BEST ACCESS SYSTEMS 45HG Installation Instructions Manual

Contents
These installation instructions describe how to install your
45HG, 45HBV, and 45HZ Electronic Stand-Alone Mortise
Lock. Topics covered include:
Preparing the door ......................................................... 1
Configuring and installing the mortise case................. 3
Installing the trim............................................................ 4
Finishing the installation................................................ 9
For instructions to install 45HW & 47HW electrified
functions, see the Installation Instructions for 45HW &
47HW Electrified Mortise Locks (T81612).
1
Identify holes to drill
1 Determine the lock function to be installed.
2 Determine the inside and outside, hand, and bevel of
the door.
3 See the Holes by Function table and Figure 1 to
determine the holes to be drilled for the lock function.
Holes by Function
Holes to drill
A M & N forged trim
†
(2 holes)
†
B Harness
C Standard cylinder
D Sensor & motor wire
F Thumb turn
G Trim mounting
‡
(2 holes)
††
H Lever
† Determine trim holes based on trim type.
‡ Because these holes pass through the mortise pocket, it is recommended that each
hole be drilled separately rather than straight through.
Installation Instructions for 45HG/HBV &
45HZ Electronic Stand-Alone Mortise Locks
Functions
DV LV
I/S O/S I/S O/S I/S
Through Through Through
door door
Through Through
door door
■
■ ■ ■
■
Through Through Through
door door
Through Through Through
door door
BEST ACCESS SYSTEMS
a Division of Stanley Security Solutions, Inc.
For hole sizes, see the
G11 Template (T81622).
Figure 1
NV TV
O/S I/S O/S
Through
door door
Through
door
■
■
■
Through
door door
Through
door door
A
B
C
F
H
G
A
Identifying holes to drill
B
G
D
1
