QUICKSTART

OUT OF THE BOX

Your Smartvue S9 network video server (SERVER) comes with a power supply and a
Quickstart Guide. Smartvue S9 network video cameras and other supported cameras are
available separately, see your authorized Smartvue dealer or visit www.smartvue.com.

TURN IT ON

Connect an Ethernet cable to the network ETHERNET PORT #1 (left port) on the back of the
SERVER and plug it into your local network. Plug in power using the included power
supply to the 12V AC connector. on the front of the SERVER and press the power button to
turn the system on.
Ethernet 1/2 Audio Out/In USB DVI Out Antenna
USB Power RS232 Power In
11
