- Page 1 CONFERENCE SYSTEM EDC-1000 SERIES Installation and operating instructions...
-
Page 2: Safety Precautions
EDC-1000 SERIES Conference System SAFETY PRECAUTIONS: Please read this manual carefully before installing and using this unit. Please keep this manual appropriately for futures questions. Please read carefully the instruction and warning in this manual. Please do not use accessories not recommended by dealers. - Page 3 EDC-1000 SERIES Conference System If the surface of the unit is dirty, please do not clean it with liquid or spraying detergent, while slightly wet cloth should be used. Please do not switch on and off the conference main control unit abruptly.
-
Page 4: Table Of Contents
EDC-1000 SERIES Conference System 1. FOREWORD ........................4 2. PRODUCT FEATURES ....................5 2.1. Main control unit …….................... 5 2.2. Chairman unit......................5 2.3. Delegate unit......................5 3. OPERATION AND FUNCTION DESCRIPTION ............. 6 3.1. Introduction to the function of front panel of main unit ........... 6 3.2. -
Page 5: Foreword
EDC-1000 SERIES Conference System 1. FOREWORD This EDC1000 series, the latest and easiest digital conference system with superb performance and elegant design, can be used for various conferencing. This conferencing system has the most updated built-in digital module with 10 chairmen... -
Page 6: Product Features
EDC-1000 SERIES Conference System 2. PRODUCT FEATURES 2.1. Main control unit of the conference system • Digital control capability: Chairman’s unit: 10 pcs, Delegate’s unit: 75 pcs. • It has 3 setting buttons which can be used to set and change the working mode of the microphone. -
Page 7: Operation And Function Description
EDC-1000 SERIES Conference System 3. OPERATION AND FUNCTION DESCRIPTION 3.1. Introduction to the function of front panel of main unit (1) MIC 1~3: volume control knob is independent of inputs. MIC 1, MIC 2 and MIC 3. (2) AUX1: volume control knob, it controls the volume of external input sound and adjusts the volume of chairman priority warning. -
Page 8: Function Of Rear Plate Of Main Control Unit
EDC-1000 SERIES Conference System 3.2. Function of rear plate of main control unit Note: disabled ports in grey. (1) LINK 1 ~ 3: Connect to conference microphone unit port. One link can connect up to 25 units. (2) L.SP-VR: Master volume-control of built-in loudspeaker of chairmen/delegate unit. -
Page 9: Main Unit Block Diagram
EDC-1000 SERIES Conference System (13) Conference power expansion unit DC power input terminal. could connect up to 75 units (14) SPEAKER 8Ω: built-in 40W×2 amplifier, low resistance 8 Ω speaker signal output terminal. (15) AC 110V/220 V 50/60 Hz: input voltage selection switch. -
Page 10: Installation And Setting Of The System
EDC-1000 SERIES Conference System 4. INSTALLATION AND SETTING OF THE SYSTEM 4.1. Basic installation instruction 4.1.1. Adjust AC power input Caution: you must adjust to correct input voltage. Otherwise, it may seriously damage the main unit. 4.1.2. Basic connection of conference control main unit to chairman/delegate microphones. -
Page 11: Power On
EDC-1000 SERIES Conference System • There are three microphone ports on the main control unit, which can be connected at random without any priority between it. • Chairman/delegate unit is equipped with hidden connecting terminal. When conducting connection, Y shape fast cable can be adopted to form hidden wiring with simple and beauty effect. -
Page 12: Led Display And Operation
EDC-1000 SERIES Conference System 4.3. LED display and operation 4.3.1. MIC CONTROL • 1~9 speaking mode：Press “SELECTOR” button to select 1~9 delegates can speak at the same time. Only the correspondent LED 1~9 will be ON. • Open system: When 1~9 LED all light up means all open. Every delegate can talk with no restriction. -
Page 13: Microphone Shape And Operation
EDC-1000 SERIES Conference System 5. MICROPHONE SHAPE AND OPERATION 5.1. Table-top chairman unit EDC-1011 (1) TALK button（with back-lighted indication lamp） (2) Chairman CONTROL button（with back- lighted indication lamp） (3) Build-in speaker (4) Microphone plug (DIN type). (5) Earphone output plug (6) Wire plug Function explanations：... -
Page 14: Table-Top Delegate's Unit Edc-1012
EDC-1000 SERIES Conference System 5.2. Table-top Delegate’s unit EDC-1012 (1) TALK button（with back-lighted indication lamp） (2) Build-in speaker (3) Microphone plug（DIN TYPE） (4) Earphone output plug (5) Wire plug Function explanations： 1. Press “TALK” button to start talking. The “TALK” button is with back-lighted indication lamp and Microphone with red LED to show its ON/OFF. -
Page 15: Flush-Mounted Chairman's Unit Edc-1021
EDC-1000 SERIES Conference System 5.3. Flush-mounted Chairman’s unit EDC-1021 (1) TALK button（with back-lighted indication lamp) (2) Chairman CONTROL button（with back-lighted indication lamp） (3) REC output plug (4) Earphone output volume plug (5) Build-in speaker (6) Microphone plug（DIN TYPE） (7) Wire plug Function explanations: Press “TALK”... -
Page 16: Flush-Mounted Delegate's Unit Edc-1022
EDC-1000 SERIES Conference System 5.4. Flush-mounted Delegate’s unit EDC-1022 (1) TALK button（with back-lighted indication lamp） (2) REC output plug (3) Earphone output plug with volume control (4) Build-in speaker (5) Microphone plug（DIN TYPE） (6) Wire plug Function explanations 1. Press “TALK” button to start talking. The “TALK” button is with back-lighted indication lamp and Microphone with red LED to show its ON/OFF. -
Page 17: Flush-Mounted Chairman's Unit Edc-1023
EDC-1000 SERIES Conference System 5.5. Flush-mounted Chairman’s unit EDC-1023 (1) Chairman CONTROL button（with back- lighted indication lamp) (2) TALK button（with back-lighted indication lamp) (3) Earphone output plug with volume control (4) REC output plug (5) Microphone plug（XLR TYPE） (6) Wire plug Function explanations：... -
Page 18: Flush-Mounted Delegate's Unit Edc-1024
EDC-1000 SERIES Conference System 5.6. Flush-mounted Delegate’s unit EDC-1024 (1) TALK button（with back-lighted indication lamp) (2) Earphone output plug with volume control (3) REC output plug (4) Microphone plug（XLR TYPE) (5) Wire plug Function explanations: 1. Press “TALK” button to start talking. The “TALK” button is with back-lighted indication lamp and Microphone with red LED to show its ON/OFF. -
Page 19: System Specifications
EDC-1000 SERIES Conference System 6. SYSTEM SPECIFICATIONS 6.1. EDC-1050 Main control unit specifications TECHNICAL DATA Frequency response 100 Hz ~ 16 kHz Line input -4 dB ~ +6 dB ≥ 10 kΩ (balanced) Line output -4 dB ~ +12 dB ≥ 200 Ω (balanced) -
Page 20: Microphone Unit Specifications
EDC-1000 SERIES Conference System 6.2. Microphone unit specifications: MICROPHONE Microphone type Electret (condenser) Frequency response 100 Hz ~ 16 kHz -23 dBv/Pa (maximum) Sensibility 126 dB (3 % THD) S/N ratio >20 dB (1 kHz) Dimensions flex + 43 cm (*)
