- Page 1 KDC-BT44U CD-RECEIVER INSTRUCTION MANUAL CD-RECEIVER BEDIENUNGSANLEITUNG CD-PECИBEP ИHCTPУKЦИЯ ПO ЭKCПЛУATAЦИИ © 2013 JVC KENWOOD Corporation GET0974-001A (EW/E0)
- Page 2 For Israel Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable for EU countries that have adopted separate waste collection systems) Products and batteries with the symbol (crossed-out wheeled bin) cannot be disposed as household waste. For Turkey Old electrical and electronic equipment and batteries should be recycled at a facility capable of Bu ürün 28300 sayılı...
- Page 3 • Android is trademark of Google Inc. • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and trade names are those of their respective owners.
-
Page 4: Table Of Contents
CONTENTS BEFORE USE Warning BEFORE USE Do not operate any function that takes your attention away from safe driving. BASICS Caution Volume setting: GETTING STARTED • Adjust the volume so that you can hear sounds outside the car to prevent accidents. •... -
Page 5: Basics
BASICS GETTING STARTED Faceplate Volume knob (turn/press) Display window Cancel the demonstration When you turn on the power (or after you reset the unit), the display shows: “SEL LANGUAGE” “PRESS” “VOLUME KNOB” Turn the volume knob to select [ENG] (English) or Detach button [RUS] (Russian), then press the knob. - Page 6 YES: Starts upgrading the firmware. ; NO: Cancels (upgrading is not performance. activated). DISPLAY For details on how to update the firmware, see: www.kenwood.com/cs/ce/ EASY MENU ON: Both display and button illumination change to white color when entering [FUNCTION]. ; OFF: Both display and button illumination remain as [COLOR SELECT] color. ( 15)
-
Page 7: Radio
RADIO MONO SET ON: Improves the FM reception, but the stereo effect may be lost. ; OFF: Cancels. NEWS SET ON: The unit will temporarily switch to News Programme if available. ; OFF: Cancels. REGIONAL ON: Switches to another station only in the specific region using the “AF” control. ;... -
Page 8: Cd / Usb / Ipod
• Audio CD: TRACK REPEAT, REPEAT OFF • MP3/WMA/AAC/WAV file or iPod: FILE REPEAT, FOLDER REPEAT, and/ or REPEAT OFF • KENWOOD Music Editor Light (KME Light)/ KENWOOD Music USB cable from the rear of the unit Control (KMC) file ( 16): FILE REPEAT, REPEAT OFF iPod/iPhone Random play * Press 3 ... - Page 9 CD / USB / iPod Select a track/file from a list Select a song by name Set the skip search ratio For iPod: Applicable only when [MODE OFF] is While listening to iPod... While listening to iPod or KME Light/ KMC file... selected.
-
Page 10: Aux
RADIO Preparation: Preparation: Do this Select [ON] for [BUILT-IN AUX]. ( 4) Install the latest version of Aha Pause or resume Press 6 IW. application onto your device (iPhone/ Start listening playback iPod touch), then create an account and log in to Aha Connect a portable audio player Press S / T. -
Page 11: Bluetooth
BLUETOOTH® You can operate Bluetooth devices using this unit. • Pairing request (via Bluetooth) is Pair a Bluetooth device automatically activated if an iPhone/iPod When connecting a Bluetooth device to touch is connected through the USB input Connect the microphone the unit for the first time, perform pairing terminal. - Page 12 BLUETOOTH® Bluetooth mobile phone Improve the sound quality during a call While talking on the phone... Do this Press the volume knob to enter [FUNCTION]. Receive a call Press or the volume knob or Turn the volume knob to make a selection (see the following table), then one of the number buttons (1 to 6).
- Page 13 BLUETOOTH® Bluetooth mode operations VOICE Speak the name of the contact you want to call or use the voice command to control the phone functions. ( 10, Use Voice Recognition) Press to enter Bluetooth mode. Turn the volume knob to make a selection (see the following table), BATT* LOW/ MID/ FULL: Shows the strength of the battery.
- Page 14 BLUETOOTH® Turn the volume knob or press S / T to select the desired first Delete a contact letter, then press the knob. Not applicable for mobile phone that supports PBAP. • To search with numbers, select “1”. • To search with symbols, select “ ”. Press to enter Bluetooth mode.
- Page 15 BLUETOOTH® Internet radio via Bluetooth Bluetooth audio player TRANSFER “DL PB ” appears and transfer the Operations and display indications may differ phonebook of the connected phone to Listen to Aha Radio according to their availability on the connected this unit manually. Preparation: device.
-
Page 16: Audio Settings
AUDIO SETTINGS While listening to any source... PRESET EQ DRIVE EQ/ TOP40/ POWERFUL/ ROCK/ POPS/ EASY/ JAZZ/ Press the volume knob to enter [FUNCTION]. NATURAL/ USER: Selects a preset equalizer suitable to the music genre. Turn the volume knob to select [AUDIO CONTROL], then press the (Select [USER] to use the customized bass, middle, and treble settings.) knob. -
Page 17: Display Settings
Press and hold to exit. • Detailed information and notes about the playable audio files are stated in an online manual on the following web site: www.kenwood.com/cs/ce/audiofile/ To return to the previous setting item or hierarchy, press Default: XX Playable files COLOR SELECT VARIABLE SCAN/ COLOR 01 —... -
Page 18: Troubleshooting
“NO DISC” appears. Insert a playable disc into the loading slot. • You cannot operate iPod if “KENWOOD” or “ ” is displayed on iPod. “TOC ERROR” appears. Make sure the disc is clean and inserted properly. About Aha Radio “PLEASE EJECT”... - Page 19 “AHA APP UPDATE Make sure you have installed the latest version of the Aha signal reception. REQUIRED” application for KENWOOD application on your device. • Voice calling method is • Use voice calling method in a more quiet environment. “AHA UNAVAILABLE”...
-
Page 20: Specifications
SPECIFICATIONS TROUBLESHOOTING Sound is being • Reduce the distance between the unit and the Bluetooth FM Frequency Range 87.5 MHz — 108.0 MHz (50 kHz space) interrupted or skipped audio player. Usable Sensitivity (S/N = 26 dB) 0.71 μV/75 Ω during playback of a • Turn off, then turn on the unit and try to connect again. Bluetooth audio player. - Page 21 SPECIFICATIONS USB Standard USB 1.1, USB 2.0 (Full speed) Frequency Response (±3 dB) 20 Hz — 20 kHz File System FAT12/ 16/ 32 Input Maximum Voltage 1 200 mV Maximum Supply Current DC 5 V 1 A Input Impedance 30 kΩ MP3 Decode Compliant with MPEG-1/2 Audio Layer-3 Operating Voltage 14.4 V (10.5 V — 16 V allowable) WMA Decode Compliant with Windows Media Audio Maximum Current Consumption 10 A...
- Page 22 Warning Installing the unit (in-dash mounting) • The unit can only be used with a 12 V DC power supply, negative ground. • Disconnect the battery’s negative terminal before wiring and mounting. • Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire (black) to prevent a short circuit.
-
Page 23: Wiring Connection
Color and function (D) Wiring harness control wire) Yellow : Battery Blue/White : Power control To connect the Kenwood Brown : Ignition (ACC) navigation system, consult (Mute control wire) MUTE Black : Earth (ground) connection your navigation manual.
