SPECIFICATIONS

Turntable Platter
Type .................................................................................................................. Plastic
Outer Diameter ...................................................................... 300 mm (11
Drive System ............................................................................................... Belt Drive
Motor Type ................................................................................................... DC Motor
Turntable Type ................................................................................ Automatic Return
Rotation Speeds ............................................................ 2-Speed (33
Tone Arm
Type ................................................................................................ Dynamic Balance
Effective Length ........................................................................ 195 mm (
Overhang ......................................................................................... 15 mm (
Tracking Error ........................................................................................ Less Than 4°
Cartridge
Output Voltage:
2.5 mv at 1 kHz (with
450 mv at 1 kHz (with
Frequency Response ............................................................................ 20–20,000 Hz
Channel Separation (1 kHz) ........................................................... More Than 15 dB
Load Resistance : 47 kohm (with
)
OFF
Tracking Force ..................................................................................... 3.5 ±1.0 Gram
Stylus
Tip ...................................................................................................... Diamond Stylus
Replacement ............................................................................................ AT3600LAX
LINE OUT ON/PHONO OUT OFF
LINE OUT ON/PHONO OUT OFF
LINE OUT ON/PHONO OUT OFF
13 / Inches)
16
1 / and 45 RPM)
3
11 / Inches)
16
/
9
16
set to
PHONO OUT OFF
set to
LINE OUT ON
set to
PHONO OUT
Inch)
)
)
13
