Ultra High Definition LED
ORION CO.,LTD.
www.oriondisplay.net
Address: 257-6, Gongdan-dong, Gumi-si, Gyeongsangbuk-do, Korea
Tel : +82-2-6678-8533,
Fax: +82-2-6678-8599
User's Manual
Thank you for purchasing this product.
Please read this manual thoroughly prior to install the product for your safety.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OLS-8410NL and is the answer not in the manual?

Questions and answers

Related Manuals for Orion OLS-8410NL

Summary of Contents for Orion OLS-8410NL

  • Page 1 Ultra High Definition LED ORION CO.,LTD. www.oriondisplay.net Address: 257-6, Gongdan-dong, Gumi-si, Gyeongsangbuk-do, Korea Tel : +82-2-6678-8533, Fax: +82-2-6678-8599 User’s Manual Thank you for purchasing this product. Please read this manual thoroughly prior to install the product for your safety.

  • Page 2: Important Safety Instructions

    Features ▶ Enjoy a wide flat screen with high brightness and high quality. ▶Easy to install and move due to its thin design ▶ Enjoy your favorite programs with various split-screen features simultaneously presenting several Notice to users programs. Class A digital device It is a device designed for business purpose with a safety certificate for electromagnetic interference, which user should be mindful of.

  • Page 3: Table Of Contents

    Content 01. Cautions ............................................4 ▶ Cautions for System installation............................4 ▶ Application information ................................5 CAUTION ▶ Clearance for Ventilation................................6 ▶ Do not cover the vent hole for the fan ..........................7 RISK OF ELECTRIC SHOCK ▶ Cleaning and Maintenance ..............................7 DO NOT OPEN 02.

  • Page 4: Cautions

    12:05 On time JA 032 12:05 Beijing On time possible service occasion in the future. - Scroll the characters periodically. - The sliding Universal Unit of ORION is recommended for easier service. DEPARTURE DEPARTURE DEPARTURE DEPARTURE Flight No. Time Gate Flight No.

  • Page 5: Clearance For Ventilation

    ▶ ▶ Clearance for Ventilation Do not cover the vent hole for the fan - When you install product, make sure there is at least 20cm clearance for effective - Carefully install product not to cover the fan air holes with any structural object. ventilation and do not seal off...

  • Page 6: Safety Precautions

    Safety Precautions • If it operates abnormally, stop using it • Do not pull out or hang down the • Do not place any liquid-containing • Do not put any foreign material into • Do not lean against the product or keep • Do not put it at any place with much immediately.

  • Page 7: Names

    Names ▶ ▶ Front Input Ports AC INPUT ON/OFF HDMI1A HDMI2A HDMI1B HDMI2B HDMI1C HDMI2C HDMI1D HDMI2D RS232 PWR SRC MODE ▶ Rear AC INPUT ON/OFF HDMI1A HDMI2A HDMI1B HDMI2B HDMI1C HDMI2C HDMI1D HDMI2D RS232 ➊ ➋ ➌ ➍ ➎ ➏...

  • Page 8: Key Pad

    ▶ ▶ KEY PAD Remote Controller POWER ON : POWER OFF : Turn on the display. Turn o the display. AC INPUT ON/OFF HDMI1A HDMI2A HDMI1B HDMI2B HDMI1C HDMI2C HDMI1D HDMI2D RS232 PWR SRC MODE EXIT : INFO : Exit from MENU & Display the resolution ➐...

  • Page 9: Cable Connection

    Cable Connection • Do not connect or disconnect the signal cables while the display and the peripheral devices are turned on. • The power must be turned off before connecting the signal cables or the peripheral devices. • The power cord must be firmly inserted to prevent unexpected disconnection. IR Reception AC INPUT ON/OFF...

  • Page 10: How To Use Remote Controller

    How to use Remote Controller 1. MENU button 5. UHD button ‚ OSD MENU will be displayed by pressing MENU button. ‚ Input A, Input B, Input C and Input D will be displayed on the screen simultanesously. 2. 2. Direction buttons for movement     6.

  • Page 11: Con Guration

    Con guration  ▶ PICTURE Adjustment BRIGHTNESS ADJUSTMENT Ÿ Screen brightness can be adjusted. Ÿ BRIGHTNESS, CONTRAST, TINT, COROR, VIDEO MODE, and PICTURE RESET can be Ÿ The brightness of black color at the dark side of the screen can be adjusted. adjusted in the PICTURE MENU.

  • Page 12: Tint Adjustment

    ▶ VIDEO MODE SELECTION ▶ TINT ADJUSTMENT Ÿ Adjust the color temperature of the screen. 1. Select VIDEO MODE from PICTURE Menu. Ÿ Adjust Red and Green color of the screen. ‚ Select VIDEO MODE and move   buttons to select a VIDEO MODE of your choice 1.

  • Page 13: Picture Reset

    ▶  PICTURE RESET SCREEN ADJUSTMENT Ÿ Initialize the values of PICTURE NENU. Ÿ H POSITION, V POSITION, ASPECT RATIO, VIDEO MUTE, SCREEN MODE, and SCREEN RESET can be adjusted in the SCREEN MENU. 1. Select PICTURE RESET from PICTURE menu. ‚...

  • Page 14: H Position

    ▶ ▶ H POSITION ASPECT RATIO Con guration Ÿ Adjust the horizontal position of the display image on the screen. Ÿ Adjust screen ratio. Ÿ FULL – All the input will be displayed with the screen ratio of 16:9. 1. Select H POSITION from SCREEN menu. Ÿ...

  • Page 15: Video Mute

    ▶ ▶ VIDEO MUTE SCREEN RESET Adjustment Ÿ Display the input image on the screen. Ÿ Initialize the values of SCREEN MENU. Ÿ ON- Display on the screen 1. Select SCREEN RESET from SCREEN menu . Ÿ OFF- No screen display (Black screen) ‚...

  • Page 16: Auto Power Con Guration

     ▶ SETUP A Con guration AUTO POWER Con guration Ÿ The display set can be turned on automatically as the power is on. Ÿ AUTO POWER, DISPLAY MODEL, FIRMWARE VERSION, LAN SETTING, SERIAL Ÿ ON – Select the function for automatic turn on. SETTING, OSD, and SETUP A RESET can be adjusted in SETUP A MENU.

  • Page 17: Firmware Con Guration

    ▶ ▶ FIRMWARE Con guration BAUD RATE Con guration Ÿ It displays the rmware version information. Ÿ It adjusts the communication rate to control the set via RS-232C. 1. Select FIRMWARE from SETUP A menu. 1. Select BAUD RATE from SETUP A menu. ‚...

  • Page 18: Osd Con Guration

    ▶ OSD Con guration 2. Select the sub-items of TURN OFF ‚ Select the duration time for OSD CONTRON MENU or TURN OFF Ÿ It con gures OSD menu. 1. Select OSD from SETUP A menu. ‚ Move to OSD and press MENU button. 3.
  • Page 19 » » OSD POSITION Con guration INFO DISPLAY Con guration Ÿ H POSITION – Select the horizontal position of OSD. Ÿ INFO DISPLAY - Select the duration time of INFO OSD. Ÿ V POSITION - Select the vertical position of OSD. 1.

  • Page 20: Setup A Reset Con Guration

    ▶  SETUP A RESET Con guration SETUP B Adjustment Ÿ Initialize the previously adjusted values of SETUP A RESET MENU. Ÿ INFORMATION, POWER ON SOURCE, SETUP B RESET, and FACTORY RESET can be adjusted in SETUP B MENU. 1. Select SETUP A RESET from SETUP A menu. 1.

  • Page 21: Power On Source Con Guration

    ▶ ▶ POWER ON SOURCE Con guration KEY LOCK Con guration Ÿ Select the default input source for power on. (Default: HDMI 1A) Ÿ It restricts key strokes to prevent any of expected set activities. Ÿ OFF – Display the input source right before power o . Ÿ...

  • Page 22: Setup B Reset Con Guration

    ▶ ▶ SETUP B RESET Con guration FACTORY RESET Con guration Ÿ Initialize the previously adjusted values of SCREEN B MENU. Ÿ Initialize the previously adjusted values of the set to the factory level. Every con guration will be initialized. 1.

  • Page 23: User Guide For Uhd Graphic

    User guide for UHD Graphic  • This display supports UHD (Ultra High Definition; Resolution 3840 X 2160) resolution. Cable connection • This display unit can display UHD images by collecting 4 different FHD (Full High Definition; Resolution 1920 X 1080) input simultaneously from a PC that can make 4 separate FHD output. •...
  • Page 24 • Please refer to the user guide of each graphic card maker or contact to the company for detailed usage of the graphic card. • The configuration for the optional ORION PC is as follows. • As you connect the output ports of the PC to the input ports in the display, you will see the following screen.
  • Page 25 Duplicating Display • Click the display No. 2 in the “Display selection part” with the right button of your mouse to popup the window and select “Duplicate.” • Select “Creating and Arranging Desktops” from the menu bar on the left after executing CCC. •...
  • Page 26 • When you see the massage “Please select a desktop to duplicate” on the screen as shown below, select • The screen will be turned off for a moment and turned on. the display No. 1 in the “Desktop layout part.” •...
  • Page 27 • When you see the massage “Please select a desktop to duplicate” on the screen as shown below, select • The screen will be turned off for a moment and turned on. the display No. 1 in the “Desktop layout part.” •...
  • Page 28 • Since the display No. 1 is left to duplicate, the window for selecting the display for duplication will not be • All the displays are duplicated as the display No. 1. popped up and the following caution window will be displayed. Then select “Continue” •...
  • Page 29 Eye nity Con guration • Then you will have the window for selecting layout as shown below. • You can select “4displays (4X1)” or “4displays (2X2).” Select “4displays (2X2)” and click “Accept.” • This is the Eyefinity configuration for combining the desktop as one screen. •...
  • Page 30 • If it is not correct, the screen can be arranged in disorder as shown below. The following screen image is • Concurrently, CCC window will be displayed as shown below. • If the arrangement is correct, select “Yes.” an example and the incorrect arrangement can be vary. •...
  • Page 31 • In case you select “No,” follow the display arrangement procedure as shown below. • Simultaneously, one of 4 displays is turned on with blue color. -58- -59-...
  • Page 32 • Click the position of the display of blue color in the “Desktop layout part” in CCC. • When the display arrangement is completed and the screen is correctly displayed, click “Done.” • Then the other one of 4 displays is turned on with blue color again. In the same manner, click the position of the display of blue color in the “Desktop layout part”...
  • Page 33 • The next procedure is “Bezel Compensation.” Since it is not a necessary procedure, click “No.” • Then all configurations for CCC are completed. The desktop with UHD resolution will be displayed as shown below. -62- -63-...

  • Page 34: Protocol

    Explanation 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte Variable Ex) OLS-8410NL 10 Byte Display Model 0x4F 0x4C 0x53 0x2D 0x38 0x34 0x31 0x30 0x4E 0x4C Group ID Multi ID Other Data 1 byte 1 byte N byte Ex) 0.80.01A.O...
  • Page 35 - Send To LCD - Receive From LCD Data Data 　 Ex CMD Length 　 Ex CMD Length Check Sum Group ID Multi ID Mode Control Group ID Multi ID Mode 0x02 0x10 0x01 0x04 0x03 0x02 0x1A 0x01 0x03 0x03 Value Variable...
  • Page 36 *Mode : Read(Get)Response – 0x00(0), Write(Set)Response – 0x02(2) - Receive From LCD *Control : 0x00(0) ~ 0x64(100) Data *Check Sum: Execute "Not" operation after adding all the values in "STX~Data" area. 　 Ex CMD Length Check Sum Group ID Multi ID Mode Control 4.5.
  • Page 37 *Control Value : 0x00(0)~0x64(100) - Send To LCD *Check Sum: Execute "Not" operation after adding all the values in "STX~Data" area. Data 　 Ex CMD Length 5.2. V Position Group ID Multi ID Mode Control 0x02 0xB7 0x01 0x04 0x03 Value Variable Variable...
  • Page 38 *Control Value : <Model Name> 10 characters, It is displayed as ASCII value. Ex) OLS-8410NL : 0x4F 0x4C 0x53 0x2D 0x38 0x34 0x31 0x30 0x4E 0x4C , - This is the command for con guring IP Address (DHCP Disable), Subnet Mask, Default Gateway, DNS Primary, and DNS Secondary to allocate the <Serial Num>...
  • Page 39 *Group ID/Multi ID range(Program) : Group ID : 0x01 / Multi ID : 0x01 Fixed - Send To LCD *Mode : Write(Set) – 0x02(2) Data * Control Value: The ranges of each 1Byte of IP Address, Subnet Mask, Default Gateway, DNS Primary, or DNS Secondary are from 0(0x00) to 　...
  • Page 40 *Group/Multi ID Range(Program) : Group ID : 0x01 / Multi ID : 0x01 Fixed *Group/Multi ID Range(Program) : Group ID : 0x01 / Multi ID : 0x01 Fixed *Mode : Read(Get) – 0x00(0) *Mode : Read(Get)Response – 0x00(0), Write(Set)Response – 0x02(2) *Control Value: The value for OFF is 0(0x00) and the duration can be selected between 3(0x03) and 10(0x0A).
  • Page 41 *Group/Multi ID Range(Program) : Group ID : 0x01 / Multi ID : 0x01 Fixed 8. Factory Control Command *Mode : Write(Set)Response – 0x02(2) 8.1. Dimming Control *Control : Input Source con guration 0x10 is for the last input source at the time of the last Power O . 0x11(HDMI1A), 0x12(HDMI1B), 0x13(HDMI1C), 14(HDMI1D), - This is the command for controlling the brightness of LCD back light.

  • Page 42: Before Calling For Service

    Before calling for service Applicable signals • Before calling for any repair, check the following and then refer to a near A/S center. Horizontal [Pixels] Vertical [Lines] Pixe ▶ "Tick" sound from the main body. Polarity Standard Resolution Clock (H/V) Type [Mhz] •...

  • Page 43: Speci Cation

    Speci cation ▶ ▶ Product Touch Model Name OLS-8410NL OLS-8410T6LG OLS-8420NL Item Description Back Light Type Touch Technology PulseIRTM Technology Power Supply AC100V ~ 240V (50/60Hz) Finger, gloved hand or Any other pointer, Touch Method 470W Stylus minimum Ø 8mm...

  • Page 44: Dimension

    Dimension ▶ ▶ OLS-8410NL/OLS-8420NL OLS-8410T6L 1917 1977.2 55.3 55.3 1917 1977.2 104.3 50.5 60.3 -84- -85-...
  • Page 45 Memo -86-...
