MOUNTING ANYLINK
Mount AnyLink high on the rear of the Tx, and extend its antenna to
point upwards from the top of the Tx as much as possible. Rotate
the antenna as shown above. Two strips of hard locking fasteners
are included for attaching AnyLink to the rear of the host Tx.

PREPARATIONS AND CONNECTIONS

IMPORTANT! Remove the airplane's propeller prior to
setting up AnyLink to work with the flight system. Failure
to do so could result in personal injury if the motor unexpectedly
turns during setup.
1. Remove the Rf module or crystal from the host Tx if possible.
2. Leave the Tx's own antenna in a retracted or folded position as
it will not be used.
3. For computer radios on 72MHz, make sure the modulation is set
to PPM mode.
4. Cables are included for attaching AnyLink to Futaba radios
having a square trainer jack, and compatible JR/Spektrum radios.
The cable with three connectors is for JR and Spektrum. Cables for
Futaba and Hitec transmitters with round trainer jacks, Hitec Aurora,
and other type transmitters are available separately (see page 10).
2
