Summary of Contents for GKB 720P SDI

  • Page 1 Before operating this unit, please read this manual thoroughly and retain it for future reference.   User’s Manual     GKB 720P SDI 36 Series Manual                            ...
  • Page 2: About This Manual

    Be aware that before installing or operating the unit, please read all safety notes and warnings provided in this manual. GKB 36 Series is a surveillance device for use in security systems that assist in the management of security. GKB is not liable nor can be held responsible for any material loss and/or personal injuries cause by robbery, fire, natural disaster or problems of any kind resulting from the use of this device.
  • Page 3     Precaution   1. Do not drop the camera. GKB HD5435 SDI Camera is not designed to resist heavy impact. Handle with care to avoid damage to sensitive internal components. 2. Do not install camera under extreme temperatures. GKB HD5435 SDI Camera operates only under temperature conditions between -10˚C ~ 50˚C and with...
  • Page 4       4. Do not supply voltage higher than 12V DC. GKB HD5435 SDI Camera regulates power within this range. Higher voltages will damage the camera’s electronic components. 5. Do not install the camera in environments with extreme humidity.
  • Page 5: Osd Menu Structure

        GKB 720P SDI 36 Series Manual   OSD MENU Structure 1.MIRROR OFF/ON 2.FLIP OFF/ON IMAGE 3.CONTRAST 0-255 4.EDGE 0-255 5.BRIGHT 0-255 1.EXP MODE AUTO MANUAL:SHUTTER :1/50s~1/3000s EXPOSURE GAIN: LOW/HIGH/EXT 2.SPEED 0-16 3.IRIS FLAG OFF/ON WHITE BAL 1.WB MODE MANUAL/AUTO/INDOOR/OUTDOOR 1.BACKLIGHT...
  • Page 6: Camera Osd Setup Menu

        GKB 720P SDI 36 Series Manual   Camera OSD SETUP MENU Operating the OSD Menu ! The button provides five separate actions: UP, DOWN, EXIT, ENTER and MENU. ! Press MENU to go to the OSD Menu Page.
  • Page 7: White Bal

        GKB 720P SDI 36 Series Manual   EXPOSURE In EXP MODE can adjust Shutter & Gain for different exposure condition. Speed/ IRIS FLAG for you adjust due to various light sources. < < EXPOSURE > > 1. EXP MODE...
  • Page 8     GKB 720P SDI 36 Series Manual   SPECIAL BACKLIGHT correct exposure of subjects in front of a bright light source. FLICKER improve the image flicker conditionECLIPSE masks strong light. < < SPECIAL > > 1. BACKLIGHT 2. FLICKER 3.
  • Page 9 < < SYSTEM > > 1. CAM ID   2. DISP CAM ID 3. DISP NAME 4. FACTORY RESET 5. RETURN Please refer to the website ”http://www.gkbsecurity.com.“ for more information. © 2014 GKB Security Corporation. Specifications are subject to change without prior notice.
