Summary of Contents for Weslo Cadence 45

Page 1 Class H Fitness Product Model No. WETL0514.0 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 Or write: ICON Health &...
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover WESLO is a registered trademark of ICON IP, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 11. If an extension cord is needed, use only a 3- that all users of this treadmill are adequately conductor, 1mm (14-gauge) cord that is no...
Page 4 DANGER: other than the procedures in this manual Always unplug the power should be performed by an authorised service cord immediately after use, before cleaning representative only. the treadmill, and before performing the main- tenance and adjustment procedures de- 23. This treadmill is intended for in-home use scribed in this manual.
Page 5: Before You Begin
And when is WETL0514.0. The serial number can be found on a you’re not exercising, the unique CADENCE 45 tread- decal attached to the treadmill (see the front cover of mill can be folded up, requiring less than half the floor this manual for the location of the decal).
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Place a mat under the treadmill to protect the floor during assembly. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until as- sembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 7 2. See the inset drawing. Identify the Right Upright (37), which has a large round hole near the lower end, and the Left Upright (32). Small Have a second person hold the Base (55) so it is resting Holes on the Wheels (34) as shown. Attach the Right and Left Uprights (32, 37) to the Base with four Upright Bolts (28), four 3/8”...
Page 8 5. Attach the end of the ground wire on the Wire Harness (53) to the small hole in the side of the right Handrail (4) with a Silver Ground Screw (89). 6. Place the Console Base (45) on the Handrails (4) (only one Handrail is shown).
Page 9 8. Set the Console (2) in the Console Base (45). Make sure that no wires are pinched. Attach the Console (2) to the Console Base (45) with six 3/4” Screws (77). Start all six Screws before tighten- ing them; do not overtighten the Screws. 9.
Page 10 12. Lower the Uprights (32, 37) until the Handrails (4) are touching the floor. 32, 27 See drawing 12a. Position the Uprights (32, 37) so that the treadmill Frame (21) is centred between the Uprights. Firmly tighten the four Upright Bolts (28). Then, raise the Uprights (32, 37) back to the vertical position.
Page 11: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
Page 12 CONSOLE DIAGRAM Note: If there is a thin sheet of Clip plastic on the console, remove it. slide the clip onto the waistband of your clothes. Insert CAUTION: the key fully into the console. After a moment, the dis- Before operating the plays will light.
Page 13 To stop the walking belt, press the Stop button. a secure place. Move the on/off switch near the The elapsed time will begin to flash in the power cord to the “off” position and unplug the Time/Distance display. power cord. Note: During the first few minutes that the tread- HOW TO CHANGE THE INCLINE OF THE TREADMILL mill is used, inspect the alignment of the walking...
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right.
Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, press the storage latch and hold it. Pivot the treadmill until the frame and foot rail are past the storage latch.
Page 16: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a.
Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES is activity that requires large amounts of oxygen for prolonged periods of time. This increases the demand WARNING: Before beginning on the heart to pump blood to the muscles, and on the this or any exercise program, consult your lungs to oxygenate the blood.
Page 19 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
Page 20 NOTES...
Page 21: Part List
PART LIST—Model No. WETL0514.0 R0305A Key No. Qty. Description Base 3/4” Tek Screw Hood Belly Pan Console Upright Spacer Motor Belt Motor Tension Washer Handrail Left Foot Rail Motor Isolator Plate Wheel Nut/Motor Nut 1” Tek Screw Belt Guide Motor Wire Clip Reed Switch Right Foot Rail...
Page 22: Exploded Drawing
EXPLODED DRAWING—Model No. WETL0514.0 R0305A...
Page 23 EXPLODED DRAWING—Model No. WETL0514.0 R0305A...
Page 24: Ordering Replacement Parts
When ordering parts, please be prepared to give the following information: • the MODEL NUMBER of the product (WETL0514.0) • the NAME of the product (WESLO CADENCE 45 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
