62 170C7 LCD
Go to cover page
6.1 Susceptibility of display to external environment
Operating
Storage
Note: recommend at 5 to 35°C, Humidity less than 60 %
Note: recommended at 5 to 35°C, Humidity less than 60 %
6.2 Transportation tests
Standard
Drop
Test
Vibration
Test
Bump
Test
6.3 Display disturbances from external environment
According to IEC 801-2 for ESD disturbances
6.4 Display disturbances to external environment
6.4.1 EMI
EMI: FCC, VCCI, CE, C-Tick, MPRIII, BCIQ, IC, BSMI, *IEC60601-1-2 (EU)
* Medical compliance only applies for dedicated models.
2004-04-17
GF Chien
GENERAL PRODUCT SPECIFICATION(Continued)
- Temperature : 0 to 35 degree C
- Humidity : 80% max
- Altitude : 0-3658m
- Air pressure : 600-1100 mBAR
- Temperature : -20 to 60 degree C
- Humidity : 85% max ( < 40
- Altitude : 0-12192m
- Air pressure : 300-1100 mBAR
Height
Sequence
Electrical function ok
Test Mechanical function ok
Result No serious damage on set appearance
(Room temp 20°C ~23°C, humidity 40%~65%)
(1) PACKAGING
Sequence 0.73 Grms. Truck spectrum, 30 min /axis , 3 Axes.
(2) OPERATING
10-55-10 Hz, 0.35 Ampl,30 min/axis, 3 Axes
Test Electrical function ok
Result Mechanical function ok
No serious damage on set appearance
For design evaluation
Operating
10 G, 11 msec, 1000 cycles
Temperature : 23°C
Humidity : 60 %
Air pressure : 100 kpa
(According to DSD draft standard UAN-D636)
17 inch LCD Monitor
TYPE : 170C7FS/00
BRAND : PHILIPS
2004-04-17
)
(Room temp) 6 face
only
8639 000 17066
590 14
19
NSTA
76.0 cm
1 corner
3 edge
