- Page 1 INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE ELECTRIC KETTLES “PMDE100.” “PMDE150.”...
- Page 2 Codice PMDE… MANUALE D’ISTRUZIONE Storia delle revisioni Data di Punto Natura della Type of correction Verbesserungsart Type de correction Firma Visto Revis. revisione correzione Prima emissione First issue Erste Ausgabe Première émission Budel 31.01.2005 Tutti Mod. schema Modify Wiring Veränderfe Mod.
-
Page 3: Table Of Contents
INDEX Part 1: General reminders and notes 1.1. General reminders 1.2. Technical data 1.3. Construction 1.3.1. Details only for pressure kettles 1.4. Laws, technical prescriptions and directives 1.5. Special requirements for the installation site Part 2: Positioning, installation and maintenance 2.1. - Page 4 Part 4: Figures and details 4.1. Wiring diagram Mod. 100/150 lt 4.2. View of appliance 4.3. Controls Instruction manual for installation, maintenance and use - GB - 4 di 16 Page Electric Kettles PMDE…...
-
Page 5: General Reminders
1.1. GENERAL REMINDERS − Read the warnings contained in this manual carefully as they provide important information concerning safety during the installation, use and maintenance of the appliance. − Keep these instructions carefully! − Only personnel trained for its specific use should use the equipment. −... -
Page 6: Technical Data
1.2. TECHNICAL DATA Instruction manual for installation, maintenance and use - GB - 6 di 16 Page Electric Kettles PMDE…... -
Page 7: Construction
1.3. CONSTRUCTION − Main structure in AISI 430 with 4 adjustable height feet. − Panels in stainless steel AISI 304, thickness 10-12/10. − Cooking vat in stainless steel AISI 316, thickness 20/10 ÷ 40/10. − Chrome-plated brass drainage tap. − The temperature limiting device which switches off automatically the appliance in case of overheating of cooking-vat-bottom. -
Page 8: Installation
2.1. POSTIONING − Remove all the packaging and check that the appliance is in perfect conditions. In case of visible damage, do not connect the appliance and notify the sales point immediately. − Remove the PVC protection from the panels. −... -
Page 9: Connection To Waterworks
2.2.2. CONNECTION TO WATERWORKS − Water inlet pressure must be between 50 and 300 kPa, otherwise install a pressure regulator on the line before the appliance. − Install a cut-off valve for each supply on the line before the appliance. −... -
Page 10: New Setting Parameters Safety Digital Thermostat
2.3.2. NEW SETTING PARAMETERS SAFETY DIGITAL THERMOSTAT The intervention temperature of the safety thermostat, positioned behind the instrument panel, had been set by the manufacturer and only the assistance can modify it, using a password. In case of working without water in the basin, reaching the set temperature, the thermostat stops the cooking functions activating a buzzer pointing it out. -
Page 11: Warnings And Hints For User
3.1. WARNINGS AND HINTS FOR USER − This manual contains all the instructions required for a proper and safe use of our appliances. Keep the manual in a safe place for future consultation! − This appliance is for catering use, hence they must be used only by trained kitchen staff. −... -
Page 12: Cleaning And Care Of The Appliance
3.2.2. SWITCHING ON, START COOKING AND SWITCHING OFF − Fill the vat with hot or cold water, according to need, using the tap that the appliance is equipped with. − The appliance has a three-position selector to start cooking functions (see figure “Controls"). −... -
Page 13: Daily Cleaning
3.3.1. DAILY CLEANING Warning! : When cleaning the appliance never use direct jets of water to prevent infiltration of the liquid and damage to components. − Clean the cooking vat with water and a detergent, rinse thoroughly and dry well with a soft cloth. −... -
Page 14: Wiring Diagram Mod. 100/150 Lt
4.1. WIRING DIAGRAM MOD. 100/150 LT LEGEND: Electromagnetic switch MAX. Heating element Relay (230v) Fender-fuse 3,15A Tc/K Temperature feeler Operating thermostat Line terminal board Temperature limiting device Safety meter Instruction manual for installation, maintenance and use - GB - 14 di 16 Page Electric Kettles PMDE…... -
Page 15: View Of Appliance
4.2. VIEW OF APPLIANCE LEGEND: Water cock Hot water connection Digital thermostat Cold water connection Cooking vat drainage tap Electrical connection Instruction manual for installation, maintenance and use - GB - 15 di 16 Page Electric Kettles PMDE…... -
Page 16: Controls
4.3. CONTROLS WORKING THERMOSTAT AND SAFETY THERMOSTAT button “ARROWS” (used to modify the values) button “SET” ( on/off ) DISPLAY LED heating in function LED settino temperature phase Only for pressure kettles: Valve and position of relief valve: Closed valve Open valve Instruction manual for installation, maintenance and use - GB -...
