Philips 170C7FS/00 Service Manual page 59

GENERAL PRODUCT SPECIFICATION(Continued)
3.3.3 Horizontal scanning
Sync polarity.
Scanning frequency.
3.3.4 Vertical scanning
Sync polarity.
Scanning frequency.
Power input connection
3.4
Power-cord length.
Power-cord type.
Power management
3.5
The power consumption and the status indication of the set with power management function are as below:
Status
H-sync
On On
Stand-by Off
Suspend On
Off Off
DC Power off
According to VESA power saving signal. TCO'99 power saving requirement EPA energy star requirement
(Power Switch Off)
For digital input power consumption is less 1W
(In non-DMPM recoverable off mode)
Display identification
3.6
3.6.1 In accordance with VESA Display Channel Standard V1.0 and having DDC-2B and DDC/CI capability.
3.6.2 In accordance with DVI requirement (DDWG digital Visual Interface revision 1.0) use DDC-2B, DDC/CI, and EDID 3.0
structure 2.0
4.0 Visual characteristics
Test conditions
4.1
Unless otherwise specified, this specification is defined under the following conditions.
(1) Input signal: As defined in 3.3, 1280 x 1024 non-interlaced mode (80K/75Hz), signal sources must
have 75 ohm output impedance.
(2) Luminance setting: controls to be set to 200 nits with full screen 100 % duty cycle white signal
(3) Warm up: more than 30 minutes after power on with signal supplied.
(4) Ambient light: 400 -- 600 lux.
(5) Ambient temperature: 20 ± 5 °C
Resolution
4.2
Factory preset modes (19 modes)
17 inch LCD Monitor
TYPE
BRAND : PHILIPS
2006-04-17
GF Chien
: Positive or Negative
: 30 - 82 KHz
: Positive or Negative
: 56 - 76 Hz
: 1.8 M
: 3 leads power cord with protective earth plug.
Power
V-sync Video
On Active
<36W
On
Blanked <1W
Off
Blanked <1W
Off
Blanked <1W
N/A
<1W
:170C7FS/00
2006-04-17
LED
Green
Amber
Amber
Amber
LED Off
8639 000 17066
19 590 11
170C7 LCD 59
