GENERAL PRODUCT SPECIFICATION(Continued)
PIN No.
3.2.2 DVI Cable
The input signals are applied to the display through DVI-D cable.
Length.
Connector type.
Pin Assignment:
17 inch LCD Monitor
TYPE
BRAND : PHILIPS
2006-04-17
GF Chien
SIGNAL
Red video input
1
Green video input / sync on green
2
Blue video input
3
4 GND
GND- Cable detect
5
Red video GND
6
7 Green video GND
8 Blue video GND
9 DDC +3.3V or +5V
10 Logic GND
11 GND
Serial data line (SDA)
12
13 H-sync / H+V
14 V-sync
Data clock line (SCL)
15
: 1.8 M +/- 50 mm
: DVI-D male with DDC-2B pin assignments
White connector thumb-operated jackscrews
:170C7FS/00
2006-04-17
8639 000 17066
19 590 5
