GENERAL PRODUCT SPECIFICATION(Continued)
FOREWORD
1.0
This specification describes a 17" SXGA multi-scan color TFT-LCD monitor with max resolution up to
1280*1024 /76
Hz non-interlaced.
PRODUCT PROFILE
2.0
This display monitor unit is a color display monitor enclosed in PHILIPS global styling cabinet,
which has an integrated
tilt and swivel base.
2.1 LCD
Type NR.
2.1.1
Number of Pixels.
Physical Size.
Pixel Pitch.
Color pixel arrangement.
Support Color.
Display Mode.
Backlight.
Active area. (WXH).
Viewing Angle (CR>=10).
Contrast ratio.
White luminance.
Type NR.
2.1.2
Number of Pixels.
Physical Size.
Pixel Pitch.
Color pixel arrangement.
Support Color.
Display Mode.
Backlight.
Active area. (WXH).
Viewing Angle (CR>=10).
Contrast ratio.
White luminance.
Type NR.
2.1.3
Number of Pixels.
Physical Size.
Pixel Pitch.
Color pixel arrangement.
Support Color.
Display Mode.
Backlight.
Active area. (WXH).
Viewing Angle (CR>=10).
Contrast ratio.
White luminance.
Scanning frequencies
2.2
H-Frequency.
V-Frequency.
Video dot rate.
2.3
Power input.
2.4
Power consumption.
2.5
2.6 Dimensions.
2.7 Weight.
17 inch LCD Monitor
TYPE
BRAND : PHILIPS
2006-04-17
GF Chien
: LM170E03 TLB1
: 1280 (H) x1024 (V)
: 358.5(w)*296.5(h)*17(d) mm
: 0.264 mm x 0.264 mm
: RGB stripes arrangement
: 16.2M colors
: Normally White
: CCFL edge light system
: 337.92 x 270.336mm (17" diagonal)
: Right:80 , Left:80 , UP:75 , down:85
: 800 :1(typic
: 300 nit
: CLAA170EA07 P
: 1280 (H) x1024 (V)
: 358.5(w)*296.5(h)*17.5(d) mm
: 0.264 mm x 0.264 mm
: RGB vertical stripes
: 16.2M colors
: Normally White
: CCFL edge light system
: 337.9 x 270.3 mm (17" diagonal)
: Right:80 , Left:80 , UP:80 , down:80
: 700 :1(typic)
: 300 nit
: M170E5-L0C
: 1280 (H) x1024 (V)
: 358.5(w)*296.5(h)*17.0(d) mm
: 0.264 mm x 0.264 mm
: RGB vertical stripes
: 16.7M colors
: Normally White
: CCFL edge light system
: 337.92 x 270.34 mm (17" diagonal)
: Right :80; Left :80 ; Up : 80 ; Down: 80
: 800:1
: 300 nit
: 30K - 82 KHz
: 56 - 76 Hz
: < 140 MHz
: 90-264 V AC, 50/60 ± 2 Hz
: < 36 W maximum
:
:170C7FS/00
2006-04-17
8639 000 17066
19 590 3
170C7 LCD 51
