Model No. WETL34709.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if there are
missing parts, please contact us:
Call: 08457 089 009
From Ireland: 053 92 36102
E-mail: www.iconsupport.eu
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC, Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WETL34709.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Weslo WETL34709.0

Summary of Contents for Weslo WETL34709.0

  • Page 1 USER'S MANUAL Model No. WETL34709.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, please contact us: Call: 08457 089 009 From Ireland: 053 92 36102 E-mail: www.iconsupport.eu...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 18. Do not attempt to raise, lower, or move the 23. This treadmill is intended for in-home use treadmill until it is properly assembled. (See only. Do not use this treadmill in a commer- ASSEMBLY on page 6, and HOW TO FOLD cial, rental, or institutional setting.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary WESLO ing this manual, please see the front cover of this man- ® COMPACT ELITE treadmill. The COMPACT ELITE ual. To help us assist you, note the product model treadmill offers an impressive selection of features de- number and serial number before contacting us.

  • Page 6: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, some lubricant may be transferred to the top of the walking belt or the shipping carton.
  • Page 7 2. Pivot the console assembly to the desired posi- tion and tighten the Console Knobs (37). Console Assembly Always make sure that the Console Knobs (37) are fully tightened before you use the treadmill. 3. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear plastic on the treadmill decals, remove the plastic.

  • Page 8: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or similar substances to the walking belt or the walking platform. Such substances will deteri- orate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product is for use on a dedicated, 20-amp, 220–240 volt circuit.
  • Page 9 CONSOLE DIAGRAM Km/H QUICK SPEED Clip FEATURES OF THE CONSOLE To turn on the power, see page 10. To use the man- ual mode, see page 10. To use a preset workout, The treadmill console offers an impressive array of see page 12.
  • Page 10 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
  • Page 11 4. Follow your progress with the display. To measure your heart rate, stand The speed display shows the speed of the walk- on the foot rails ing belt. and hold the metal contacts. Avoid The time display shows the elapsed time. Note: moving your hands.
  • Page 12 HOW TO USE A PRESET WORKOUT To stop the workout at any time, press the Stop button. To restart the workout, press the Start but- 1. Insert the key into the console. ton. The walking belt will begin to move. When the next segment of the workout begins, the treadmill See step 1 on page 10.

  • Page 13: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, remove the key and unplug the power cord. CAUTION: You must be able to safely lift 45 lbs. (20 kg) to raise, lower, or move the treadmill. 1.

  • Page 14: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 15 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...

  • Page 16: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 17: Part List

    PART LIST—Model No. WETL34709.0 R1209B To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description Base Key/Clip Frame Incline Arm Washer Left Upright Lower Support Tube Cap...

  • Page 18: Exploded Drawing

    EXPLODED DRAWING A—Model No. WETL34709.0 R1209B...
  • Page 19 EXPLODED DRAWING B—Model No. WETL34709.0 R1209B...

  • Page 20: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
