- Page 1 User Manual Convertible Tablet roda PEGASUS...
- Page 2 PEGASUS User Manual roda ————————————————————————————— Page 2 of 23 —————————————————————————————...
- Page 3 PEGASUS User Manual roda ————————————————————————————— roda computer GmbH Landstrasse 6 77839 Lichtenau/Baden Telephone: +49(0)7227/9579-0 Telefax: +49(0)7227/9579-20 roda Service Center Hüllhorst Bredenhop 20 32609 Hüllhorst Telephone: +49(0)5744/944-470 Telefax: +49(0)5744/944-475 Page 3 of 23 —————————————————————————————...
- Page 4 (and not the manufacturer, its distributor, or its supplier) assumes the entire cost of all necessary servicing, repair and any incidental or consequential damages resulting from any software defects. Copyright © 2010 roda computer GmbH Lichtenau, January 2010 Author: Joachim Tschan Version History:...
- Page 5 PEGASUS User Manual roda ————————————————————————————— EMC and Safety Notice Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 6 PEGASUS User Manual roda ————————————————————————————— This equipment complies with the requirements set out in the Council Direction on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC). For the evaluation regarding the electromagnetic compatibility, the following standards were applied:...
-
Page 7: Table Of Contents
PEGASUS User Manual roda ————————————————————————————— Table of contents GETTING STARTED.................9 System Configurations..............10 Preparing your 13.3” Rugged Notebook Pegasus......11 COMPONENTS AND FUNCTIONS ............13 Front View..................13 I/O Port View...................14 Stylus ....................14 Making Connections ...............15 2.4.1 USB (Universal Serial Bus) Ports ..........15 2.4.2 LAN Port.................15... - Page 8 PEGASUS User Manual roda ————————————————————————————— GETTING STARTED Page 8 of 23 —————————————————————————————...
-
Page 9: Getting Started
GETTING STARTED Congratulations on your purchase of a Pegasus 13.3” rugged notebook. The 13.3” rugged notebook Pegasus is a fully functional PC with built-in wireless connectivity. You will be able to organize and access important business and personal information. In addition, you will be able to send and receive e-mail and access the Internet. -
Page 10: System Configurations
PEGASUS User Manual roda ————————————————————————————— 1.1 System Configurations Processor: Intel U7500" Merom" Processor Support Speed at 1.06GHz Chipset: INTEL ICH-8M + 965GM Chipset OS Support: Microsoft Windows XP Edition OS Support Display Screen Interface Support: Standard Touch Screen ... -
Page 11: Preparing Your 13.3" Rugged Notebook Pegasus
————————————————————————————— These are only quick instructions for using your 13.3” rugged notebook. Read the 1.2 Preparing your 13.3” Rugged Notebook Pegasus later pages for detailed information on using your 13.3” rugged notebook. 1. Connect the AC Power Adapter 2. Install the battery pack 3. -
Page 12: Components And Functions
PEGASUS User Manual roda ————————————————————————————— COMPONENTS FUNCTIONS Page 12 of 23 —————————————————————————————... -
Page 13: Front View
PEGASUS User Manual roda ————————————————————————————— GETTING STARTED 2.1 Front View 1. Five Way Control Key Up/Down , Left/Right & Enter Button 2. WiFi/BT Trigger Button 3. mouse button 4. Power Button 5. LCD Panel 6. Internal Microphone & Speaker 7. LED Status Indicator 8. -
Page 14: I/O Port View
PEGASUS User Manual roda ————————————————————————————— 2.2 I/O Port View USB port RS232 port Kensington lock LAN port Display output MIC in & Headphone out Modem port Optical drive PCMCIA and flash memory USB port Battery Slot Power (DC) input 2.3 Stylus Page 14 of 23 —————————————————————————————... -
Page 15: Making Connections
PEGASUS User Manual roda ————————————————————————————— Your 13.3” rugged notebook Pegasus is equipped with a full array of ports and 2.4 Making Connections connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers, keyboards, and mice. Refer to documentation included with individual devices for details on connecting these devices to your 13.3”... -
Page 16: Optical Drive
PEGASUS User Manual roda ————————————————————————————— 2.4.8 Optical Drive The Notebook PC comes in various models with different optical drives. The digital Notebook PC’s optical drive may support compact discs (CD) and/or video discs (DVD) and may have recordable (R) or re-writable (RW) capabilities. -
Page 17: Power System
2.5 Power System 2.5.1 Using AC Power The Pegasus power is comprised of two parts, the power adapter and the battery power system. The power adapter converts AC power from a wall outlet to the DC power required by the 13.3” Rugged Notebook. Your 13.3” Rugged notebook comes with a universal AC-DC adapter. -
Page 18: Using Battery Power
FROM YOUR BODY. 2.5.2 Using Battery Power The Pegasus is designed to work with a removable battery pack. The battery pack consists of a set of battery cells housed together. A fully charged pack will provide several hours of battery life, which can be further extended by using power management features through the BIOS setup. -
Page 19: To Remove The Battery Pack
PEGASUS User Manual roda ————————————————————————————— 2.5.4 To remove the battery pack: IMPORTANT! Only use battery packs and power adapters supplied with this 13.3” rugged notebook or specifically approved by the manufacturer or retailer for use with this model or else damage may occur to the 13.3”... - Page 20 PEGASUS User Manual roda ————————————————————————————— MAINTENANCE / SERVICE Page 20 of 23 —————————————————————————————...
-
Page 21: Bredenhop
Fax: +49 5744-944 475 E-Mai: support@roda-computer.com Note: The roda Service Center needs a detailed description of the problem and the serial number of the device. If it is necessary to send in your computer for repairs, you can download a service waybill (Service Supply Note) on the roda homepage (www.roda-computer.com), which you have to fill in. -
Page 22: Service Supply Note
PEGASUS User Manual roda ————————————————————————————— 3.2.1 Service Supply Note Include this sheet with the following information: Name Address Serial number, Customer number, Article number Place and date of purchase or the original invoice number Date of failure A DETAILED description of the problems you have encountered... -
Page 23: Downloads
PEGASUS User Manual roda ————————————————————————————— 3.2.2 Downloads Check our website (www.roda-computer-com) for downloads: Updates Drivers Manuals Service Supply Note Page 23 of 23 —————————————————————————————...
