    IGW/400-CAN WLAN Device Server Firmware Update User Manual SSV Embedded Systems Heisterbergallee 72 D-30453 Hannover Phone: +49 (0)511/40 000-0 Fax: +49 (0)511/40 000-40 Manual Revision: 1.0 E-mail: sales@ist1.de Date: 2006-01-31 For further information regarding our products please visit us at www.ssv-embedded.de...
  • Page 2: Table Of Contents

    Hardware Requirements......................3 Software Requirements ......................3 PREPARATIONS ......................4 Installing Philips LPC2000 Flash Utility..................4 Preparing IGW/400-CAN ......................4 UPGRADING THE IGW/400-CAN FIRMWARE ..............7 Configure the Philips LPC2000 Flash Utility ................7 Power up the IGW/400-CAN....................7 Test the Connection ........................8 Upload the new Firmware......................9 Complete the Firmware Upgrade....................10...
  • Page 3: Introduction

    IGW/400-CAN – Introduction INTRODUCTION This document describes how to upgrade the firmware of the IGW/400-CAN. For further information about the individual components of this product you may read the IGW/400-CAN hardware reference and follow the links from our website at http://www.ssv-comm.de.
  • Page 4: Preparations

    Preparing IGW/400-CAN Connect the power supply cable as well as the RS232 adapter cable with the 14-pin Environment Interface of the IGW/400-CAN like shown in the following figure. Use the screw driver to fix the cables. Figure 1: Pin assignment of plug-in connector...
  • Page 5 IGW/400-CAN – Preparations Now connect the null modem cable with a free COM port of your Windows PC and the RS232 adapter cable of the IGW/400-CAN like shown in the figure below. Figure 2: Connecting Windows PC and IGW/400-CAN Caution: DO NOT connect the plug-in power supply with the power supply cable yet!
  • Page 6 IGW/400-CAN – Preparations Open the case of the IGW/400-CAN carefully. Set the ISP mode jumper (JP2) and the Watchdog disable jumper (Pins 9 and 10 on J2) like shown in the following figure: Figure 3: Setting the ISP mode jumper and the Watchdog disable jumper...
  • Page 7: Upgrading The Igw/400-Can Firmware

    Now connect the power supply cable with the plug-in power supply to start the IGW/400-CAN. Caution: DO NOT touch the boards or any other parts inside the IGW/400-CAN while it is connected to the power supply! S S V E M B E D D E D S Y S T E M S...
  • Page 8: Test The Connection

    IGW/400-CAN – Upgrading the IGW/400-CAN Firmware Test the Connection To test the connection between the IGW/400-CAN and your Windows PC click the button “Read Device ID” of the Philips LPC2000 Flash Utility. If you receive an error message, try to read the device ID a second time. If you still receive an error message, please check the cable connections and the settings of the Philips LPC2000 Flash Utility.
  • Page 9: Upload The New Firmware

    IGW/400-CAN – Upgrading the IGW/400-CAN Firmware Upload the new Firmware Click the button “…” (Filename) to choose the new firmware. The firmware file is called igw400_scli_upgrade.hex and is located in the directory CD-ROM:\isp-win32 on the Starter Kit CD-ROM. Now click the button “Upload to Flash”. You will see the upload progress like shown in...
  • Page 10: Complete The Firmware Upgrade

    4. Close the case of the IGW/400-CAN. That’s it! Now you can start the IGW/400-CAN again and work with the new firmware. S S V E M B E D D E D S Y S T E M S...
  • Page 11: Contact

    ‘as is’ without warranty of any kind. Some names within this document can be trademarks of their respective holders. © 2006 SSV EMBEDDED SYSTEMS. All rights reserved. S S V E M B E D D E D S Y S T E M S...
