34: Multi Line
ST2030s VoIP Business Phone Multi line Display of Line/Call status The IP phone supports up to 10 multi-lines that is configurable by administrator via Web-Page access. Each line can be separately operated various services, including answer, reject, hold, transfer and conference call etc. When the phone is in conversation mode, following is the Line/Call status displayed on LCD.
Page 35: Pick Up
ST2030s VoIP Business Phone Switch Between Line/Call The IP phone supports up to 10 multi-lines that is configurable by administrator. Each line can be switched by pressing line keys (i.e. keys F1 – F10). Besides the current active line, all others are held by IP phone and can be resumed by pressing associated line key or pressing proper soft key.
Page 36: Park Up
ST2030s VoIP Business Phone Park up Somewhat similar to the Call Hold feature; however, once a call is placed in the “park” condition, any station within the system may retrieve it by either dialing the appropriate access code. Park a call at the phone, and resume the call at another phone. Set Call park ...
Page 37: Missed Calls
ST2030s VoIP Business Phone Missed Calls Idle Missed Call log CalLog  Entry number is refreshed when pressing 9 10 11 12 13 14 15 16 17 18 19 20 scrolling key ( n / m ) Line 1 Date Time ...
Page 38: Phone Book
ST2030s VoIP Business Phone Content of missed call Parameters Max. Comment Item Name Data Format Length While length of number is more than that LCD Number Numeric can display, press “” or “” to get remainder. Alias (Phone name) Alphanumeric Date Time YY/MM/DD hh:mm Display when there are any message or missed calls...
Page 39 ST2030s VoIP Business Phone The user is able to search and retrieve a phone number without having to scroll between all the entries by typing on a letter. For instance, if the user presses quickly 2 times on key „2‟ (corresponding to “b” letter), the first name beginning with “b”...
Page 40: Character Input- Edit Mode
ST2030s VoIP Business Phone Character Input- Edit Mode The editor is automatically activated whenever you are modifying content of configurable parameters. Apart from entering characters, you can use this editor to navigate through text or delete characters. Even though the maximal text length is not limited by the number of characters on the display because the text can be shifted to the left and right, there are limits for the certain scenarios.
Page 41: Part 5 Configuration Through Lcd
ST2030s VoIP Business Phone Part 5 Configuration through LCD Menu list Ringer Date Time Language Key Echo Status Time Personalize Type Alarm Clock Bell Contrast Config Sample text : AB…H PIN Setting Sample text : 1…8 Shortcut Memory Key Information Enter Password Shortcut 1 SC (1) Shortcut 2 SC (2)
Page 42: F Igure 5.1 O Peration M Enu Lcd D Isplay
ST2030s VoIP Business Phone Mode IP Address MAC Address Networking Gateway PPPoE Netmask NTP Setting Input Admin DNS 1 Password : SIP Configuration 784518 (select DNS 2 VLAN setting number with Ethernet configuration A>a>1 Status Emergency Dial Plan Reset Default Zone Dial Subscibe Auto Stop...
Page 43: Operation Menu Display
ST2030s VoIP Business Phone Operation menu display Home operation menu display 9 10 11 12 13 14 15 16 17 18 19 20 Date Time Icon O P E R A T I O N M E N U C o n f i g A d m i n O p t i o n Config Menu Display...
Page 44: Admin Menu Display
ST2030s VoIP Business Phone Sub-menu list of User Setting Option Message Comment Personalize Set date/time format, Key-echo, language and Ringer type Alarm Clock Activate Alarm clock, set bell and time Contrast PIN Setting Change personal phone password Shortcut Shortcut setting Memory Keys Configure Speed dial keys Information...
Page 45: Option Menu Display
ST2030s VoIP Business Phone Option Menu Display Shortcut Menu Option Idle  Scroll by pressing 9 10 11 12 13 14 15 16 17 18 19 20 Line 1 Up/Down key Date Time Line 2  Select by pressing OK or “Select”...
Page 46: Detailed Lcd Menu Settings
ST2030s VoIP Business Phone Detailed LCD menu settings Idle Menu Home operation menu display 9 10 11 12 13 14 15 16 17 18 19 20 Date Time O P E R A T I O N M E N U U s e r A d m i n O p t i o n...
Page 47 ST2030s VoIP Business Phone  Scroll by pressing 9 10 11 12 13 14 15 16 17 18 19 20 Up/Down key Line 1 Icon Date Time  Select by pressing OK Line 2 or “Select” Line 3 SUB-MENU LIST ...
Page 48: Alarm Clock
ST2030s VoIP Business Phone You can press soft key Format to MM/DD/YY change format. Date (Configurable when DD/MM/YY MM/DD/YY NTP is disabled) YY/MM/DD DD/MM/YY YY/MM/DD You can press soft key Format to hh:mm change format. Time (Configurable when hh:mm am hh:mm 12 Hours NTP is disabled) 24 Hours...
Page 49 ST2030s VoIP Business Phone Contrast Contrast Menu Config Idle  Scroll by pressing 9 10 11 12 13 14 15 16 17 18 19 20 Up/Down key Line 1 Time Date  Exit to higher-level Line 2 S a m p l e T e x t : A B C D E F G H menu by pressing C S a m p l e...
Page 50 ST2030s VoIP Business Phone 9 10 11 12 13 14 15 16 17 18 19 20 Line 1 Icon Time Date  Scroll by pressing Line 2 Up/Down key Line 3  Select by pressing OK Options list or “Select” Line 4 ...
Page 51 ST2030s VoIP Business Phone Information Menu Config Information Idle Content Item Name Configurable Comment Indicate to the user the firmware‟s version FW version Indicate to the use r the hardware‟s version HW version IP address Indicate to the user the IP address MAC address Indicate to the user the MAC address Gateway...
Page 52 ST2030s VoIP Business Phone Menu of Admin Settings Idle Menu Admin You have to input a password to access Admin settings: 784518 Caution 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Date Line 1 Time...
Page 53 ST2030s VoIP Business Phone Networking Configuration Networking Menu Admin Idle 9 10 11 12 13 14 15 16 17 18 19 20  ItemName is refreshed Line 1 Item Name Time Date when pressing scrolling Line 2  Scroll by pressing Line 3 CONTENT Up/Down key...
Page 54: Ntp Setting
ST2030s VoIP Business Phone Content of PPPoE Parameters Item Name Configurable Data Format Options List Max. Length ACC Name (Acc) Alphanumeric PASSWORD (Pwd) Alphanumeric NTP Setting NTP setting Menu Admin Idle 9 10 11 12 13 14 15 16 17 18 19 20 ...
Page 55 ST2030s VoIP Business Phone S e l e c t A c t i v e B a c k Line 6 Profile List Profile Name Comment  Profile name is configurable (refer to “3.4.1 SIP Profile Parameter”) Profile 1 ...
Page 56: Part 6 Configuration Via Web Interface
ST2030s VoIP Business Phone Part 6 Configuration via Web Interface Configuration through the Web interface The phone can also be configured using the web browser. It has a friendly web interface to set and modify parameters. Step 1 – Before starting The IP phone should be connected to the Network and then be powered it up before the connection to the web server.
Page 57 ST2030s VoIP Business Phone CONNECTION PAGE HOME PAGE ST2030s SIP Administrator Guide v3.0 Page 49 of 308...
Page 58 ST2030s VoIP Business Phone SETUP PAGE SETUP: Network setup page (DHCP) ST2030s SIP Administrator Guide v3.0 Page 50 of 308...
Page 59 ST2030s VoIP Business Phone SETUP: Basic setup page Profile edit ST2030s SIP Administrator Guide v3.0 Page 51 of 308...
Page 60 ST2030s VoIP Business Phone APS basic setup ADVANCED PAGE ST2030s SIP Administrator Guide v3.0 Page 52 of 308...
Page 61 ST2030s VoIP Business Phone ADVANCED: STUN page ADVANCED: UPnP ST2030s SIP Administrator Guide v3.0 Page 53 of 308...
Page 62 ST2030s VoIP Business Phone ADVANCED: SNTP ADVANCED: SNMP ST2030s SIP Administrator Guide v3.0 Page 54 of 308...
Page 63 ST2030s VoIP Business Phone ADVANCED: QoS ADVANCED: Ethernet connection ST2030s SIP Administrator Guide v3.0 Page 55 of 308...
Page 64 ST2030s VoIP Business Phone ADVANCED: Outband proxy ADVANCED: SIP signalling ST2030s SIP Administrator Guide v3.0 Page 56 of 308...
Page 65 ST2030s VoIP Business Phone ADVANCED: Codec setup ADVANCED: Option configure ST2030s SIP Administrator Guide v3.0 Page 57 of 308...
Page 66 ST2030s VoIP Business Phone ADVANCED: Call Features ADVANCED: Advanced ST2030s SIP Administrator Guide v3.0 Page 58 of 308...
Page 67 ST2030s VoIP Business Phone ADVANCED: Service Code ADVANCED: Dial plan ST2030s SIP Administrator Guide v3.0 Page 59 of 308...
Page 68 ST2030s VoIP Business Phone ADVANCED: Melody management ADVANCED: System Melody ST2030s SIP Administrator Guide v3.0 Page 60 of 308...
Page 69 ST2030s VoIP Business Phone ADVANCED: CWT Melody ADVANCED: Phone book ST2030s SIP Administrator Guide v3.0 Page 61 of 308...
Page 70 ST2030s VoIP Business Phone ADVANCED: Remote phone book ADVANCED: Call blocking ST2030s SIP Administrator Guide v3.0 Page 62 of 308...
Page 71 ST2030s VoIP Business Phone UTILITY PAGE UTILITY: Save & restart ST2030s SIP Administrator Guide v3.0 Page 63 of 308...
Page 72 ST2030s VoIP Business Phone UTILITY: Backup setting UTILITY: Restore setting ST2030s SIP Administrator Guide v3.0 Page 64 of 308...
Page 73 ST2030s VoIP Business Phone UTILITY: Firmware Update UTILITY: Restore default ST2030s SIP Administrator Guide v3.0 Page 65 of 308...
Page 74 ST2030s VoIP Business Phone UTILITY: Telephone configure UTILITY: LangTbl update ST2030s SIP Administrator Guide v3.0 Page 66 of 308...
Page 75 ST2030s VoIP Business Phone UTILITY: LangTb1 dump UTILITY: ToneTbl update ST2030s SIP Administrator Guide v3.0 Page 67 of 308...
Page 76 ST2030s VoIP Business Phone UTILITY: ToneTbl dump UTILITY: User managment ST2030s SIP Administrator Guide v3.0 Page 68 of 308...
Page 77 ST2030s VoIP Business Phone UTILITY: PIN setting UTILITY: Phone lock ST2030s SIP Administrator Guide v3.0 Page 69 of 308...
Page 78 ST2030s VoIP Business Phone UTILITY: Ping test STATUS PAGE ST2030s SIP Administrator Guide v3.0 Page 70 of 308...
Page 79 ST2030s VoIP Business Phone STATUS : Product info STATUS : Interface Status ST2030s SIP Administrator Guide v3.0 Page 71 of 308...
Page 80 ST2030s VoIP Business Phone STATUS : Phone Status ST2030s SIP Administrator Guide v3.0 Page 72 of 308...
Page 81: Part 7 Auto-Provisioning
ST2030s VoIP Business Phone Part 7 Auto-Provisioning The automatic provisioning requires one DHCP server and one TFTP server. Please find below the way to provision your IP Phone. Automatic phone provisioning with TFTP The automatic phone provisioning is particularly adapted to the provision of several phones at the same time, of any large-scale deployment environment.
Page 82 ST2030s VoIP Business Phone The files: File INF: (extension .txt or .inf) inform about the place of the various files to download (relative way or absolute) Firmware: Version‟s code which needs to be upgrade by the phone File “common_config”: (extension.txt) informs the phone about configurations which need to be upgrade on the level network, sip (or mgcp), auto provisioning, etc…...
Page 83 ST2030s VoIP Business Phone option tftp-server-name "@IP serveur TFTP"; --------------> option 66 option bootfile-name "nomDeFichierINF.txt"; --------------> option 67 option provision-server-ip code 150 = text; ------------->option 150 is text, not binary mode option provision-server-ip "@IP serveur TFTP "; -------------> next server address option vendor-encapsulated-options "http://192.168.70.10/swupgrade_st2030m.txt"...
Page 84 ST2030s VoIP Business Phone 1. In the order: Remote loading of file INF Remote loading of the firmware Reboot Remote loading of file INF Remote loading of the file TelConf Remote loading of the file Common_config Attempt of remote loading of the specific file MAC if he is Reboot Remote loading of file INF Attempt of remote loading of the specific file MAC if he is...
Page 85: Automatic Phone Provisioning With Http
ST2030s VoIP Business Phone Automatic phone provisioning with HTTP Also the provisioning can be carried out via HTTP. For that, it is necessary to follow following steps Needed : 1 router DHCP 1 ST2030 (SIP or MGCP) The last version of the firmware Process of auto provisioning in the theory: At the time of the connection of a phone to the network, it will ask an IP address to DHCP server.
Page 86 ST2030s VoIP Business Phone  descend the cursor using the low button until Information  Select Information and note the IP address indicated 6. Open a WEB browser (Internet Explorer, Mozilla,…) 7. Enter the bar of address : IPaddressofphone/admin.html The IPaddressofthephone being that noted in (5).The Web interface appears. 8.
Page 87 ST2030s VoIP Business Phone 11. Select « Firmware Update » ST2030s SIP Administrator Guide v3.0 Page 79 of 308...
Page 88 ST2030s VoIP Business Phone 12. In the box Firmware Update Using leave "HTTP" and click on the button "Browse...” In the window which opens, select the version of the firmware to be installed. 13. Press « Apply » 14. The phone will normally reboot. 15.
Page 89: Part 8 Ringtones Configuration
ST2030s VoIP Business Phone Part 8 Ringtones configuration 1. Description The ringtones which are integrated into the ST2030 use a RTTTL format. A ringing with RTTTL format looks like the following example: Halloween:d=4,o=5,b=180:8d6,8g,8g,8d6,8g,8g,8d6,8g,8d#6,8g,8d6,8g,8g,8d6,8g,8g,8 d6,8g,8d#6,8g,8c#6,8f#,8f#,8c#6,8f#,8f#,8c#6,8f#,8d6,8f#,8c#6,8f#,8f#,8c#6,8f#,8f#,8c #6,8f#,8d6,8f# These ringtones can be created by the user and they can be also downloaded for free on Internet.
Page 90: Figure 8.2 Ringtone Converter
ST2030s VoIP Business Phone This software makes it possible to the user to create their own melodies directly with RTTTL format. For that, it is necessary to go in "File", "Ringtone composer" and finally "open with new melody" Figure 8.2 Ringtone Converter .The following screen is displayed and will make it possible to the user to compose the melodies according to its choice.
Page 91: Figure 8.4 Ringtone Composer
ST2030s VoIP Business Phone Moreover, a data base, already comprising a great number of melodies to RTTTL format, is integrated into this software. To reach these rings, it is necessary to carry out the handling which is presented to you on the screenshot below. Figure 8.4 Ringtone Composer 3.
Page 92 ST2030s VoIP Business Phone Next we need to find the phone IP address. So: If MGCP phone:  Press on the key menu of the phone  Press on the softkey admin  Press on the button OK of the phone ...
Page 93 ST2030s VoIP Business Phone Next, we must click on « Advanced »: Lastly, it is necessary to select "Melody management" and to enter the name of the file (txt extension) which contains the rings while clicking on browser. ST2030s SIP Administrator Guide v3.0 Page 85 of 308...
Page 94 ST2030s VoIP Business Phone ST2030s SIP Administrator Guide v3.0 Page 86 of 308...
Page 95: Part 9 Feature Overview
ST2030s VoIP Business Phone Part 9 Feature Overview This part is to show the number of new features implemented in each software new release, up to 2.69. This administrator guide is based on firmware v.2.69, you can download the latest administrator guide on: www.thomsonbroadbandpartner.com Note ST20XX SIP New Features (SG vx.69.2)
Page 96: Via Telnet
ST2030s VoIP Business Phone B. Via Telnet To configure, open a command line console, and telnet the phone: Example: V_flag is set to enable (sys set V_flag [administrator]# sys set V_flag 1 [OK] Set OK [administrator]# V_state_prefix is set to 212 (sys set V_state_prefix 212) [administrator]# sys set V__state_prefix 212...
Page 97: Lldp
ST2030s VoIP Business Phone LLDP The following parameters are added for LLDP Service. This parameter is configurable in common config file and telnet. lldpXFlag = 0/1 // 0: Disable LLDP function (Default) // 1: Enable LLDP function lldpTxPeriod = 5 – 32768 (30 default) lldpTTL=120 lldpPortDesc= lldpSysName=...
Page 98: Mgc
ST2030s VoIP Business Phone In this release, a new parameter is added for MGC Service. This parameter is configurable in common config file and telnet. For the flag for this feature MGC_service = 0/1/2 // 0: disable (default) // 1: HW_pstn // 2: Cirpack MGC service The following new parameters are added for Cirpack MGC service/ Dial_Dtmf_Code = „#5‟...
Page 99: Blf
ST2030s VoIP Business Phone In this release, we have implemented the third BLF - Presence based BLF. ST2030 already supports two types of BLF based on “dialog” event package: User and List- oriented. For some other environments, it is desirable to support also a third flavour, based this time on a different subscribe/notify package: presence.
Page 100: Feature Activation
ST2030s VoIP Business Phone Parameter name Description Values Default CLI commands value Type of BLF 0: User-Oriented BLF is sys set blf_type BLFType that is active active [0(User-oriented 1: List-oriented BLF is BLF), 1(List- active oriented BLF), 2: Presence based BLF is 2(Presence-based BLF)] active...
Page 101: Acr Response
ST2030s VoIP Business Phone ACR response When incoming call for ST20XX is Anonymous and phone has ACR enabled, ST20XX sends as response message 603 – Declined but some server require phone should send message 433 - Anonymity Disallowed. Feature Activation A.
Page 102: Attend Transfer
ST2030s VoIP Business Phone Attend Transfer There is a hold action before sending REFER message with current behavior of  attend transfer. However, the transfer behavior will be processed by some server. That`s why some server will have the problem of attend transfer. Our solution is to not sending the hold before REFER message.
Page 103: Preferred Identity
ST2030s VoIP Business Phone Preferred Identity For some server when ST20XX is sending in INVITE header parameter P-Asserted-Identity (which is not assigned for CPE but for network) so phone should not use it. Instead of Phone should correctly send parameter P-Preferred-Identity. A new parameter is added for INVITE header parameter.
Page 104: Dscp Of Dhcp
ST2030s VoIP Business Phone DSCP of DHCP In this release, you can change DSCP of DHCP separately. Feature Activation A. Via Web GUI 1. Login to ST20XX Web GUI 2. Go to Advanced Page 3. Choose QoS 4. In Diffserv, choose Voice 5.
Page 105: Via Aps
ST2030s VoIP Business Phone B. Via APS APS in [qos] section of both Common and Specific-MAC config files with the new parameter – DSCP3. DSCP3 = 0 ~ 63 [net] … DSCPflag=1 … [qos] … DSCP3=0 … C. Via Telnet To configure, open a command line console, and telnet the phone: Example: [administrator]# net set dscp 1...
Page 106: Input Mode
ST2030s VoIP Business Phone Input mode In the release package, it is possible to change the input mode and char set used. 1. LangTbl_x.69.2.zz (original English Language Table). 2. LangTbl_x.69.2_Czech.zz (sample Czech Language Table – Still in English but with Czech input mode).
Page 107: St20Xx Sip New Features (Sg Vx.68.5)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.68.5) Overview This document describes a set of features included in ST2030 and S2022 SIP V2.68.5 and 4.68.5 respectively in order to improve their usability in different environments. Hua Wei SoftSwitch Starting with this new release, ST20xx have implement Softswitch (Hua Wei SoftX3000 V300R006) PSTN call handling including call waiting and switching.
Page 108 ST2030s VoIP Business Phone [Answer] and [Reject] softkey displays on the screen. ST2030s (Phone B) ST2022s (Phone B) Date Hour Icons 01 PSTN Call Answer Reject Answer Reject Server Phone B INFO Press [Answer] to take the PSTN 2 call. 200 OK INFO: flashhook when press [Answer] Remark: Go back to previous screen when [Reject] is pressed.
Page 109 ST2030s VoIP Business Phone Switch implementation Requirement [Switch] softkey is required to caller parties to switch between caller during conversation Below is to list out a flow which shows IP Phone B call to IP phone A in conversation, then PSTN 1 call to IP phone B.
Page 110: Feature Activation
ST2030s VoIP Business Phone Phone A Server Phone B INVITE (with SDP2) Server invites phone A 200 OK (with SDP2) INVITE (with SDP2) Server invites phone B 200 OK (with SDP2) Phone A hang up the call 200 OK INFO: tone-type=busy INFO Phone B know that the waiting phone is hang up and the...
Page 111: Via Telnet
ST2030s VoIP Business Phone D. Via Telnet To configure, open a command line console, and telnet the phone: Example: 1. MGC_service is set to disable (sys set mgc_service [administrator]# sys set mgc_service 0 [OK] Set OK [administrator]# 2. MGC_service is set to Hua Wei Softswitch PSTN handling (sys set mgc_service [administrator]# sys set mgc_service 1...
Page 112 ST2030s VoIP Business Phone All parameters changed in Option Configure page are configured without reload. Except “ACD”, “Shared Call Appearance”, “Conference Mode”, “Start Spare FK” and “BLF Type”, all parameters changed in Call Features page are configured without reload. ST2030s SIP Administrator Guide v3.0 Page 104 of 308...
Page 113: Ccbs Enable/Disable
ST2030s VoIP Business Phone Apart from “Use Secure outgoing calls if possible”, “Silence Suppression”, “Acoustic Echo Cancellation (AEC)”, “Packet Loss Compensation”, all parameters changed in Advance page are configured without reload. CCBS Enable/Disable A new parameter is added for CallBack feature. This parameter is configurable in common config file and telnet.
Page 114: Via Telnet
ST2030s VoIP Business Phone F. Via Telnet To configure, open a command line console, and telnet the phone: Example: 1. Auto_cb is set to enable (lcdui set auto_cb [administrator]# lcdui set auto_cb 1 LcdUi Set Command OK! [administrator]# 2. Auto_cb is set to disable. (lcdui set auto_cb [administrator]# lcdui set auto_cb 0 LcdUi Set Command OK!
Page 115: Feature Activation
ST2030s VoIP Business Phone 4. The cipher-suites of TLS is supported by OpenSSL library(0.9.7d), and cipher-suites negotiation is supported according to capability of remote side 5. Switching transport layer to TLS while receiving SIP messages with any one of following content: Transport parameter(transport=tls) in Contact and Record-Route header etc…...
Page 116: Via Aps
ST2030s VoIP Business Phone With the activation of SIPS + TLS, you are required to upload a Certificate and Private Key for authentication on the phone. Set port to be 5061. The certificate from trusted authorities can be imported to create an internal Certificate Authority (CA).
Page 117: Via Telnet
ST2030s VoIP Business Phone [sip] … TransportFlgMP1=0 // UDP for profille 1 TransportFlgMP2=1 // TCP for profille 2 TransportFlgMP3=2 // TLS for profille 3 TransportFlgMP4=2 // TLS for profille 4 TransportFlgBK1=0 // UDP type for backup profile 1 TransportFlgBK2=1 // TCP type for backup profile 2 TransportFlgBK3=2 // TLS type for backup profile 3 TransportFlgBK4=2...
Page 118: Improve Https Aps Feature
ST2030s VoIP Business Phone Improve HTTPS APS feature Now, starting with the new release, SG x.67.2, St20xx HTTPS auto provisioning supports both client and server authentication with using certificates. This improvement is totally enhanced a reliable and secure provisioning based on HTTPS requests from ST20xx to server and server to ST20xx.
Page 119: Support Encryption Of Configuration Files In Aps
ST2030s VoIP Business Phone Support Encryption of Configuration files in APS In current implementation, file transfer via APS TFTP and HTTP is transparent, the confidential information, e.g. accounts, password, are not protected. Therefore, starting with the new release, x.67.2, the transfer of encrypted configuration files is supported to prevent data exposure during APS.
Page 120 ST2030s VoIP Business Phone In Linux Platform: Filename: Linux_aes_cbc_128_bin.tar.gz ../Encryption Tool folder.  tar zxvf FileName.tar.gz  cd FileName  ./aes_cbc_128 <key> <source file or directory> <destination file or directory>  „*.ser‟ file will be generated Things to know: The ComConfig/ MacConfig file should be encrypted with symmetric key offline before doing APS.
Page 121: Feature Activation
ST2030s VoIP Business Phone Feature Activation A. Via WebGui Visit the SETUP  , Basic Setup will be shown like below: Input the decryption key (16 digits) in the field and confirm field. If the key is different with the key for confirmation, an error message will prompt you to input the key again.
Page 122: Via Aps
ST2030s VoIP Business Phone APS log (if Decryption key not-Match): Begin Common Config download... AES decrypt common config file successfully! CommonConfig: ComConf2030SG.R11.1.090213.2.67.1.ser download successfully! Begin Mac config download... MacConfig: ST2030S_00147F00DFE4.ser download successfully! AES decrypt mac file successfully! Error: Parse config file failed or config_sn tag not found! Begin upgrading config file...
Page 123 ST2030s VoIP Business Phone Visit the ADVANCED  Dialling Call page, the Dialling Call interface will be shown like below: Line Account shows the outgoing call identify of the phone Make an outgoing call by inputting telephone number or SIP URL in the field.
Page 124 ST2030s VoIP Business Phone To make an outgoing call, you can just choose the active outgoing identity from the pull-down menu of Line Account, and input the telephone numbers or SIP URL in the field. Click the icon to make an outgoing call. A status will be shown on the screen to indicate the call is successfully dialed out.
Page 125 ST2030s VoIP Business Phone Phone Book From the phone book page, the enhancement enable you to delete entry, modify entry and call back to the entries you want. You can press the button from call dailling page or go to ADVANCED  Phone book to access the page.
Page 126: Sip Message During Call (Rfc 3428)
ST2030s VoIP Business Phone SIP Message during call (rfc 3428) Currently, ST20xx supports SIP message method. But it is limited to in idle status. In other words, the phone can only receive short message pushed by server in idle mode to indicate its current status. Now, starting from the new release, SG x.67.2, St20xx not only supports the receving message in idle mode, but also in conversation mode.
Page 127: Feature Activation
ST2030s VoIP Business Phone Feature Activation Same as the current implementation. This feature does not need specific activation to be supported. With using the current parameter, it is to avoid messages attacks from non desired sources. The parameter is AuthMessageServer. Default value is 0.0.0.0, which means phone accepts all messages received from everywhere.
Page 128: Dns Query ( Circular Method)
ST2030s VoIP Business Phone DNS Query ( Circular Method) In the new release today, x.67.2, ST20xx have done an improvement on the mechanism of the DNS Query, which increases the efficiency on the DNS request. Current Implementation (up to SG1.66) For each SIP message sent from the ST20xx to the proxy server, it have to wait for the IP resolution done on the Pri DNS server.
Page 129: Via Telnet
ST2030s VoIP Business Phone B. Via Telnet To configure, open a command line console, and telnet the phone: Support Remote call logs for local user Remote call logs are currently supported for login/logout function in ST20xx. However, it doesn‟t support for normal user. In this section, you will know the implemetation of the remote call log for normal user in the new release SG x.67.2.
Page 130 ST2030s VoIP Business Phone The call-log file contains 3 sections: the missed calls, the received calls and the dialed calls. Each section can have up to 30 calls. The calls shall be classified from the most recent to the oldest. Each call is described by the phone number, phone name, date and time of the call.
Page 131: Feature Activation
ST2030s VoIP Business Phone The data are stored on the phone until the user quits the call log menu by pressing [Back] soft key or “C” key or the phone returns to the idle screen after a timeout. Feature Activation A.
Page 132: St20Xx Sip New Features (Sg Vx.66.2)
ST2030s VoIP Business Phone Where, #LOGIN is the phone number of the active profile #PASSWORD is the SIP password of the active profile #IP is the IP address of the phone #MAC is the MAC address of the phone [sys] …...
Page 133: Feature Activation
ST2030s VoIP Business Phone Transf] softkey enable/disable on ringing in MMI is directly followed the activation / deactivation of callforward bit accordingly. New Implementation A new parameter in Common and MAC configuration files is added to increase the flexibility to assign the [Transf] softkey on ringing shown in MMI with/without respect to the call forward bit in parameter “OptionVisible”...
Page 134: Via Aps
ST2030s VoIP Business Phone J. Via APS: APS in [ipp] section of both Common and Specific-MAC config files with the new parameter: [ipp] … OptionVisible=8191 TransfOnRingFlag =0 //by default, transfer on ringing is always enabled …... K. Via Telnet To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 126 of 308...
Page 135: Call-Hold "Inactive" Method
ST2030s VoIP Business Phone Call-hold “inactive” method To enhance the compatibility with different softswitches, a new call-hold method is introduced in this section. Current implementation Currently, ST20xx implements “send-only” method for holding a call, carried in SDP session. Content-Type: application/sdp Content-Length: 221 o=2215 1325412 1325413 IN IP4 192.168.1.102 c=IN IP4 192.168.1.102...
Page 136: Feature Activation
ST2030s VoIP Business Phone Feature Activation A new parameter is needed to configure this function and with some additional definitions listed below. call_hold_method=<0|1>, 0 is by default call_hold_method=0, “send-only” call-hold method is used call_hold_method=1, “inactive” call-hold method is used A. Via APS: APS in [sip] section of both Common and Specific-MAC config files with the new parameter: [sip]...
Page 137: Comverse: Line And Service Supervision (Reg & Ua-Profile Event Package)
ST2030s VoIP Business Phone Comverse: Line and Service supervision (reg & ua-profile event package) The purpose of this feature is to increase the ability of ST20xx to request and monitor the registration status, change user profile and receive notifications related to a set of services of other supervised SIP phones in Comverse environment, like: - DND activation status - Call Forward activation status...
Page 138 ST2030s VoIP Business Phone and « Unregistered » . The service variable for DND supervision will be discussed in next section. Upon reception of a NOTIFY request, ST20xx update the lamp associated to the supervised phone accordingly. Implementation and configuration Table below describes an overall ST20xx‟s behavior that is used for implementation, based on the Dialog and Registration and DND supervision of a same target:...
Page 139 ST2030s VoIP Business Phone Service variable supervision Now, ST20xx has already implemented the service variable supervision, the “ua-profile” event package is supported. But working in Comverse environment, this feature has been enhanced, which not only allows supervising phone itself, but also supervised with other phones. The service allows ST20xx to be periodically notified about the state of a set of services implemented by the network.
Page 140 ST2030s VoIP Business Phone When ST20xx receives the SIP NOTIFY message, indicating successful profile enrollment, it makes it effective immediately and displays service status to the user. The duration of the subscription is 3600 by default. Implementation and configuration One function key will be affected to each service. Depending on the state of the service, the corresponding function key‟s LED will be turned ON or OFF.
Page 141: Feature Activation
ST2030s VoIP Business Phone To: <sip:*70x#@domain.com> (where x is the hunt group extension) INVITE sip: *71x#@domain.com *71x# SIP/2.0 From: <…> To: <sip:*71x#@domain.com> (where x is the hunt group extension) Remark: Call Forward: it is only possible to activate/deactivate for the self phone. Not support for the supervision of other phone in this case.
Page 142: Via Webgui
ST2030s VoIP Business Phone FK5 to FK6: Use to monitor the status of CFW and DND of the supervised phone (Supervised phones: 2005) FK7: CFU (Self Phone) LED indicates ON/Off, Press Key for activation Deactivation depends on the current status of the service. FK8: DND (Self Phone) LED indicates ON/Off, Press Key for Activation or Deactivation depends on the current status of the...
Page 143 ST2030s VoIP Business Phone Select the item in the roll down “Type” menu: Supervised Line and enter the supervised phone numbers in the corresponding field of the function keys. In this case, the function keys 3 to 4 will monitor the dialog, registration with DND service for the corresponding supervised phones.
Page 144 ST2030s VoIP Business Phone You can also press the up and down arrow to change the priority for the enabled service. The priority is to decide which services would be used to the first assigned function key. The higher the priority, the first assigned function key will be used.
Page 145 ST2030s VoIP Business Phone environment. For more detail, please refer to “ST20xx SIP New Features SG vx.62” P.145 Remark: Now, if the Starcodes are used for self-phone, those will be denoted by SC. While, if the Starcodes are used for supervised phones, which will be denoted by SV.
Page 146 ST2030s VoIP Business Phone Enter the starcodes for SFOnSV , SFOffSV, HGOnSV and HGOffSV respectively and Apply. ST2030s SIP Administrator Guide v3.0 Page 138 of 308...
Page 147: Via Aps
ST2030s VoIP Business Phone B. Via APS: In order not to conflict with the original user-oriented BLF, a new parameter will be added in Common and MAC configuration files to enable the feature of line supervision of registration and service supervision for each function key.
Page 148: Via Telnet
ST2030s VoIP Business Phone …. [sip] …. CallFwdFlg=sc // StartCode for call forward (self phone) CallFwdOffSC=*211* CallFwdAlwaysSC=*21x* DNDFlg=sc // StartCode for DND (self phone) DNDOnSC=*31# DNDOffSC=*32# SFOnSV=*270x* // StartCode for SF (supervised phone) SFOffSV=*271* HGOnSV=*71x# // StartCode for HG (supervised phone) HGOffSV=*70x# …...
Page 149: Comverse: Redirecting Identity And Name Presentation
ST2030s VoIP Business Phone Comverse: Redirecting identity and name presentation Currently, the ST20xx do not support the "display-name" string of the Diversion header. With working in Comverse environment, the feature of redirecting identity and name presentation allows its displays on the terminating phone. And the redirecting identity and name information is received on the initial INVITE request.
Page 150: Feature Activation
ST2030s VoIP Business Phone 1. In Ringing (During call incoming) state St20xx display the Caller and the Redirecting name alternatively on the screen, and the redirecting name will be displayed in reverse video. The time interval for the swap will be in 1 second. If the diversion header has Redirecting party Name, phone should display “Bob the Manager”, but if it doesn‟t have Redirecting party Name, phone should display Number “81000541”.
Page 151 ST2030s VoIP Business Phone ST2030s SIP Administrator Guide v3.0 Page 143 of 308...
Page 152: St20Xx Sip New Features (Sg Vx.65.1)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.65.1) Overview This document describes a set of features included in ST20xx vx.65.1 in order to improve their usability in different environments. Multi-registration on a same server St20xx is able to support multi-registration on the same server. Same as before, the main line will be the master.
Page 153: Via Aps
ST2030s VoIP Business Phone Example: M. Via APS: APS in [sys] section of both Common or Specific-MAC config files with the Parameter: M will be used to denote the option for multi-registration, like below: [sys] ….. Current_Max_Multiline=5 (available overall number of Mulit-registration line is Multiline-1) FeatureKeyExt02=M/:<sip:2001|username|password|PhoneName2001>...
Page 154: Via Telnet
ST2030s VoIP Business Phone N. Via Telnet To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 146 of 308...
Page 155: St20Xx Sip New Features (Sg Vx.64.2)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.64.2) Overview This document describes a set of features included in ST20xx vx.64.2 in order to improve their usability in different environments. Support Private Number (ST2030 only) Our customer‟s architecture includes a private identifier (called “pn”) in the INVITE message in order to notify the end-user with a more legible number notification.
Page 156: Feature Activation
ST2030s VoIP Business Phone Feature Activation A) Through APS: In Common or Mac Config file, user can set enable or disable the use of private number to 0 or 1 respectively. Default value is 0 [sip] … use_PrivateNumber=0 (default) use_PrivateNumber=1 ( Notify the end-user with a more legible number ) …...
Page 157: Softkey Left Scrolling In Talking Mode (St2030 Only)
ST2030s VoIP Business Phone Softkey left scrolling in talking mode (ST2030 only) In order to improve the MMI and have the same behaviour between idle mode and talking mode, the navigation thru the soft keys has to be changed Current Implementation (up to SG v1.63) Currently you cannot go directly from Page1 to Page3.
Page 158: St20Xx Sip New Features (Sg Vx.63)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.63) Overview This document describes a set of features included in ST2030 and S2022 SIP v1.63 and 3.63 respectively in order to improve their usability in different environments. Incoming Call during transfer When users try to transfer a call and receive a call at that moment, the transfer shall not be cancelled.
Page 159 ST2030s VoIP Business Phone -if user A rejects the call from D, transfer screen is resumed Call flow 1: Phone Phone Phone Phone 1002 1003 1004 1001 A call B B answers A and B are in conversation A wants to transfer B to C A press |Transf| then dial C‟s number...
Page 160 ST2030s VoIP Business Phone Call flow 2: Phone Phone Phone Phone 1002 1003 1004 1001 A call B B answers A and B are in conversation A wants to transfer B to C A press |Transf| then dial C‟s number The user dial C‟s number Enter a number...
Page 161 ST2030s VoIP Business Phone Call flow 3: Phone Phone Phone Phone 1002 1003 1004 1001 A call B B answers A and B are in conversation A wants to transfer B to C A press |Transf| then dial C‟s number The user dial C‟s number Enter a number...
Page 162: 2- Blind Transfer
ST2030s VoIP Business Phone 2- Blind Transfer When the user initiates a blind transfer, the phone launches a “recovery timer”. This timer ends if the 2nd correspondent answers and transfer is then completed or if first dialog is recovered due to failure in the transfer or timer expiration.
Page 163 ST2030s VoIP Business Phone Call flow 4: Phone Phone Phone Phone 1002 1003 1004 1001 A call B B answers A and B are in conversation A wants to transfer B to C A press |Transf| then dial C‟s number Enter a number 1003 |Transf| |...
Page 164: Number Display In Standby
ST2030s VoIP Business Phone Number display in Standby St2030s is able to show a different number in standby that the one used for registration. For this purpose, two new parameters have been included in section [sip] of common or MAC config files in each profile. DisplayNumFlag value is disable by default DisplayNum could be any char.
Page 165 ST2030s VoIP Business Phone DisplayNum2= DisplayNum3= DisplayNum4=2001 (max digits is 20) … B) Through Telnet: To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 157 of 308...
Page 166: Only )
ST2030s VoIP Business Phone List oriented BLF V2 (ST2030 only) List-oriented BLF is already supported by ST2030. In Broadsoft environment, this feature allowed so far monitoring other line status, and speed dialing. Call capture was not possible on FW 1.62.3 or previous version. A number of improvements have been done on server side.
Page 167: User Action
ST2030s VoIP Business Phone  LED off - if all the state tags are Terminated <?xml version="1.0" encoding="UTF-8"?><dialog-info xmlns="urn:ietf:params:xml:ns:dialog-info" version="7" state="full" entity="thomson2@as.iop1.broadworks.net"><dialog id="bG9jYWxIb3N0NDU5NDY5OjA=" direction="recipient"><state>terminated</state> <local><identity display="Broadsoft SIP2">sip:thomson2@as.iop1.broadworks.net</identity><identity display="Broadsoft SIP2">tel:+12408881412;ext=1412</identity></local> </dialog></dialog-info> User action There are three different statuses defined when the BLF Key is pressed: 1.
Page 168 ST2030s VoIP Business Phone Then go to Advanced  Call feature. Parameter “Start Spare Fk” indicates the first function key which will be dynamically provisioned. This parameter, by default, is automatically set to Multiline+1. If you want to keep some keys reserved for speeddial, please change this value Select “List-oriented BLF”, and configure the List-uri to which the phone should subscribe, in accordance with your server configuration ST2030s SIP Administrator Guide v3.0...
Page 169 ST2030s VoIP Business Phone Then, you can check the configuration through Advanced  Call feature  Function Key table. To enable the call pickup feature from function key BLF, please enter the starcode defined in your server. ST2030s SIP Administrator Guide v3.0 Page 161 of 308...
Page 170 ST2030s VoIP Business Phone Please refer to “ST20xx SIP New Features SG vx.62” P.145  How to activate call Pick-Up Service. B) Through APS: The parameters governing this feature, both included in the [sys] section, are: BLFType Value : 0 or 1 Meaning : 0 : User-oriented BLF is active 1 : List-oriented BLF is active Default value: 0...
Page 171 …. With this parameters, List-oriented BLF is enabled, the List Uri is List- URI@thomson.net and the first key to be provisioned is F6 For the call pick up service, please refer to “ST20xx SIP New Features SG vx.62” P.145  How to activate call Pick-Up Service.
Page 172: Improved Shared Call Appearance (Sca)
ST2030s VoIP Business Phone Improved Shared Call Appearance (SCA) Thomson ST20xx currently supports SCA according to Broadsoft R14 specification. However, due to its single line architecture, which only allows 1 SIP account active at a time. This section addresses the improvements to be done in ST20xx to enhance its support for this feature and its application developed for Broadworks R14 only.
Page 173: Feature Activation
ST2030s VoIP Business Phone 5. Behavior when an incoming call is received and another one is active: In the event that additional call arrives when the user is already engaged in a call, the phone should provide call waiting indicator. Calls to other lines (than primary line) should be indicated with on-screen display and Function Keys LEDs, with the same approach as above: function key led which corresponds to that appearance is the one to be...
Page 174 ST2030s VoIP Business Phone Then, you have to set the Multiline (available overall number of SCA‟s is Multiline-1), in Advanced  Advanced. Function Key 1 will always correspond to the main line. Then go to Advanced  Call feature  Function Key table. An additional item will be created in the roll down “Type”...
Page 175 ST2030s VoIP Business Phone B) Through APS: APS in [sip] section of both Common or Specific-MAC config files with the Parameter: - SharedCallAppearance= 0 (0 by default, inactive; 1 to active) - SCAMainLinePrivate= 0 (0:default, 1: Main line is private, this flag only take effect with SharedCall Appearance=1) [sip] SharedCallAppearance= <0|1>...
Page 176 ST2030s VoIP Business Phone C) Through Telnet: To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 168 of 308...
Page 177: St20Xx Sip New Features (Sg Vx.62)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.62) Overview This document describes a set of features included in ST2030 and S2022 SIP v1.62 and 3.62 respectively in order to improve their usability in different environments. Second dial-tone for PBX-like environments. This new feature specifies how to simulate the behavior of an analog phone or a “proprietary phone”...
Page 178 ST2030s VoIP Business Phone Two new parameters have been created to support this new feature: , to indicate if the phone is behind a PBX or not. PBXconfiguration <Dial-Tone> will be played first when user goes off hook (as it was already the case until this version), no matter the value of this parameter.
Page 179: Feature Activation
ST2030s VoIP Business Phone Feature Activation A) Through the WebGui: The activation of this feature is accessible from the WebGui in the Advanced  Dial Plan section. B) Through APS: For this purpose, two new parameters have been included in the [sys] section of the Common/MAC config files, to be able to activate the configuration of the second dial tone behind a PBX.
Page 180 ST2030s VoIP Business Phone C) Through Telnet: For this purpose, two new parameters have been created, described as follow: sys set PBXconfiguration (0: default setting 1: phone behind a PBX) sys set PBXprefix (0 to 9, * or #) To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 172 of 308...
Page 181: New Specific Keys In The Dial Plan
ST2030s VoIP Business Phone New specific keys in the Dial Plan. The following DigitMap syntax definition was used by ST20xx to define when the phone has to stop collecting digits and initiate a call in off hook mode: However it does not cover the specific functions on server side (controlled by n-digits star codes) like enable or disable access voice mail server, enable or disable voice recording, etc which often include “*”...
Page 182: Feature Activation
ST2030s VoIP Business Phone “####”: If dialed number exactly matches 4 “hash” digits, then we send it to server. “#xxx”: If dialed number exactly matches 4 digits and the first digit is “#”, then we send it to server. “*xx#”: If dialed number exactly matches 4 digits and the first digit is “*” and last digit is “#”, then we send it to server.
Page 183 ST2030s VoIP Business Phone C) Through Telnet: For this purpose, you have to use the following telnet parameters (already existing in previous versions): sip set voip_dialplan (dialplan_string(max:120chars)) sys set emg_dialplan (dialplan_string(max:120chars)) To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 175 of 308...
Page 184: New Error Message Display For 403 Response
ST2030s VoIP Business Phone New error message display for 403 response. When the user dials a number that is not authorized on a network, it receives a 403 Forbidden message. On current implementation, when the phone receives a 403 Forbidden message, it displays “Dialing Failed !”.
Page 185: Services Supervision Feature
Via: SIP/2.0/UDP 10.0.0.55:5060;branch=z9hG4bK4696915359658109209-910168 From: <sip:2205@10.0.0.5:5060>;tag=c0a80101-de357 To: <sip:2205@10.0.0.5:5060> Call-ID: e32b4-c0a80101-d-3@10.0.0.55 CSeq: 1 SUBSCRIBE Max-Forwards: 70 Event: ua-profile;profile-type=user Accept: application/service-user-profile+xml Expires: 3600 Contact: <sip:2205@10.0.0.55:5060;user=phone> Allow-Events: refer,dialog,message-summary,check-sync,talk,hold User-Agent: THOMSON ST2030 hw0 fw1.62 00-0E-50-4E-88-E0 Content-Length: 0 ST2030s SIP Administrator Guide v3.0 Page 177 of 308...
Page 186 ST2030s VoIP Business Phone Then, SIP Server receives successfully this Subscribe and identifies the requested profile data. It prepares a SIP NOTIFY message to ST20xx with the ua profile data inserted inside the body, and sends it immediately to complete the enrollment. B) Content Retrieval A successful profile enrollment leads to an initial SIP notification, and may result in subsequent change notifications.
Page 187 ST2030s VoIP Business Phone When ST20xx receives the SIP NOTIFY message, indicating successful profile enrollment, it makes it effective immediately and displays service status to the user. The duration of the subscription is 3600 by default. C) Change Notification Each time service configuration changes, the SIP server sends a NOTIFY message to communicate the updated service variables to the ST20xx.
Page 188: Feature Activation
ST2030s VoIP Business Phone Feature Activation A) Through the WebGui: This feature can not be configured through the Web (as mention above). However you can check the configuration through Advanced – Call Feature – Function Key Table : B) Through APS: For this purpose, two new parameters have been included in the [sys] section of the Common/MAC config files, to be able to activate the feature.
Page 189 ST2030s VoIP Business Phone  the other values are the order of the function key affected to this service. CallFwd is linked to “cfu_on” valiable is linked to “dnd” valiable SecFilter is linked to “sf_on” valiable HuntGroup is linked to “hg_rdy” valiable For example: [sys] Current_Max_Multiline=5...
Page 190 ST2030s VoIP Business Phone ST2030s SIP Administrator Guide v3.0 Page 182 of 308...
Page 191: Star Codes
ST2030s VoIP Business Phone Star Codes. Star Codes (SC) or Feature Access Codes (FAC) are special char or digity patterns that are dialed from a phone to invoke particular server features. Typically, FAC are invoked using a short sequence of digits that are dialed using the keypad on an analog phone, while IP phones users select soft-keys to invoke the same features.
Page 192: Call Pick-Up Service
ST2030s VoIP Business Phone Call Pick-Up Service Feature Activation A) Through the WebGui: The activation of this feature is accessible from the WebGui in the Advanced  Call Feature section. B) Through APS: For this purpose, two new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature.
Page 193: Behavior
ST2030s VoIP Business Phone Behavior Call pick-up with Soft Key 1. Press Pick-Up soft key. 2. The phone will display "Enter a number". 3. Then, user will enter the extension number to be picked up. 4. The phone will send the INVITE with TO header set to "SC + phoneNr" Call pick-up with Function Key (User oriented BLF) 1.
Page 194 ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature. [sip] CallFwdFlg=sc CallFwdOffSC=*73 CallFwdAlwaysSC=*72 CallFwdBusySC=*90 CallFwdNoAnswerSC=*92 TransferOnRingSC=*94 ST2030s SIP Administrator Guide v3.0 Page 186 of 308...
Page 195: Behavior
ST2030s VoIP Business Phone C) Through Telnet: For this purpose, new parameters have been created, described as follow: sip set CallFwdFlg [local|sc] sip set CallFwdOffSC ( Call FwdOff star code) sip set CallFwdAlwaysSC (Call FwdAlways star code) sip set CallFwdBusySC (Call FwdBusy star code) sip set CallFwdNoAnswerSC (Call FwdNoAnswe star code) sip set TransferOnRingSC (Transfer OnRing star code) Behavior...
Page 196: Do Not Disturb Service
ST2030s VoIP Business Phone Call Flow: Do Not Disturb Service Feature Activation A) Through the WebGui: The activation of this feature is accessible from the WebGui in the Advanced  Call Feature section. ST2030s SIP Administrator Guide v3.0 Page 188 of 308...
Page 197: Behavior
ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature. [sip] DNDFlg=sc DNDOnSC=*67 DNDOffSC=*68 C) Through Telnet: For this purpose, new parameters have been created, described as follow: sip set DNDFlg [local|sc] sip set DNDOnSC (DND on star code) sip set DNDOffSC (DND off star code)
Page 198 ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature. [sip] TrVoiceMailFlg1=local TrVoiceMailFlg2=local TrVoiceMailFlg3=local TrVoiceMailFlg4=local TrVoiceMailOnSC1= TrVoiceMailOnSC2= TrVoiceMailOnSC3= TrVoiceMailOnSC4= TrVoiceMailOffSC1= TrVoiceMailOffSC2= TrVoiceMailOffSC3=...
Page 199: Behavior
ST2030s VoIP Business Phone Behavior Transfer to voicemail ON 1. Using the navigation keys, press TrMail, select ON 2. The phone sends the INVITE with TO header = SC Transfer to voicemail OFF 1. Using the navigation keys, press TrMail, select OFF 2.
Page 200: Behavior
ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature. [sip] CallParkFlg=local CallParkSC= CallRetreiveSC= C) Through Telnet: For this purpose, new parameters have been created, described as follow: sip set CallParkFlg [local|sc] sip set CallParkSC ( Call Park star code) sip set CallRetreiveSC (Call Retreive star code)
Page 201: Behavior
ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature. [sip] CallBlockFlg=local CallBlockAllowSC= CallBlockRejectSC= CallBlockOFFSC= C) Through Telnet: For this purpose, new parameters have been created, described as follow: sip set CallBlockFlg [local|sc] sip set CallBlockAllowSC (Call Block Allow star code) sip set CallBlockRejectSC (Call Block Reject star code)
Page 202: Privacy Call Service
ST2030s VoIP Business Phone Call Blocking Rejected 1. Press Menu - Option - CallBlocking - Select 2. Press Edit - Select Rejected - press Save 3. The phone will send the INVITE with TO header = SC Call Blocking OFF 1.
Page 203: Behavior
ST2030s VoIP Business Phone C) Through Telnet: For this purpose, new parameters have been created, described as follow: sip set ClirFlg [local|sc] sip set ClirOnSC ( Clir On star code) sip set ClirOffSC (Clir Off star code) Behavior CLIR ON (Privacy code) 1.
Page 204: Behavior
ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the feature. [sip] CallWaitingFlg=local CallWaitingOnSC= CallWaitingOffSC= C) Through Telnet: For this purpose, new parameters have been created, described as follow: sip set CallWaitingFlg [local|sc] sip set CallWaitingOnSC ( Call Waiting On star code) sip set CallWaitingOffSC (Call Waiting...
Page 205 ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sys] section of the Common/MAC config files, to be able to configure the feature. [sys] Current_Max_Multiline=5 FeatureKeyExt06=L/<sip:2206> FeatureKeyExt07=S/<sip:2207> FeatureKeyExt08=S/<sip:2208> FeatureKeyExt09=S/<sip:2209> FeatureKeyExt10=D/<sip:*123456789#> ST2030s SIP Administrator Guide v3.0 Page 197 of 308...
Page 206: Behavior
ST2030s VoIP Business Phone C) Through Telnet: For this purpose, new parameters have been created, described as follow: sys set fkuri id(1~66) uri_string sys set fktype id(1~66) 0/1/2/3/4/5/6/7 (L/S/E/R/G/B/D/V) Behavior 1. During a conversation, press the Function key 2. The phone will dial the FK number as DTMF, with configured or negotiated DTMF method.
Page 207 ST2030s VoIP Business Phone B) Through APS: For this purpose, new parameters have been included in the [sys] section of the Common/MAC config files, to be able to configure the feature. [sys] Current_Max_Multiline=5 FeatureKeyExt09=S/<sip:2209> FeatureKeyExt10=V/<sip:*8|1103|#> C) Through Telnet: For this purpose, existing parameters are used, described as follows: sys set fkuri id(1~66) uri_string sys set fktype id(1~66) 0/1/2/3/4/5/6/7...
Page 208: Behavior
ST2030s VoIP Business Phone Behavior 1. Press the Function key 2. The phone will display "Enter a number" displaying also the programmed number. 3. User will modify or not that number, and then press OK to dial out. 4. The phone will send an INVITE with TO header = SC + phoneNr + SC If you press the FK during a call, it will be treated as another call (so the phone will put the current active call on hold, perform the action, and will wait for user to go back to the active call).
Page 209: St20Xx Sip New Features (Sg Vx.61)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.61) Overview This document describes a set of features included in ST2030 and S2022 SIP v1.61 and 3.61 respectively in order to improve their usability in different environments. Ad-Hoc Conf (RFC 4579) The ST20xx is now a "conference-aware"...
Page 210 ST2030s VoIP Business Phone ST20xx as Initiator is ready to receive early Byes to its Refers, with or without received Notify (200)· Here you can find an example Call-Flow of Centralized Conference: Once A is in a call with the "focus UA", it could add another participant (D) in the same way: 9.
Page 211: Feature Activation
ST2030s VoIP Business Phone 4. A press “Join” to switch in conference mode. 5. Phone A shall send an INVITE to the Conference_Factory_URI. 6. It will retrieve the “conference ID” either in the 200 OK or the 302 Moved response. 7.
Page 212 ST2030s VoIP Business Phone C) Through APS: For this purpose, two new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the conference mode and the conference factory URI. [sip] ConferenceMode=2 ConferenceFactoryURI=conf The parameter “ConferenceFactoryURI”...
Page 213: Ylantro Sip-B
ST2030s VoIP Business Phone Sylantro SIP-B Correction of the known limitations and bug fixing of the Sylantro SIP-B provided in the release SG1.58. Please refer to the document “ST20XX SIP Sylantro SIP-B features.pdf“ for more Info. Identity Header Precedence This new feature specifies how the “source” for the caller/called party identity display, will be determined.
Page 214: Feature Activation
ST2030s VoIP Business Phone Different softswitch vendors use one or more of the different headers to provide information, and there is not a clear common criterion to all of them on the priority to be applied. Moreover, ST20xx phones have a local phonebook. Phonebook shall be always the 1st priority, but the header to look for in the phonebook will depend on the priority of the headers.
Page 215 ST2030s VoIP Business Phone To configure, open a command line console, and telnet the phone: C) Through APS: For this purpose, two new parameters have been included in the [sip] section of the Common/MAC config files, to be able to configure the priority. [sip] CLIPDisplayPrior=ppreferred(1)passerted(2)remoteparty(3)from(4) CalledDisplayPrior=dialed(1)passerted(2)remoteparty(3)
Page 216: Nat Keep Alive
Call-ID: 34ac-c0a80101-2-2@10.0.0.48 CSeq: 1 OPTIONS Max-Forwards: 70 Contact: <sip:2207@10.0.0.48:5060;user=phone> Accept: application/sdp User-Agent: THOMSON ST2030 hw5 fw1.61 00-14-7F-E1-81-F9 Content-Length: 0 Call flow example: Two parameters have been created: 1. The destination address for the SIP OPTIONS request. It could be either an SIP URI (or only the host part), an ip address or a domain name.
Page 217: Feature Activation
ST2030s VoIP Business Phone Examples: =server@domain.com KeppAliveDest =122.22.22.22 KeppAliveDest =domain.com KeppAliveDest 2. The time interval between 2 SIP OPTIONS requests. The value is in seconds and between 0 and 600. With 0 meaning disable sending Keep-Alive packets (default value). Examples: KeepAliveTimer =120 KeepAliveTimer...
Page 218 ST2030s VoIP Business Phone ST2030s SIP Administrator Guide v3.0 Page 210 of 308...
Page 219: Trusted Ip For Notify "Check-Sync
ST2030s VoIP Business Phone Trusted IP for Notify “check-sync” Up to now it was possible to send a SIP NOTIFY message to the phone, to launch remotely the automatic provisioning. Extract of the APS document "ST2030-ST2022 AutoProvisioning-V0030.doc" : To avoid attacks once the feature is enabled (as mentioned above), an additional parameter has been created to contain the authorized server from which the Notify is going to be allowed.
Page 220: Feature Activation
ST2030s VoIP Business Phone An example Call Flow: Feature Activation A) Through the WebGui: This feature can not be configured through the Web. B) Through Telnet: For this purpose, a new parameter has been created, described as follow: sip set auth_notify_sync_srv (Max 127 chars) To configure, open a command line console, and telnet the phone: C) Through APS: ST2030s SIP Administrator Guide v3.0...
Page 221: Reboot On Notify "Check-Sync; Reboot=True
ST2030s VoIP Business Phone For this purpose, a new parameter has been included in the [sip] section of the Common/MAC config files, to be able to configure the server. [sip] AuthNotifyCheckSync=10.0.0.1 Reboot on Notify “check-sync; reboot=true” In the implementation existing prior to this new version, when the phone received NTFY check-sync, it did not force reboot, but start APS procedure.
Page 222 ST2030s VoIP Business Phone An example Call Flow where the phone takes the APS configuration from the DHCP options would be: ST2030s SIP Administrator Guide v3.0 Page 214 of 308...
Page 223: Downloadable/Uploadable Local Phonebook
ST2030s VoIP Business Phone Downloadable/Uploadable Local Phonebook As requested by many customers, we have included the possibility to save, edit and load the local phonebook of the IP phone. This feature allows you (the user) to copy the local Phonebook directory from your ST2030 phone to your PC.
Page 224 ST2030s VoIP Business Phone And : B) Through Telnet: To configure, open a command line console, and telnet the phone: ST2030s SIP Administrator Guide v3.0 Page 216 of 308...
Page 225 ST2030s VoIP Business Phone ST2030s SIP Administrator Guide v3.0 Page 217 of 308...
Page 226: Mixed Paging Remote Phonebook
ST2030s VoIP Business Phone Mixed paging Remote Phonebook In the implementation prior to this sw version, ST20xx could accept 2 kinds of syntax in the XML reply from the server: 1- Less than 32 results to the query with directory entries: <ThomsonPhoneBook>...
Page 227 ST2030s VoIP Business Phone <DirectoryEntry> <Name>Marco, Tomás</Name> <Telephone>10022384</Telephone> </DirectoryEntry> <MenuItem> <Name>Next-Page...</Name> <URL>http://www.server.com/Paging.php?NAME=M&PAGE=2</URL> </MenuItem> </PhoneBook> In previous example, for “MenuItem” elements, the content of the tag “Name” would be literally shown on the screen, and when selected would launch the url contained in “URL” tag. As an alternative, an additional tag has been defined within “MenuItem”, in order to support keywords.
Page 228: Feature Activation
ST2030s VoIP Business Phone Keywords Norway Russian Portuguese Netherlands Neste Cледующий Seguinte Volgende next-page Tidligere Предыдущий Precedente Vorig previous- page Feature Activation Feature is activated by default, all you need is a remote phonebook using this structure. You can check this new feature by configuring the remote phonebook like this, and uploading to your http server the example provided with this release: An example of a normal Call Flow:...
Page 229: Login/Logout - Disable Subscribe To Dialog
ST2030s VoIP Business Phone Login/logout – disable Subscribe to dialog In the context of the Login/Logout feature, the phone subscribes to the Dialog Event before trying to register with a dynamic personal profile or static personal profile, to ensure any phone potentially registered with this profile is not in conversation or ringing).
Page 230: Feature Activation
ST2030s VoIP Business Phone Feature Activation A) Through the WebGui: This feature can not be configured through the Web. B) Through Telnet: For this purpose, a new parameter has been created, described as follow: sip set subdlgbflogin_flag [0(Disable)/ 1(Enable)] To configure, open a command line console, and telnet the phone: C) Through APS: For this purpose, a new parameter has been included in the [sip] section of the Common/MAC config files, to be able to configure the feature.
Page 231 ST2030s VoIP Business Phone [ipp] ManualLog=1 [sip] SubscribeDilaogBeforeLogin=0 A call flow for reference : ST2030s SIP Administrator Guide v3.0 Page 223 of 308...
Page 232: St20Xx Sip New Features (Sg Vx .59)
SIP data provided by this tool is shown split in headers and packet body as follows: Recv from udp: 10.0.0.5:5060 00:00:00:01:066 (937 bytes) INVITE sip:2205@10.0.0.55:5060 SIP/2.0 Via: SIP/2.0/UDP 10.0.0.5:5060;branch=z9hG4bK2b55f27f;rport From: "Thomson-2204" <sip:2204@10.0.0.5>;tag=as1b93c676 To: <sip:2205@10.0.0.55:5060> Contact: <sip:2204@10.0.0.5> Call-ID: 7b068be424cee3565279b5cb075e248b@10.0.0.5 CSeq: 102 INVITE User-Agent: Asterisk 1.4.11...
Page 233: Overview 224 Tracing Tool 224 Feature Activation
Password: 789234 [administrator]# sip tracer on [administrator]# [administrator]# Recv from udp: 10.0.0.5:5060 00:00:00:01:066 (937 bytes) INVITE sip:2205@10.0.0.55:5060 SIP/2.0 Via: SIP/2.0/UDP 10.0.0.5:5060;branch=z9hG4bK2b55f27f;rport From: "Thomson-2204" <sip:2204@10.0.0.5>;tag=as1b93c676 To: <sip:2205@10.0.0.55:5060> Contact: <sip:2204@10.0.0.5> Call-ID: 7b068be424cee3565279b5cb075e248b@10.0.0.5 CSeq: 102 INVITE User-Agent: Asterisk 1.4.11 Max-Forwards: 70 Remote-Party-ID: "Thomson-2204" <sip:2204@10.0.0.5>;privacy=off;screen=no...
Page 234 PCMU/8000 a=rtpmap:101 telephone-event/8000 a=fmtp:101 0-15 a=sendrecv Recv from udp: 10.0.0.5:5060 00:00:00:02:908 (445 bytes) ACK sip:2205@10.0.0.55:5060 SIP/2.0 Via: SIP/2.0/UDP 10.0.0.5:5060;branch=z9hG4bK6c7d8777;rport From: "Thomson-2204" <sip:2204@10.0.0.5>;tag=as1b93c676 To: <sip:2205@10.0.0.55:5060>;tag=c0a80101-79d86 Contact: <sip:2204@10.0.0.5> Call-ID: 7b068be424cee3565279b5cb075e248b@10.0.0.5 CSeq: 102 ACK User-Agent: Asterisk 1.4.11 Max-Forwards: 70 Remote-Party-ID: "Thomson-2204" <sip:2204@10.0.0.5>;privacy=off;screen=no Content-Length: 0 ST2030s SIP Administrator Guide v3.0...
Page 235: Download And Update Tone And Language Tables
ST2030s VoIP Business Phone Download and update tone and language tables Downloading and updating Tone table or Language table capability has been added to improve and enhance admin possibilities in terms of managing languages and tones of his/her phone/s. Phone provides 9 language tables (English, French, Spanish, German, Italian, Norway, Russian, Portuguese, Deutsch), and now, 1 more extra language...
Page 236: How To Modify The Templates
ST2030s VoIP Business Phone You can also do it through Telnet: For example, to get US : or, to get English : Finally we will have the Templates to create the new tables: How to modify the Templates: Tone/Language template files are “txt”...
Page 237 ST2030s VoIP Business Phone If you modify: <ThomsonToneTable> <Country-TableName>Spain 2</Country-TableName> <Busy> <Num-of-Element>2</Num-of-Element> </Busy> </ThomsonToneTable> this means the name of the extra tone table will be “Spain 2”. And: <ThomsonLanguageTable> <ProductName>ST2030(S)</ProductName> <Country>Czech</Country> <Charset>Latin-2</Charset> <ThomsonDisplayString> </ThomsonLanguageTable> means the name of the extra language table will be “Czech”. The new language table should be based on Latin-1, Latin-2, Cyrillic and Hebrew...
Page 238: How To Upload The Templates
ST2030s VoIP Business Phone  Num-of-Tones is up to 4,  Freq (frequency) is up to 3000Hz,  Amp is between -800 ~ +30 (*0.1 db),  Duration is up to 60000 seconds. 2. Language table limits - > Length limit - > refer to the limit of MMI display ...
Page 239 ST2030s VoIP Business Phone B) Through Telnet C) Through APS: File Syntax for TFTP APS:  [application] fw_filename=v2030SG.080227.1.59.3.zz [config] telcfg=TelConf2030SG_v1.59.3.txt common_config=ComConf2030SG_v1.59.3.txt melodies=Melodies.txt system_melodies=Sys_Ringtones.txt call_waiting_tone=Bellcore_CW.txt tone_table=ToneTable.txt language_table=LangTable.txt File Syntax for HTTP APS:  [application] fw_url=http://10.8.1.217/v2030SG.080227.1.59.3.zz [config] common_config=http://10.8.1.217/ComConf2030SG_v1.59.3.txt telcfg=http://10.8.1.217/TelConf2030SG_v1.59.3.txt melodies=http://10.8.1.217/Melodies.txt system_melodies=http://10.8.1.217/Sys_Ringtones.txt call_waiting_tone=http://10.8.1.217/ Bellcore_CW.txt tone_table=http://10.8.1.217/tonetable.txt language_table=http://10.8.1.217/langtable.txt config=http://10.8.1.217/...
Page 240: Feature Activation
ST2030s VoIP Business Phone Feature Activation Once the files have been uploaded, user can activate them by the following means: A) Through Keypad : Only Language table can be changed. Menu  Config  Personalize  Lang option  Edit  choose your own table and save. B) Through Telnet : Only Tone table can be changed: C) Through APS : ST2030s SIP Administrator Guide v3.0...
Page 241: St20Xx Sip New Features (Sg Vx.58.6)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.58.6) Overview This document describes a set of features included in ST2030 and S2022 SIP v1.58.6 and 3.58.6 respectively in order to improve their usability in different environments. SIP MESSAGE support (rfc 3428) for Status display applications More and more, services supported locally by the phone are also supported centrally by the IP PBX or softswitch (call forwarding, call rejection, call...
Page 242: Feature Activation
ST2030s VoIP Business Phone Feature Activation This feature does not need specific activation to be supported. But a parameter has been created to avoid messages attacks from non desired sources. Parameter is AuthMessageServer. Default value is 0.0.0.0, which means phone accepts all messages received from everywhere. Otherwise, to limit from which server messages can be accepted, this parameter should contain either SIP messages server IP address or domain name.
Page 243: Soft Keys Reordering
ST2030s VoIP Business Phone Soft keys reordering Up to now, the soft keys position was fixed. If you removed a soft key (by web GUI or APS), its position remained empty. So you could have 2 soft keys on the first page, another one on the second… In order to avoid this situation, soft key reordering is possible since this version.
Page 244: Early Media Type Parameter
ST2030s VoIP Business Phone softkey03=PickUp softkey04=LockPhone softkey05=VoiceMail softkey06=RetrievePark softkey07=DNDstate softkey08=ShortCut1 softkey09=ShortCut2 softkey10=ACDCheckIn softkey11=ACDAvailable softkey12=Login Defined soft keys location is displayed on MMI screen as follow: Date Hour Icons Phone Name Phone Number < > Softkey1 Softkey2 Softkey3 < > Softkey4 Softkey5 Softkey6 <...
Page 245 ST2030s VoIP Business Phone Default value is 0. That means phone will switch to local ring tone if it receives a 180 Ringing (no sdp) response, regardless if an RTP stream corresponding to the early media session is present. Setting Earlymediatype parameter to 1, phone will continue playing RTP stream corresponding to the early media session even if a 180 Ringing (no sdp) response is received.
Page 246: St2030 Sip New Features (Sg V1.56)
ST2030s VoIP Business Phone ST2030 SIP New Features (SG v1.56) Overview This document describes a set of features included in ST2030 SIP v1.56 in order to improve its usability in different environments. Login/Logout Login/Logout feature allows the user to register easily with his own parameters (username and password) on any ST2030S or ST2022S in a location.
Page 247 ST2030s VoIP Business Phone Feature activation This feature can be cofigured via APS setting to 1 ManualLog parameter and adding the user part of the registration events server uri in RegEventServer parameter in common or MAC file: [ipp] ManualLog=1 [sip] RegEventServer=MyRegEventServer Or via Web GUI in section “Advanced | Voice Settings | Advanced”...
Page 248: Broadsoft Shared Call Appearance
ST2030s VoIP Business Phone Broadsoft Shared Call Appearance This new feature makes the phone compatible with Broadsoft Shared Call Appearance facility. This function allows several users to share a phone number (the one in the active SIP profile), so that they can receive the same calls, make a call from the same number, unhold a previously held call, or even conference.
Page 249 ST2030s VoIP Business Phone Or by APS in [sip] section of both Common or Specific-MAC config files with the new parameter SharedCallAppearance (0 by default, inactive; 1 to active): [sip] SharedCallAppearance=1 The rest of the configuration will be done by your BroadSoft accounts administrator.
Page 250: St20Xx Sip New Features (Sg Vx.54.2)
ST2030s VoIP Business Phone ST20XX SIP New Features (SG vx.54.2) Overview This document describes a set of features included in both ST2030 SIP v1.54.2 and ST2022 SIP v3.54.2 in order to improve its usability in different environments. Automatic Hang Up This new feature allows the phone to hang up automatically, stopping the audio output (regardless it‟s from speaker, headset or handset) and turning...
Page 251: Call Park Type
ST2030s VoIP Business Phone Or by the Autoprovisioning with the parameter AutoHangUp in the [ipp] section of APS config files (both Common or specifi-MAC): [ipp] … AutoHangUpTimer = 3 … In both cases, via Web and via Autoprovisioning, the behaviour is the same. User introduces the number of seconds he wants the phone to wait (after the BYE) for hanging up;...
Page 252: Call Park/Retrieve Park Implementation Modes
ST2030s VoIP Business Phone Call Park/Retrieve Park implementation modes Both modes requires a proper enviroment that supports Call Park. Mode 0: Call park is achieved by st20xx sending a REFER message to the park extension with - Request-URI: the park extension - Refer-to: the party which is going to be parked - Replaces (param inside Refer-to header): dialog between parked and the one who parks.
Page 253: Aps Upgrade Between Sip And Mgcp
ST2030s VoIP Business Phone APS upgrade between SIP and MGCP This new feature allows a particular st20xx be used for both SIP and MGCP enviroments toggling application via a simple APS upgrade. Process and Requirements As this compatibility between SIP and MGCP st20xx phones is new, admin has to make sure that his/her phone is using approppriate versions of boot, dsp and application firmware.
Page 254: Feature Activation
ST2030s VoIP Business Phone Feature activation This is always active; it‟s a new behaviour rather than a feature. Just pressing the volume keys when headset is active will adjust the volume for the rest of the current call and for the nexts, also the ringer volume, until next change.
Page 255: St20Xx Sip New Features (Sgx.53)
ST2030s VoIP Business Phone ST20XX SIP New Features (SGx.53) Overview This document describes a set of features included in both ST2030 SIP v1.53 and ST2022 SIP v3.53 in order to improve its usability in different environments. Call-info header with Answer-after parameter...
Page 256: Network Conference
ST2030s VoIP Business Phone Network Conference This is not exactly a new feature but it‟s a new way of supporting traditional Conference (called Local Conference from now on). Network conference allows the phone to be interoperable with servers that are able (an prefer) to carry out the conference by theirselves. Feature activation This feature can be configured via web with a new flag: or by the APS files with a new parameter in Config Files (either common.txt...
Page 257: Configurable Refer-To Header Population
ST2030s VoIP Business Phone … After that, when initiating a Conference (by Conf or Join softkeys, same as traditional Local Conference) the phone just have to send a NOTIFY (event: conference) containing in its Refer-to header, location info of the 3rd, 4th, 5th…...
Page 258: Check Phonebook Domain Name
ST2030s VoIP Business Phone In APS config files (common and mac ) this issue will be configured using the parameter TransferUseContact=1 (flag ON) or 0 (flag OFF ) Which is placed in [sip] section and set to 1 by default Check phonebook Domain name For users who use to registered the phone in different accounts, with different servers or at least domain names, this can be use to get more...
Page 259: Phonebook Entries Recognition
ST2030s VoIP Business Phone Or by APS, with a new parameter Check_phonebook_domain_name=1 (or 0 to deactivate) included in config files (common or MAC). Exactly in [ipp] section and having 1 as default value Phonebook entries recognition Behaviour of the phone related to this option can be resumed in this points (points 3 and 4 are interesting but independent of this new flag): 1.- Call from/to 1234(@my_domain) will be recognised by phone as phonebook entry 1234@any_domain, showing its assigned name<=>Flag...
Page 260: Aps Improvement
ST2030s VoIP Business Phone APS improvement TelConf file will only be downloaded if its name has changed from the previous downloaded one. Changes in APS are deeply explained in several documents in APS&FW upgrade of this Release package. Talk and hold event packages for click-to-answer and other 3PCC scenarios This extension provides the ability for an Application Server to send an asynchronous NOTIFY event to our phone, using an existing INVITE dialog.
Page 261: Persistent Vlan
ST2030s VoIP Business Phone Persistent VLAN This is an improvement in VLAN configuration via DHCP. This is deeply explained in VLAN provisioning via DHCP.pdf placed in the same folder as this. ST2030s SIP Administrator Guide v3.0 Page 253 of 308...
Page 262: St2030 Sip New Features (Sg1.52.1)
ST2030s VoIP Business Phone ST2030 SIP New Features (SG1.52.1) Overview This document describes a set of features included in ST2030 SIP v1.52.1 in order to improve its usability in different environments. List-oriented BLF The purpose of this feature is to supervise other phones as is the case of standard BLF (from now on, referred to as User-Based BLF).
Page 263 ST2030s VoIP Business Phone Select “List-oriented BLF”, and configure the List-uri to which the phone should subscribe, in accordance with your server configuration. Parameter “Start Spare Fk” indicates the first function key which will be dynamically provisioned. This parameter, by default, is automatically set to Multiline+1.
Page 264: Keyword Definition And Usage
BLF, then you need not change this parameter. Example: [sys] BLFType=1 BLFListSipUri=L/<sip:List-URI@thomson.net> Current_Max_Multiline=4 StartSpareFK=6 With this parameters, List-oriented BLF is enabled, the List Uri is List- URI@thomson.net and the first key to be provisioned is F6 ST2030s SIP Administrator Guide v3.0 Page 256 of 308...
Page 265: User Class Identifier
The content delivered by ST2030 within this option depends on the protocol loaded. Hence it will be “Thomson ST2030S” or “Thomson ST2030M” As an example, this is what would be seen with a packet sniffer with an SG version Feature activation ST2030s SIP Administrator Guide v3.0...
Page 266: Additional Softkey Control
ST2030s VoIP Business Phone This feature is always active and does not need any configuration. Additional Softkey Control The purpose of this feature is being able to deactivate/activate “Transfer to voice mail” and “Pick up” soft keys, to accomodate to environments in which these features are not supported.
Page 267: Keyword Definition And Usage
ST2030s VoIP Business Phone Keyword definition and usage The parameters governing this feature, included in the [ipp] section, are: Transfer_to_voice_mail Values : 0 or 1 Meaning : 0 : Transfer to Voicemail softkey will not appear on phone screen 1 : Transfer to Voicemail softkey will appear on phone screen Default: default value is “1”...
Page 268: Call Progress Indication Control
ST2030s VoIP Business Phone Call Progress Indication Control For environments in which early media is provided, e.g. to convey network progress tones, the status information shown on the display of the phone may in some cases result confusing. For example, when you receive a busy tone via early media, and the phone shows “Ringing”, according to its call progress status.
Page 269: Phone Number Display In Idle Mode Control
ST2030s VoIP Business Phone Phone Number Display in Idle Mode Control ST2030 idle screen shows both display name and user part of the sip uri in the active account (phone number). In some systems, however, the phone number has some additional characters like MAC address, for example, which makes the screen look unfriendly to users.
Page 270: St2030 Sip New Features (Seg1.50T3)
ST2030s VoIP Business Phone ST2030 SIP New Features (SEG1.50t3) Overview This document describes a set of features included in ST2030 SIP in order to improve its usability in different environments. Automatic call when offhook The purpose of this feature is to allow the user to call a number that is pre- registered in the phone.
Page 271: Hide Missed Calls Flag
ST2030s VoIP Business Phone Hide Missed Calls flag The purpose of this feature is being able to deactivate/activate Missed Calls message display on the phone screeen. This will have mainly interest within the framework of call centres in which calls are sent to all Agents and only picked up by one of them, whereas it is not desirable to have all other phones of the group announcing a missed call.
Page 272: Autoanswer Device Routing
ST2030s VoIP Business Phone Autoanswer device routing The purpose of this feature is being able to select which audio devices will be activated when Autoanswer feature is enabled. In previous versions, default device was handsfree speaker/mic. In Call Centre environments it makes more sense to use headset for this purpose. Feature activation Web GUI or APS are currently used to control this feature.
Page 273: Keyword Definition And Usage
ST2030s VoIP Business Phone Keyword definition and usage The parameter governing this feature, included in the [ipp] section, is: AutoAnsMode Values : 0 or 1 Meaning : 0 : Autoanswered call routed to handsfree 1 : Autoanswered call routed to headset Example: [ipp] AutoAnsMode=1...
Page 274: Daylight Saving Refinements
ST2030s VoIP Business Phone Daylight saving refinements In previous ST2030 versions, parameter NtpDaylight exists in order to allow the telephone to automatically switch to summer-time. But some states in some countries have a particular and varying switching time which makes it difficult to handle internally on a global basis. In order to overcome this problem, a new value for the existing parameter is created.
Page 275: Keyword Definition And Usage
ST2030s VoIP Business Phone Keyword definition and usage The parameter governing this feature, included in the [ntp] section, is: NtpDaylight Values : 0, 1 or 2 Meaning : 0 : NTP time unchanged 1 : Automatic Daylight saving applied to NTP time 2 : NTP +1 Example : [ntp]...
Page 276: Information Shortcut -"Menu " Long Press
ST2030s VoIP Business Phone Example : [ntp] NTPFlag=1 NtpIP=192.43.244.18 NtpDaylight=1 NtpMode=0 NtpZoneNum=50 NtpSyncTime=1 Information shortcut-“Menu” long press The purpose of this feature is to facilitate Support tasks, by granting fast access to basic phone information: HW and FW version, MAC and IP address, This information was already provided by pressing UserInformation Now, access to this submenu is also available by long pressing “Menu”...
Page 277: St2030 Sip Monitoring Extension Feature (Blf) V1.47
1 SUBSCRIBE/NOTIFY support for monitoring extension states- Overview The objective of this document is to present the way ST2030 SIP uses backlit function keys to monitor the state of other extensions. The backlit function keys will indicate if an extension is idle, in use, or ringing. This feature is known as BLF or Monitoring Extension function.
Page 278: Blf Configuration
ST2030s VoIP Business Phone The "<state>early|confirmed|void</state>" in the received NOTIFY msgs determines the LEDs activity. • If the line on the extension rings, the programmable key LED on the phone blinks. Related state is early. • If the line on the extension is busy, the programmable key LED on the phone is steadily lit.
Page 279 ST2030s VoIP Business Phone To configure the function keys, visit Advanced  Call features and click on Function keys: ST2030s SIP Administrator Guide v3.0 Page 271 of 308...
Page 280 ST2030s VoIP Business Phone The feature keys are split in 3 pages: F1 to F10 F11 to F38 (1st extension module, will only appear if the module is detected) F39 to F66 (2nd extension module, will only appear if the module is detected) On each page, the feature keys are detailed in a list.
Page 281: Examples With Asterisk Sip Server As Notifier
ST2030s VoIP Business Phone FeatureKeyExt01=L/<sip:2345@domain1.com> FeatureKeyExt02=L/<sip:3455> FeatureKeyExt03=L/<sip:number@domain2.com> FeatureKeyExt04=L/<sip:> FeatureKeyExt05=L/<sip:> FeatureKeyExt06=S/<sip:346666666> FeatureKeyExt07=S/<sip:345455555@mydomain.com> 4 Examples with Asterisk SIP server as notifier -------------------------------------------------------------------------------- Sent to udp:10.0.0.5:5060 at 19/10/2005 12:26:20:770 (425 bytes): #With this message 2200@lan subscribes to the state of 2205. The message will be forwarded to 2205 or not depending on Proxy capabilities SUBSCRIBE sip:2205@lan.net;user=phone SIP/2.0 Via: SIP/2.0/UDP 10.0.0.1:2051;branch=z9hG4bK-wkwhbwu19wgc;rport...
Page 282 ST2030s VoIP Business Phone entity="sip:2205@lan.net"></dialog-info> -------------------------------------------------------------------------------- ..The UA 2200@lan should send the 200 OK to the NOTIFY above ..-------------------------------------------------------------------------------- -------------------------------------------------------------------------------- Received from udp:10.0.0.5:5060 at 19/10/2005 12:35:57:430 (930 bytes): #This make the led FLASH NOTIFY sip:2200@10.0.0.1:2051;line=xjqldyhz SIP/2.0 Via: SIP/2.0/UDP 10.0.0.5:5060;branch=z9hG4bK- a566a0acd02fdaf578d455bc48614953 Page 6 de 9 From: <sip:2205@lan.net;user=phone>tag=6sam28oefu...
Page 283 ST2030s VoIP Business Phone Content-Length: 504 <?xml version="1.0"?> <dialog-info xmlns="urn:ietf:params:xml:ns:dialog-info" version="20" state="full" + entity="sip:2205@lan.net"><dialog id="dummy" call-id="feb21493- d84a9bd6@192.168.0.113" + local-tag="6yln5cag4d" remote-tag="fe9c856f35980aao0" + direction="recipient"><state>confirmed</state> + <local><identity>sip:2205@lan.net</identity><target uri="sip:2205@lan.net"/> + </local><remote><identity>sip:22052@lan.net</identity><target + uri="sip:22052@lan.net"/></remote></dialog></dialog-info> + -------------------------------------------------------------------------------- ..The UA 2200@lan should send the 200 OK to the NOTIFY above ..-------------------------------------------------------------------------------- -------------------------------------------------------------------------------- Received from udp:10.0.0.5:5060 at 19/10/2005 12:36:04:050 (580 bytes):...
Page 284: St2030 Sip Distinctive Ringing And Cwt Using
INVITE requests for distinctive ringing and distinctive CWT (Call waiting tone) features. 2. <Alert-Info> Header and Ringing management This chapter specifies how the ST2030 SIP handles the <Alert-Info> header and parameters in SIP when the phone is in idle state, i.e., no other call is currently active.

Page 285: Alert-Info> Header And Call Waiting Tones Management
3. <Alert-Info> Header and Call Waiting Tones management This chapter specifies how the ST2030 SIP handles the <Alert-Info> header and parameters in SIP when the phone has already an active call. In this case, the header will determine which Call Waiting tone will be played.
Page 286 ST2030s VoIP Business Phone APS: file names can be included in the information file (*.inf) within the parameters: system_melodies= call_waiting_tone= in [config] section. Please check ST2030-AutoProvisioning-V0026.pdf for details. Some examples of melodies and call waiting tones, and their usage within an .inf file can be found in this release package, “APS sample files” folder.
Page 287: Part 10 - Remote Phonebook Specification
The aim of this service is to provide an easy access to the company's phonebook through the Thomson ST2030 Phone. The final user enters the name of the person he wishes to call on the telephone, using the DTMF keys. The telephone then consults an external server (using HTTP/XML), and displays the entries that matches the name entered.
Page 288: Phone Query
ST2030s VoIP Business Phone HTTP:: GET Identification Company Query Results HTTP:XML 2.2 Phone query The ST2030 is able to send several parameters to the server in the GET request: Parameter Description IP address of the phone #MAC MAC address of the phone The string to search (most likely the first #SEARCH letters of the last name of the person we want...
Page 289: Answer To The Request From The Server
ST2030s VoIP Business Phone <Name> </Name> <Telephone> </Telephone> See following paragraphs for some examples. 2.4 Answer to the request from the server 2.4.1 No answers If the server doesn‟t find any answers to the result of the query, it will send back to the phone this XML page: [ThomsonPhoneBook XML page] <ThomsonPhoneBook>...
Page 290: Less Than 32 Results To The Query
ST2030s VoIP Business Phone 2.4.2 Less than 32 results to the query If the server finds less than 32 answers to the query, it should send to the telephone this kind of XML page: [ThomsonPhoneBook XML page] <ThomsonPhoneBook> <DirectoryEntry> <Name>Dupad André</Name> <Telephone>0175008348</Telephone>...
Page 291: St2030 Phone Specifications
3. ST2030 Phone Specifications 3.1 Presentation The Thomson ST2030 will be able to send the queries to the HTTP server, and display the XML pages sent back from the server, and enable the user to navigate in simple menus, in order to select an entry, view the number, and call the contact.
Page 292: Accessing The Phonebooks
The user is able to browse in the list of phonebooks using the up and down keys, and select one of them using a softkey or the OK button. He is of course also able to cancel his search. > Thomson Telecom <...
Page 293: Incoming Call During Search
ST2030s VoIP Business Phone 3.6 Incoming call during search If the phone receives an incoming call anytime during the search, the search is cancelled and the phone shows up the call, in the same way as if it was in IDLE mode before the call arrives. 3.7 Displaying empty phonebook If no results are found, the phone will receive an empty ThomsonPhoneBook XML page.
Page 294: Displaying An Entry In The Phonebook
ST2030s VoIP Business Phone will be able to browse in the list of URLs using the up and down keys, and select one of them using a softkey or the OK button. > Abbot  Lennox < McNamara Nemo Obi Wan  Rufus Sade ...
Page 295: Part 11 Telnet Activation
ST2030s VoIP Business Phone Part 11 Telnet Activation Introduction This part reviews and summarizes ST20xx Telnet commands useful for remote management of the phone. Other commands (like configuration of the phone‟s parameters) are described in another Technical document: “Syntax of ST20xx Configuration file”. It is issued in the firmware release package.
Page 296: Open A Telnet Session
ST2030s VoIP Business Phone Then check off the Telnet Server to activate it. Open a Telnet session In Windows OS: Click on “Start” , select “Execute”, type “cmd” then press “Enter” In the CMD window, type “telnet <ip address>” Enter the usename and password: Login (default): administrator Password (default): 789234 ST2030s SIP Administrator Guide v3.0...
Page 297: Telnet Commands
ST2030s VoIP Business Phone Telnet commands The table below, lists the telnet commands mainly focused on the remote management. Command Descriptions Examples Tftp Upgrade Firmware [administrator]# tftp 192.168.1.3 tftp X.X.X.X filename [f/F] v2030SG.080619.1.62.3.zz [TFTP server should be ready and select the corresponding directory] Tftp2 Upgrade a number of defined...
Page 298: Reset To Default
ST2030s VoIP Business Phone tftp2 putfile X.X.X.X filename [f/F] [TFTP server should be ready and select the corresponding directory] Reboot Trigger phone reboot [administrator]# Reboot now Activate Enable services [administrator]# Activate Commit Save settings [administrator]# commit Version Show boot, dsp and FW version [administrator]# Version Info Show phone info...
Page 299: Part 12 Troubleshooting
ST2030s VoIP Business Phone Part 12 Troubleshooting If your phone is not operating as it should, please refer to the list of the problems in the following table. It should help you to solve the issue. Possible cause Remedy Problem No dialing tone No connection to the Ensure that the Ethernet cable is...
Page 300: Part 13 Appendix
ST2030s VoIP Business Phone Part 13 Appendix Configuration and Commands Table 9.1 lists a minimum set of configurable parameters and commands. Parameters shall be configurable either via the auto-provisioning process, via the web-page, or via LCD menu. The Administrator will have access to all parameters, either via the web-page or LCD menu.
Page 301 ST2030s VoIP Business Phone Configuration Administrator Name administrator 6 Digits Administrator Password 784518 User Name user 4 Digits User Password blank Command Reset to factory defaults Save (upload) configuration on Command server Saves all parameters Protocol stacks Signalling port for sending signalling packets 2427 port for receiving signalling packets 2427...
Page 302: Examples Of Files To Configure Auto Provisioning Via Tftp
ST2030s VoIP Business Phone Examples of files to configure auto provisioning via TFTP Example of file INF SIP: [provision_mode] provision_mode=auto_provisioning [application] fw_filename=st2030SEG_fw.zz dsp_filename=v2030_dsp_ver_.zz boot_filename =v2030_boot_ver.zz [config] telcfg=TelConf2030SEG_telcfg.txt common_config=st2030s_common.txt melodies=Melodies.txt system_melodies=S_Melodies.txt call_waiting_tone=ringtone.txt tone_table=ToneTb.txt language_table=langtable.txt Example of file INF MGCP: [provision_mode] provision_mode=auto_provisioning [application] fw_filename=v2030MEC_fw.zz dsp_filename=v2030_dsp_ver_.zz...
Page 303 ST2030s VoIP Business Phone common_config=st2030m_common.txt melodies=Melodies.txt system_melodies=S_Melodies.txt call_waiting_tone=ringtone.txt beep_tone=beeptone.txt Example of file Common_config SIP: [ipp] AutoAnsMode=0 AutoAnsTimer=0 Autocall=0 AutocallNumber= AutoRejectTimer=0 AutoStopTimer=0 AutoHangUpTimer=3 CaLogPrefix= Check_phonebook_domain_name=1 Disable_call_progress=0 Hide_Phone_Number_Display=0 HideMissedCall=0 LanguageType=0 LocalMusicOnHold=1 ManualLog=0 OptionVisible=8191 PasswordString=0000 PhoneLock=0 Pick_up_call=1 Ringer_default_vol=4 Ringer_lock=0 RingToneMP1=0 RingToneMP2=0 RingToneMP3=0 RingToneMP4=0 Suppress-DomainName-Flag=1 Transfer_to_voice_mail=1 TransfOnRingFlag=0...
Page 304 ST2030s VoIP Business Phone TelnetSrv=1 VLAN=0 WanModFlag=1 [pstn] [sip] ACD=0 AuthMessageServer=0.0.0.0 KeppAliveDest=0.0.0.0 KeepAliveTimer=0 AuthNotifyCheckSync=0.0.0.0 CallBlockType=0 CF_Address1= CFNA_Time1=30 CF_domain= ConnectReuseFlgMP1=0 ConnectReuseFlgMP2=0 ConnectReuseFlgMP3=0 ConnectReuseFlgMP4=0 ConnectReuseFlgBK1=0 ConnectReuseFlgBK2=0 ConnectReuseFlgBK3=0 ConnectReuseFlgBK4=0 ConferenceMode=0 ConferenceFactoryURI=conf CallParkType=0 CLIPDisplayPrior=ppreferred(1)passerted(2)remoteparty(3)from(4) CalledDisplayPrior=dialed(1)passerted(2)remoteparty(3) CallPkupFlg=local CallPkupSC= CallFwdFlg=local CallFwdOffSC= CallFwdAlwaysSC= CallFwdBusySC= CallFwdNoAnswerSC= CallParkFlg=local CallParkSC= CallRetreiveSC= CallBlockFlg=local CallBlockAllowSC=...
Page 305 ST2030s VoIP Business Phone CFUOnSV= CFUOffSV= DisplayNumFlag1=0 DisplayNumFlag2=0 DisplayNumFlag3=0 DisplayNumFlag4=0 DisplayNum1= DisplayNum2= DisplayNum3= DisplayNum4= DNDFlg=local DNDOnSC= DNDOffSC= DNDOnSV= DNDOffSV= DNDResp=1 DisplayName1= DisplayName2= DisplayName3= DisplayName4= DisplayNameFlag1=0 DisplayNameFlag2=0 DisplayNameFlag3=0 DisplayNameFlag4=0 DiversionHeaderFlag=0 ExpireTimeMP1=3600 ExpireTimeMP2=3600 ExpireTimeMP3=3600 ExpireTimeMP4=3600 ExpireTimeBK1=3600 ExpireTimeBK2=3600 ExpireTimeBK3=3600 ExpireTimeBK4=3600 Earlymediatype=0 HGOnSC= HGOffSC= HGOnSV= HGOffSV= MissedCallSummary=0...
Page 306 ST2030s VoIP Business Phone ProxyServerBK2= ProxyServerBK3= ProxyServerBK4= P-AssertedIDforCallee=0 regid1= regid2= regid3= regid4= regpwd1= regpwd2= regpwd3= regpwd4= RegisterServerMP1= RegisterServerMP2= RegisterServerMP3= RegisterServerMP4= RegisterServerBK1= RegisterServerBK2= RegisterServerBK3= RegisterServerBK4= RtpPort=41000 ReTransTimer1=500 ReTransTimer2=4 RegisterFrequencyMP1=600 RegisterFrequencyMP2=600 RegisterFrequencyMP3=600 RegisterFrequencyMP4=600 RegisterFrequencyBK1=600 RegisterFrequencyBK2=600 RegisterFrequencyBK3=600 RegisterFrequencyBK4=600 REQ_RUI_with_port=1 RFC2833=1 RFC2833_rtp_pltype=96 RFC3262=0 RandomCSeqFlag=0 SubscribeDilaogBeforeLogin=1 RandomRTPPortFlag=0 RegEventServer=...
Page 307 ST2030s VoIP Business Phone sip_portMP2=5060 sip_portMP3=5060 sip_portMP4=5060 sip_portBK1=5060 sip_portBK2=5060 sip_portBK3=5060 sip_portBK4=5060 sip_reg_srv_portMP1=5060 sip_reg_srv_portMP2=5060 sip_reg_srv_portMP3=5060 sip_reg_srv_portMP4=5060 sip_reg_srv_portBK1=5060 sip_reg_srv_portBK2=5060 sip_reg_srv_portBK3=5060 sip_reg_srv_portBK4=5060 sip_pxy_srv_portMP1=5060 sip_pxy_srv_portMP2=5060 sip_pxy_srv_portMP3=5060 sip_pxy_srv_portMP4=5060 sip_pxy_srv_portBK1=5060 sip_pxy_srv_portBK2=5060 sip_pxy_srv_portBK3=5060 sip_pxy_srv_portBK4=5060 SubscriptionExpire=3600 SubscriptionExpireCB=60 SharedCallAppearance=0 SCAMainLinePrivate=0 Specific_IP_flag=0 HeaderCompact=0 subscribe_event=0 sw_anon_reject=0 sw_CF=0 sw_CFA=0 sw_CFNA=0 sw_CFB=0 sw_not_disturb=0 sw_call_park=0 sw_notify_autoprovision=0 sw_tr_vmail_address1=...
Page 308 ST2030s VoIP Business Phone TrVoiceMailFlg2=local TrVoiceMailFlg3=local TrVoiceMailFlg4=local TrVoiceMailOnSC0= TrVoiceMailOnSC1= TrVoiceMailOnSC2= TrVoiceMailOnSC3= TrVoiceMailOnSC4= TrVoiceMailOffSC0= TrVoiceMailOffSC1= TrVoiceMailOffSC2= TrVoiceMailOffSC3= TrVoiceMailOffSC4= TrVoiceMailRingSC0= TrVoiceMailRingSC1= TrVoiceMailRingSC2= TrVoiceMailRingSC3= TrVoiceMailRingSC4= TEL1Number= TEL2Number= TEL3Number= TEL4Number= TransportFlgMP1=0 TransportFlgMP2=0 TransportFlgMP3=0 TransportFlgMP4=0 TransportFlgBK1=0 TransportFlgBK2=0 TransportFlgBK3=0 TransportFlgBK4=0 TransferUseContact=1 URLTypeMP1=0 URLTypeMP2=0 URLTypeMP3=0 URLTypeMP4=0 URLTypeBK1=0 URLTypeBK2=0 URLTypeBK3=0 URLTypeBK4=0...
Page 309 ST2030s VoIP Business Phone [snmp] commRW1=0 commRW2=0 commRW3=0 flag=1 filter=0 snmpManager1=0.0.0.0 snmpManager2=0.0.0.0 snmpManager3=0.0.0.0 snmpManager4=0.0.0.0 snmpManager5=0.0.0.0 sysTrapSrv=0.0.0.0 sysCommName1=public sysCommName2= sysCommName3= sysContact=Thomson sysDescr=Thomson IP Phone sysLocation=France sysName=ST2030 SIP TrapLevel=0 [sys] 2833_volume=0 AEC=1 BLFType=0 BLFListSipUri=L/<sip:> CountryCode=US config_sn=200402190001 Current_Max_Multiline=10 CodecJitterBufMult=g711a(1/2/4)g711mu(1/2/4)g729(1/2/4)g723(1/2/4) CodecPktime=g711a(10)g711mu(10)g729(10)g723(30) CodecAdaptivePlayout=g711a(1)g711mu(1)g729(1)g723(1) DisableCWtone=0 Dialednum_timeout=4...
Page 310 ST2030s VoIP Business Phone FeatureKeyExt14=L/<sip:> FeatureKeyExt15=L/<sip:> FeatureKeyExt16=L/<sip:> FeatureKeyExt17=L/<sip:> FeatureKeyExt18=L/<sip:> FeatureKeyExt19=L/<sip:> FeatureKeyExt20=L/<sip:> FeatureKeyExt21=L/<sip:> FeatureKeyExt22=L/<sip:> FeatureKeyExt23=L/<sip:> FeatureKeyExt24=L/<sip:> FeatureKeyExt25=L/<sip:> FeatureKeyExt26=L/<sip:> FeatureKeyExt27=L/<sip:> FeatureKeyExt28=L/<sip:> FeatureKeyExt29=L/<sip:> FeatureKeyExt30=L/<sip:> FeatureKeyExt31=L/<sip:> FeatureKeyExt32=L/<sip:> FeatureKeyExt33=L/<sip:> FeatureKeyExt34=L/<sip:> FeatureKeyExt35=L/<sip:> FeatureKeyExt36=L/<sip:> FeatureKeyExt37=L/<sip:> FeatureKeyExt38=L/<sip:> FeatureKeyExt39=L/<sip:> FeatureKeyExt40=L/<sip:> FeatureKeyExt41=L/<sip:> FeatureKeyExt42=L/<sip:> FeatureKeyExt43=L/<sip:> FeatureKeyExt44=L/<sip:> FeatureKeyExt45=L/<sip:> FeatureKeyExt46=L/<sip:> FeatureKeyExt47=L/<sip:> FeatureKeyExt48=L/<sip:> FeatureKeyExt49=L/<sip:> FeatureKeyExt50=L/<sip:>...
Page 311 ST2030s VoIP Business Phone FeatureKeyExt66=L/<sip:> FeatureKeyOpt01=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt02=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt03=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt04=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt05=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt06=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt07=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt08=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt09=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt10=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt11=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt12=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt13=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt14=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt15=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt16=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt17=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt18=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt19=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt20=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt21=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt22=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt23=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt24=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt25=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt26=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt27=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt28=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt29=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt30=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt31=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt32=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt33=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt34=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt35=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt36=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt37=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt38=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0))
Page 312 ST2030s VoIP Business Phone FeatureKeyOpt52=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt53=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt54=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt55=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt56=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt57=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt58=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt59=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt60=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt61=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt62=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt63=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt64=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt65=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) FeatureKeyOpt66=dialog(1)regDND(0)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0)) NormalDigitFlag=1 PCallLogURL= PSettingURLdl= PSettingURLul= Phonebook1_url= Phonebook2_url= Phonebook3_url= Phonebook4_url= Phonebook5_url= Phonebook6_url= Phonebook7_url= Phonebook8_url= Phonebook1_name= Phonebook2_name= Phonebook3_name= Phonebook4_name= Phonebook5_name= Phonebook6_name= Phonebook7_name= Phonebook8_name= PBXconfiguration=0 PBXprefix= softkey01=TrVoiceMail softkey02=CallLog...
Page 313 ST2030s VoIP Business Phone SuppressRTCP=0 TelnetID=administrator TelnetPWD=789234 UserID=user UserPWD= VOIPDialPlan=x.T WebPWD=784518 [autoprovision] AutoprovisionFlag=1 AutoprovisionHTTPServer= AutoprovisionTFTPServer= AutoprovisionTimeDays=0 Autoprovisionstarttime=00:00 AutoprovisionTimeSpan=0 AutoprovisionRetryPeriod=30 [qos] DHCPVLANid1=1 DHCPVLANid2=1 DSCP1=46 DSCP2=40 DSCPdata=40 TOS=160 VLANid1=1 VLANid2=1 VLANTag1=6 VLANTagdata=6 [ftp] FTPID= FTPPWD= [ntp] NtpDaylight=1 NTPFlag=0 NtpIP= NtpMode=0 NtpSyncTime=1 NtpZoneNum=23 [pppoe] PPPoEID= PPPoELCPMod=2...
Page 314 ST2030s VoIP Business Phone STUNFlag=0 [upnp] UPnPFlag=1 [customer] sw_call_wait=1 Example of file Common_config MGCP: [ipp] LanguageType=0 [mgcp] ActivatedCAProfile=0 caip1=ca@[217.66.118.137]:2427 caip2=ca@[217.66.118.137]:2427 caip3=ca@[217.66.118.137]:2427 caip4=ca@[217.66.118.137]:2427 nat_keep=1 nat_keep_timeout=90 rgw=218.97.191.86 rgw_use_ip_addr=0 [net] DNSSrv1=202.96.209.5 DNSSrv2=168.95.1.1 DSCPflag=0 ESWITCH_LAN=1 Gateway=218.97.191.81 ipwan=218.97.191.86 MaskWan=255.255.255.240 TelnetSrv=0 VLAN=0 WanModFlag=0 [sys] CountryCode=FR Phonebook1_url= Phonebook1_name= TelnetID=administrator TelnetPWD=789234...
Page 315 ST2030s VoIP Business Phone NTPFlag=1 NtpIP=192.43.244.18 NtpZoneNum=0 Example of file TelConf: (Don’t touch) Not recommended to change. Specific file MAC: The content is the same as common_config file, except the parameter “config_sn=xxxxxxxxxxxx”, which need to be changed for each APS update. Files Deck: (only MGCP) Until version 1.61.4 (11 files): MC.080620.abrege.thd...
Page 316: Part 14 Figures & Tables
ST2030s VoIP Business Phone Part 14 Figures & Tables IP P ............. 2 IGURE HONE ABLE ONNECTIONS IP P ..............10 IGURE HONE SER PANEL IP P ............12 ABLE HONE PHYSICAL FEATURES ..............15 ABLE EFINITIONS OF SOFT KEYS LED ................
