Summary of Contents for Roda SolidPad LR11
- Page 1 SolidPad LR11 User´s manual...
- Page 2 ©2014 roda computer GmbH. All rights reserved. TRADEMARKS roda logo is a trademark of roda computer GmbH. Microsoft and the Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary ®...
-
Page 4: Table Of Contents
Lithium Battery Safety Statement ............... 6 Chapter 1. Introduction About This Guide ..................7 Unpacking the Device................. 7 Technical Specifications ................7 SolidPad LR11 Configuration Options ............9 Parts List ....................10 Identifying the Device ................11 Identifying the Digitizer ................15 Dimensions ....................16 Touch Screen Features ................17... - Page 5 Installation an Operating System...............39 BIOS Passwords ..................42 EC and BIOS.....................44 Chapter 5. Troubleshooting Troubleshoot the Wi-Fi Connection ............49 Troubleshoot Operating the Computer ............50 Call Product Support .................50 Chapter 6. Maintenance Cleaning the Device ..................51 Returning the Device .................51 Contacting roda ..................51...
-
Page 7: About This Manual
About This Manual The SolidPad LR11 User’s Manual provides instruction for qualified personnel to follow when setting up a new SolidPad LR11 device. This document is intended for use by qualified personnel to compliment the training and expertise, not to replace it. -
Page 8: Basic Safety Guidelines
The SolidPad LR11 is designed and manufactured according to strict controls and following the stated safety regulations. The following list identifies incorrect operating uses of the SolidPad LR11. Incorrect use of the SolidPad LR11 can lead to hardware damage, safety issues and possible risk to personnel health: The SolidPad LR11 is under operation by untrained personnel;... -
Page 9: Safety
Environmental Ambient Temperature The SolidPad LR11 operates on the basis of a passive cooling concept which internal waste heat is released via the housing surface and requires fresh airflow in the environment. Operating the SolidPad LR11 with no fresh cooling air may cause overheating and damage to the device. -
Page 10: Radio Transmissions
Cleaning and Servicing Disconnect the SolidPad LR11 from power before cleaning or servicing. Never clean the SolidPad LR11 with compressed air, a pressure washer or a vacuum cleaner. If necessary, clean the housing of the SolidPad LR11 with a damp cloth. -
Page 11: Lithium Battery Safety Statement
Consult the dealer or an experienced radio/ TV technician for help. Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. This device is operation in 5.15 – 5.25GHz frequency range, then restricted in indoor use only, Outdoor operations in the 5.15 –... -
Page 13: Chapter 1. Introduction
Embedded Standard 8 64bits About This Guide The SolidPad LR11 User Manual provides instruction for qualified personnel to use as a guide for setup of the device. This document is not intended to replace the training and expertise of the end- user. - Page 14 Introduction Item Description Wireless WLAN Wi-Fi IEEE 802.11 a/b/g/n/ac Bluetooth Bluetooth V4.0 WWAN (Optional) Option for 3.5G or 4G LTE Sensor Sensor Gyroscope, G Sensor, E-compass, Light Sensor Docking Connector 12-pin DC-IN Jack Micro SIM Card Slot MicroSD Slot Audio Jack x1;...
-
Page 15: Solidpad Lr11 Configuration Options
Range Storage Temperature -30°C (-22°F) to 70°C (158°F) Range Humidity 5-95% without condensation SolidPad LR11 Configuration Options The following options are available for the SolidPad LR11: NFC module Barcode reader Magnetic stripe reader Smart card reader High capacity battery Digitizer... -
Page 16: Parts List
Introduction Parts List The SolidPad LR11 is shipped with the following items. All other accessories are sold and ordered separately. For help, contact your local roda sales representative. See “Contacting roda” on page 47. SolidPad LR11 Power Adapter Digitizer 2-Point Carrying Handle... -
Page 17: Identifying The Device
Introduction Identifying the Device Overview Figure 1. Overview Table 2. Overview Item Description Left view See “Side View” on page 14 for further information. Front view See “Front View” on page 12 for further information. Rear view See “Rear View” on page 15 for further information. See “Side View”... - Page 18 Volume - Volume decrease. Volume + Volume increase. Power key Turns the SolidPad LR11 on or off. The power LED lights when the device is on or when the battery is Power LED being charged. F2 key Programmable function key.
- Page 19 Figure 3. Bottom View Table 5. Bottom View Item Description Docking connector 12 pin connector for docking onto a station. Kensington lock Lock the SolidPad LR11 to a stationary object for security. Pass-through Dual pass-through for WLAN, GNSS and WWAN.
- Page 20 Connect USB devices to the SolidPad LR11. Audio jack Connect a 3.5 mm jack for a headphone or external speakers. Ethernet Connect the SolidPad LR11 to an Ethernet (RJ-45) cable. DC-IN jack Insert power connector to charge battery. RS-232 Connect the SolidPad LR11 to a serial device.
-
Page 21: Identifying The Digitizer
Place digitizer here. Identifying the Digitizer You can use the digitizer to control your SolidPad LR11 as with a mouse or keyboard. The digitizer is not waterproof. Take care not to soak it or dip it in water. Click Button... -
Page 22: Dimensions
Introduction Dimensions The following image lists the device dimensions without add-ons (mm/inches). Figure 7. Front View Dimensions 2.3 / 0.9 2.3 / 0.9 Figure 8. Side View Dimensions... -
Page 23: Touch Screen Features
Introduction Touch Screen Features Always use the point of the digitizer for clicking or making strokes on the touch screen. Never use an actual pen, pencil, or sharp/abrasive object on the touch screen. The digitizer is used as if it were a pen or pencil. Touch the screen with the tip of the digitizer then remove the digitizer from the screen. -
Page 24: Chapter 2. Getting Started
Close the left I/O compartment cover. See “Closing the I/O Compartment Cover” on page Charging the Battery When you use the AC adapter to connect your SolidPad LR11 to a power outlet, the standard and external (optional) battery will automatically begin to recharge. -
Page 25: Powering The Device On And Off
Powering the Device On and Off Powering On the Device Only power on the SolidPad LR11 after connecting all of the peripherals and cabling. Press and hold the power button until the screen lights. The device runs through the start up sequence and powers up. -
Page 26: Installing The Micro Sim Card
Getting Started Powering Off the Device Start screen: > Shut down. Desktop screen: Tap and hold at the bottom left corner of the Desktop screen. Tap Shut down or sign out > Shut down. Both Start screen and Desktop screen: Display charm bar and tap Settings. -
Page 27: Removing The Micro Sim Card
Getting Started Take the micro SIM card from its packaging. The micro SIM card has a corner missing. Align the SIM card with the slot making sure that the corners match. Insert the micro SIM card and press it in until an audible click sounds. Figure 15. -
Page 28: Installing The Microsd Card
Getting Started Press the micro SIM card in and release it. The card springs out. Grasp the micro SIM card and remove it from the slot. Figure 17. Removing the Micro SIM Card Close the left I/O compartment cover. See “Closing the I/O Compartment Cover” on page Installing the MicroSD Card The device supports microSD card for easier data storage. -
Page 29: Removing The Microsd Card
Getting Started The microSD card has a beveled edge. Align the microSD card with the slot making sure that the corners match. Insert the microSD card and press it in until an audible click sounds. Figure 19. Installing the MicroSD Card Close the left I/O compartment cover. -
Page 30: Using The Digitizer
Getting Started Press the microSD card in and release it. The card springs out. Grasp the microSD card and remove it from the slot. Figure 21. Removing the MicroSD Card Close the left I/O compartment cover. See “Closing the I/O Compartment Cover” on page Using the Digitizer Following the information below when using a digitizer: Use only the included digitizer to touch the screen. -
Page 31: Removing The Protective Film From The Display
Removing the Protective Film from the Display The front display of the SolidPad LR11 is protected during transport by a transparent film. This film should remain on the front display during assembly to avoid damage to the front display surface. -
Page 32: Chapter 3. Operation
Operation Chapter 3. Operation Opening the I/O Compartment Cover Place the device display side down on a clean work surface. Locate the I/O compartment cover. Left view Right view Right I/O Compartment Cover Left I/O Compartment Cover Figure 23. Side View: Locating the I/O Compartment Cover Unlock the latch. -
Page 33: Closing The I/O Compartment Cover
Operation Closing the I/O Compartment Cover Place the device display side down on a clean work surface. Locate the I/O compartment cover. Left view Right view Right I/O Compartment Cover Left I/O Compartment Cover Figure 26. Side View: Locating the I/O Compartment Cover Flip the I/O compartment cover and install. -
Page 34: Connecting To External Cabling
Connect USB Cabling The SolidPad LR11 have one USB port for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB port support USB 2.0 or USB 3.0 devices. Open the left I/O compartment cover. See “Opening the I/O Compartment Cover” on page Connect to USB device via USB cable. - Page 35 Connect to HDMI devices via micro HDMI cable. Open the left I/O compartment cover. See “Opening the I/O Compartment Cover” on page Connect micro HDMI cable to micro HDMI port on the SolidPad LR11. ON OFF Figure 32. Connect Micro HDMI Cabling...
-
Page 36: Handstrap And Shoulder Strap
Figure 33. Connect RS-232 Cabling Handstrap and Shoulder Strap The SolidPad LR11 is equipped with a handstrap and a shoulder strap to provide users safety use. For more information, see “Connecting the Handstrap” on page 30 and “Connecting the Shoulder Strap” on page 30. -
Page 37: Removing The Standard Battery
Operation Locate the battery. Locking Switch Release Button Battery Figure 34. Rear View: Locating the Battery Align the tabs on the battery with the slots on the chassis. Angle the battery in place and set the tabs in the chassis slots. Lower the raised end of the battery and press in place until an audible click is heard. - Page 38 Operation Locate the battery. Locking Switch Release Button Battery Figure 37. Rear View: Locating the Battery Slide the locking switch on the top-left side to the unlock position. Figure 38. Unlock the Battery...
-
Page 39: Connecting To A Wireless Network
Press in the clips to release them from the metal loop. Remove the clips. Metal Loop Figure 41. Removing the Carrying Handle Connecting to a Wireless Network Before you can make use of the SolidPad LR11 wireless functions, you need to connect to a... - Page 40 Operation network. The following is a set of procedures for connecting to a wireless network. Before beginning, make sure your Wi-Fi setting is enabled and you are within range of a wireless network. If your Wi-Fi setting is disabled, proceed to step 2. Look at the Network icon located at the right side of the taskbar.
-
Page 41: Chapter 4. Using Bios Setup Utility
To run the BIOS Setup Utility, use the following procedures: Perform one of the following: If the SolidPad LR11 is powered off Press the Power button to start up the device. The power LED lights. Quickly press and hold the Windows Home key until the BIOS Post screen displays. -
Page 42: Installation An Operating System
Using BIOS Setup Utility Due to the device’s fast boot up and boot down time, there is only a small time frame of a few seconds between the release of the Power button and the opportunity to press the Windows Home key. - Page 43 Using BIOS Setup Utility Tap Yes to enable CSM support. Figure 44. Main > Boot Features Step 2: Advanced > Miscellaneous Configuration Save the Settings After you configure BIOS, you will need to save the settings.
- Page 44 Using BIOS Setup Utility Navigate to APP Menu > Exit and tap Exit Saving Changes. Figure 45. Exit the BIOS Utility A prompt display, tap Yes to save the configuration. The BIOS settings are configured and the Windows 7 operating system can be installed.
-
Page 45: Bios Passwords
Using BIOS Setup Utility BIOS Passwords Setting Up a Supervisor Password To setup a supervisor password, follow the procedure as described: Go to APP Menu > Security > Account’s Password Status. Tap the Enter icon next to Setup the Supervisor Password to access the virtual keyboard. Figure 46. - Page 46 Using BIOS Setup Utility Verification of the password is required. Tap the same password again and tap Enter to confirm the new password. Navigate to APP Menu > Exit. Figure 48. Exit Screen Tap Exit Saving Changes to display the confirmation screen. Tap Yes to save the new configuration settings.
-
Page 47: Ec And Bios
Contact your technical sales or technical representative to obtain the correct BIOS file. Copy the BIOS file on to the USB device. Connect the USB device to one of the device’s USB ports and power on the SolidPad LR11. A USB keyboard is required for entering command. - Page 48 Using BIOS Setup Utility Tap Change PC settings. Figure 50. Change PC Settings From the PC settings menu, tap Update and recovery to continue. Figure 51. Update and Recovery...
- Page 50 Using BIOS Setup Utility From the Update and recovery screen, tap Recovery. The Advanced startup option displays. Figure 52. Recovery Under Advanced startup, tap Restart now. Figure 53. Restart Now...
- Page 51 Figure 54. Use a Device 11. From the Use a device menu, tap Internal Shell to open the command screen. Make sure connect the SolidPad LR11 to the AC adapter to prevent a sudden loss of power. Figure 55. Internal Shell...
- Page 52 The BIOS is now updated. Updating EC Connect the SolidPad LR11 to the AC adapter to prevent a sudden loss of power. Updating EC requires the use of the Internal Shell Command menu, refer to steps 1 to 12 of “Updating BIOS”.
-
Page 53: Chapter 5. Troubleshooting
If you send the computer in for service, it is your responsibility to save the computer data and configuration. roda is responsible only for ensuring that the hardware matches the original configuration when repairing or replacing the computer. -
Page 54: Troubleshoot Operating The Computer
The computer appears to be locked up and you cannot enter data. Restart the computer. Call Product Support Simple instructions please contact the dealer, contact roda representative, or leave a message visit the roda website at www.roda-computer.com. To better assist you have the following information ready:... -
Page 55: Chapter 6. Maintenance
Chapter 6. Maintenance Cleaning the Device Danger to electric shock when cleaning or maintaining the SolidPad LR11. To avoid electric shock, turn the SolidPad LR11 off and disconnect it from the power supply before cleaning or maintaining it. Housing The housing of the SolidPad LR11 is best cleaned with a damp cloth.
