Installation and Operation Data
FOR YOUR SAFETY - This product must be installed and serviced by a profes-
sional service technician, qualified in pool heater installation. Improper installa-
tion and/or operation could create carbon monoxide gas in flue gases which
could cause serious injury, property damage, or death. Improper installation and/
or operation will void the warranty.
Installation and
Operation Manual
Laars Lite 2
Model LC (Australia)
Pool and Spa Heater
Natural Gas
Propane (Outdoor Only)
WARNING: If these instructions are not followed exactly, a fire or explosion
may result, causing property damage, personal injury, or death.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a nearby phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified service technician.
WHAT TO DO IF YOU SMELL GAS
Outdoor
Configuration

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lite 2 LC and is the answer not in the manual?

Questions and answers
