Support for disks
- MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,Mp3,Mp4
Karaoke support various functions
-
Function of presetting the song and helps to preset 99 songs.
- The list of new songs.
- Favorite songs.
- Language is displayed in Vietnamese and English.
- Reserve the song and clear the reserved song
- Adjust the key and tempo appropriate with each voice.
- Increase/decrease the song's melody as desired.
- Install greetings/lines on the screen in Vietnamese.
- Score and applause as preference.
Qualitative picture, transparent and clear sound
- Decoding technique MPEG1, MPEG2 and MPEG3, DIVX(Code3.11-5.0).
* Note: not support absolutely 100% for DIVX formats.
- High quality sound with digital effect.
- High quality picture (MPEG2).
Other special features:
- Unique VOCAL/CHORUS technique with the lively effect of vocal/chorus
-
USB interface: play picture and audio data of all formats MP3,MP4,WMA,WAV...
USER'S MANUAL
AR-36CN
-
DVD disc can play up to 135', including 8 languages and 32 different captions
- MPEG-2 helps compress picture with high quality sound; creates the great, lively
audio and picture as in the theaters.
FEATURES
Advertisement
Table of Contents
Related Manuals for Arirang AR-36CN
Summary of Contents for Arirang AR-36CN
- Page 1 USER’S MANUAL AR-36CN FEATURES Support for disks - MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,Mp3,Mp4 Karaoke support various functions Function of presetting the song and helps to preset 99 songs. - The list of new songs. - Favorite songs. - Language is displayed in Vietnamese and English.
-
Page 2: Name Of Each Part
NAME OF EACH PART Front panel: Power Load/eject disk tray Play Pause Stop Previous/Next Micro port Echo volume 1 Track/Chapter Reserve the song Displayed screen Number keys Micro volume USB port Increase/decrease the tempo Displayed screen: Repeat Inform Dobby Digital Disc contents being played Play/Pause Inform the Track... -
Page 3: Basic Connection
- 01 Midi Karaoke disc - 01 User’s manual - 01 Vietnamese song book - 01 Remote control - 01 Pair of AAA batteries - 01 Set of AV cable (3 wires) BASIC CONNECTION S-Video input Audio input Video input Component video port Component video cable S-Video... -
Page 4: Remote Control
REMOTE CONTROL 1. iFUN: turn on/off the cheer scoring 2. SETUP: set the device’s configuration 3. MUTE: turn on/off the volume of device 4. ANGLE/ADD SONG: + MIDI: add song to the list of favorite songs + DVD: select view angle (supported by disk) 5. - Page 5 8. MENU: + MIDI: set Karaoke feature +DVD/VCD: enter to main MENU, on/off PBC (VCD2.0) 9. MALE: select male tone when the song being played (MIDI) 10. STEP/RESTART: + MIDI: replay the song being played + DVD/VCD: slowly play each picture 11.
-
Page 6: Configuration Setting
CONFIGURATION SETTING * Press SETUP key on the remote control to start setting: 1. Language installation: Language: set language for the device Caption: caption language (supported by DVD disk) Voice-over: voice-over language (supported by DVD disk) Disc language: default language in disc play (supported by DVD disk) 2. - Page 7 + Automatic + NTSC + PAL Angle: Turn on/off the effect of view angle (supported by DVD disk) 3. Audio installation: Digital output: digital audio output + Off + BTS: Stereo output + LPCM: Coaxial output Downmix: + LT/RT (supported Dolby Prologic by amplifier) + Stereo + 5.1 Channel Dual mono:...
- Page 8 4. Karaoke installation: Micro setting: + Off + Automatically Key: increase/decrease the key Scoring: select the way to score + Off + Normal + Automatically Scale: + Non professional + Normal + Professional 5. Effect setting:...
- Page 9 EQ: Adjust the timbre, support for 5 timbres Effect: default setting in 8 sound effects Configure Surround Delay: the delay of rear speaker 0ms-25ms Center Delay: the delay of center speaker 0ms-5ms 6. Children lock: Change: Set the code to lock children from seeing the movie that is not suitable for their ages (supported by DVD disk) Limit: Set limit to lock children + Kid safe: Highest...
- Page 10 Melody: on/off the song melody Cheer scoring (iFUN): on/off Background picture: DVD/blue Drive lock: lock the drive in MIDI use Coin Function: on/off the mode of coin use DVD/VCD/CD PLAY 1. Put disc in the tray: + Press OPEN/CLOSE key to eject the disk tray then put disc in the tray (Note: label located above the disk, not placed the disc askew to avoid scratch and damage when the device is operating) + Press OPEN/CLOSE or PLAY...
-
Page 11: Basic Operation
+ Press “PLAY” key to return to normal play mode 8. Zoom in picture (DVD/VCD): can zoom in picture up to 3 times. Depending on the play mode, “ZOOM” key has different effects. Press up/down/left/right key to move + In the mode of normal play, “ZOOM” key has the effect of zoom in the picture + In the mode of moving picture, “ZOOM”... - Page 12 + Press POPULAR key to display the list of popular songs (approximately 300 songs) + Press ENTER after selecting one of the favorite songs in the list + Press POPULAR again to exit 7. Favorite song: + Press FAVORITE key + Select the song, press PLAY/ENTER key to play + Press STOP to exit 8.
-
Page 13: Usb Connection
Increase/decrease the number of word Character to be found The total number of words (5 words) in the song (CHAR +/-) USB CONNECTION * Plug USB in connection port supported in front/rear side of the device. The device automatically identifies the internal data, use up/down/left/right key to select the data format, press ENTER to play - Audio: Audio (*.mp3/*.wma) - Image: Picture (*.jpg) - Page 14 SETTING IN MIDI KARAOKE DISC - Press MENU key on the remote control to enter to configuration setting + List of songs: list of songs of each language + Search as per author: list of author’s name (only support for Vietnamese author) + New song + Popular song + Favorite song...
-
Page 15: Troubleshooting
TROUBLESHOOTING TECHNICAL PROBLEMS SPECIFIC REPAIR Not eject the disk tray - The power-source cable not plug in Plug the power-source cable in The device not playing - Not have disc in drive - Put disc in drive - Disc placed in opposite side - Select the correct disc side - Disc is too dirty or scratched - Clean disc or change disc... -
Page 16: Specifications
SPECIFICATIONS Voltage: AC 90 – 240VAC 50/60Hz Power Consumption: 17W Weight: 4.5Kg Compatible with: DVD Midi Karaoke/DVD/DVD-R/SVCD/ VCD/CD-R/ CD-RW/Mp3/WMA/Mp4 & Jpeg Video 1VP-P (750) 1VP-P (750) S-Video 0.286 VP-P (750) Output 1VP-P (750) Component 0.7 VP-P (750) 0.7 VP-P (750) Audio L/R,5.1CH 2Vrms(max) Input...
