Doc. No.
DOC-00051810
REV.
HTC Corporation.
Issued Date
2008/12/29
AX02
.
Revised Date
2009/01/14
Page
1 of 91
Doc. Title
Sapphire Service Manual
Sapphire
Service Manual
HTC Proprietary
U
Confidential Treatment Requested
Rev. AX02
HTC Corporation.
Engineering Mobility
HTC CONFIDENTIAL
SM-TP008-1125

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sapphire and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HTC Sapphire

Summary of Contents for HTC Sapphire

  • Page 1 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 1 of 91 Doc. Title Sapphire Service Manual Sapphire Service Manual HTC Proprietary Confidential Treatment Requested Rev. AX02 HTC Corporation. Engineering Mobility HTC CONFIDENTIAL SM-TP008-1125...
  • Page 2 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 2 of 91 Doc. Title Sapphire Service Manual REVISION CONTROL TABLE DATE CONTENTS DEPT REVISED STAGE AX01 2008/12/29 Fist Draft Marc AX02 2009/01/14 Add product picture at page 1...

  • Page 3: Table Of Contents

    REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 3 of 91 Doc. Title Sapphire Service Manual 1. INTRODUCTION ..................................4 1.1 P ...............................5 RODUCT EATURES 1.2 P ...............................7 RODUCT OVERVIEW 2. DEVICE DISASSEMBLING AND ASSEMBLING PROCEDURE ................13 2.1 D ............................13...

  • Page 4: Introduction

    Page 4 of 91 Doc. Title Sapphire Service Manual 1 Introduction This manual provides the technical information to support the service activities of this product. This document contains highly confidential information, so any or all of this document should not be revealed to any third party.

  • Page 5: Product Features

    Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 5 of 91 Doc. Title Sapphire Service Manual Product Features HTC CONFIDENTIAL SM-TP008-1125...
  • Page 6 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 6 of 91 Doc. Title Sapphire Service Manual HTC CONFIDENTIAL SM-TP008-1125...
  • Page 7 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 7 of 91 Doc. Title Sapphire Service Manual HTC CONFIDENTIAL SM-TP008-1125...

  • Page 8: Product Overview

    Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 8 of 91 Doc. Title Sapphire Service Manual Product overview Front side Accessories HTC CONFIDENTIAL SM-TP008-1125...
  • Page 9 DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 9 of 91 Doc. Title Sapphire Service Manual ITEM FUNCTION AC ADAPTER RECHARGES THE BATTERY. CONNECTS TO A PC AND SYNCHRONISES USB SYNC CABLE DATA. HTC CONFIDENTIAL SM-TP008-1125...
  • Page 10 2009/01/14 Page 10 of 91 Doc. Title Sapphire Service Manual Install the SIM card Make sure your device is turned off. Press the back cover latch down and gently slide the back cover towards yourself. Once the back cover pops out, remove it by lifting it up from the bottom end.
  • Page 11 2009/01/14 Page 11 of 91 Doc. Title Sapphire Service Manual Install the SD card If you need more storage for your device, you can install an SD card into the slot on the upper part of the device. To install the SD card, gently insert the card into the slot (with its gold contacts facing down) until it snaps in place.
  • Page 12 Revised Date 2009/01/14 Page 12 of 91 Doc. Title Sapphire Service Manual To perform a soft reset • Use the stylus to press the RESET button found on the back of the device. Your device restarts and displays the Today screen.

  • Page 13: Device Disassembling And Assembling Procedure

    HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 13 of 91 Doc. Title Sapphire Service Manual 2 Device Disassembling and Assembling Procedure 2.1 Disassembling procedure 1. P HILLIPS SCREW DRIVER 2. F LAT PLASTIC STICK (P/N:RTT-00006) 3. C LEANING CLOTH 4.
  • Page 14 2008/12/29 AX02 Revised Date 2009/01/14 Page 14 of 91 Doc. Title Sapphire Service Manual Unfasten the screws at the location indicated. Remove the antenna by inserting the plastic stick in to the gap Use the flat plastic stick to slide...
  • Page 15 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 15 of 91 Doc. Title Sapphire Service Manual Disassemble speaker from keyboard bottom cover. Unfasten the screws at the location indicated HTC CONFIDENTIAL SM-TP008-1125...
  • Page 16 DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 16 of 91 Doc. Title Sapphire Service Manual Disassemble connector from the Main board. Disconnect Vibrator cable Disconnect the FPC connector from the Upper board. HTC CONFIDENTIAL SM-TP008-1125...
  • Page 17 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 17 of 91 Doc. Title Sapphire Service Manual Unfasten the screws at the location indicated Turn over the upper board. 13. Disassemble the cable. 14. Disconnect volume FPC from Rigid-Flex board. HTC CONFIDENTIAL...
  • Page 18 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 18 of 91 Doc. Title Sapphire Service Manual 15. Remove the volume FPC from the chassis 16. Disassemble the camera module from the upper board. 17. Disconnect the AP key FPC connector...
  • Page 19 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 19 of 91 Doc. Title Sapphire Service Manual Disconnect the Rigid-Flex board connector form the Main board as shown.(1) Use the white stick to separate it Unfasten the screws at location indicated (blue) 21.
  • Page 20 2008/12/29 AX02 Revised Date 2009/01/14 Page 20 of 91 Doc. Title Sapphire Service Manual 22. Remove the Main Board from Chassis 23. Unplug the cable from the Main Board. Remove the Mylar Release the hook from the Main Board to separate the...
  • Page 21 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 21 of 91 Doc. Title Sapphire Service Manual 26. Remove the Microphone Rubber 27. Remove Receiver from Chassis. Remove the AP key FPC from Chassis as shown. HTC CONFIDENTIAL...
  • Page 22 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 22 of 91 Doc. Title Sapphire Service Manual Start from the top two corners and Press LCM along the two sides of it to separate the LCM. Disassembly Completed HTC CONFIDENTIAL SM-TP008-1125...

  • Page 23: Assembling Procedure

    Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 23 of 91 Doc. Title Sapphire Service Manual 2.2 Assembling procedure Remove the protect film on the LCM and Combine it will Bezel. Attach the receiver to Chassis. Insert the switch hook...
  • Page 24 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 24 of 91 Doc. Title Sapphire Service Manual Remove the release paper and stick AP key FPC on the Chassis as shown Connect the cable with the Main board HTC CONFIDENTIAL SM-TP008-1125...
  • Page 25 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 25 of 91 Doc. Title Sapphire Service Manual Combine the FPC with Main Board Fasten the screws at the location indicated Screw:72H01266-01M*2 : 1.0+-0.1 ORQUE Connect Main FPC with HTC CONFIDENTIAL...
  • Page 26 2008/12/29 AX02 Revised Date 2009/01/14 Page 26 of 91 Doc. Title Sapphire Service Manual Stick the copper foil as location indicated 11. Stick the Rigid-Flex Board on the Main Board Combine the Rigid-Flex board with Main board and stick Rigid-Flex at...
  • Page 27 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 27 of 91 Doc. Title Sapphire Service Manual Install the Camera module on the Upper board Connect the cable 15. Insert the volume FPC into the connector on the upper board. HTC CONFIDENTIAL...
  • Page 28 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 28 of 91 Doc. Title Sapphire Service Manual 16. Attach the Volume FPC to the Chassis Combine Main FPC upper board as show 18. Fasten the screws at the location indicated Screw: 72H01266-01M Torque : 1.0+-0.1kgf-c...
  • Page 29 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 29 of 91 Doc. Title Sapphire Service Manual Insert vibrator as shown Combine LCM FPC with Main-Board as shown. 21. Fasten two screws as shown 72H01266-00M Screw: Torque : 0.8+-0.1kgf-c...
  • Page 30 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 30 of 91 Doc. Title Sapphire Service Manual Attach the speaker to the Housing. Combine Housing with Bezel 24. Combine the antenna with Housing as shown HTC CONFIDENTIAL SM-TP008-1125...
  • Page 31 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 31 of 91 Doc. Title Sapphire Service Manual 25. Fasten the screw as location indicated Torque : 1.0+-0.1kgf-c Insert battery into housing. Assemble the Battery Cover HTC CONFIDENTIAL SM-TP008-1125...

  • Page 32: Rom Re-Flash Procedure

    AX02 Revised Date 2009/01/14 Page 32 of 91 Doc. Title Sapphire Service Manual 3 ROM Re-flash Procedure 3.1 ROM upgrade thru RUU (Re-flash Upgrade Utility) Connect device to PC Setting and allow USB connections in Microsoft ActiveSync. Connect your device and desktop/ or laptop via USB cable.
  • Page 33 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 33 of 91 Doc. Title Sapphire Service Manual RUU - 1 III. Read the pop-up message form ROM update utility and select the “I understand…” checkbox. Click “Next” to proceed. RUU - 2...
  • Page 34 2008/12/29 AX02 Revised Date 2009/01/14 Page 34 of 91 Doc. Title Sapphire Service Manual RUU - 4 IX. Double verify the ROM revision which you want to update before re-flash procedure. Click “Next” to proceed. RUU - 5 XI. Read the information from pop-up...
  • Page 35 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 35 of 91 Doc. Title Sapphire Service Manual RUU - 7 XIV. The OS upgrade is finished, click “Finish” to close the utility. HTC CONFIDENTIAL SM-TP008-1125...

  • Page 36: Rom Image Upgrade Thru Sd Card

    Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 36 of 91 Doc. Title Sapphire Service Manual 3.2 Rom Image upgrade thru SD card Download ROM Image from SDO Download ROM image from SDO. http://htcscm10.htc.com.tw /SDO Un-zip the image file. Format SD card and copy image file to SD card III.
  • Page 37 2008/12/29 AX02 Revised Date 2009/01/14 Page 37 of 91 Doc. Title Sapphire Service Manual SD Upgrade - 2 VIII. Reading source code from SD card. [Note]: This process will takes 10 mins, please don’t power off the device. After finish, press Action button to reboot.

  • Page 38: Diagnostic Program

    HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 38 of 91 Doc. Title Sapphire Service Manual 4 DIAGNOSTIC PROGRAM 4.1 List of Diagnostic / WinCE Test Items Mode No Item Description Remark Function Test Auto Regular Tests (SD card, Vibrator, Display, B.L, 1 Auto etc…)
  • Page 39 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 39 of 91 Doc. Title Sapphire Service Manual Calibration Test (Perform WLAN calibration) Compass Test Battery Test (1H) Battery info. 1 USB Test USB link test 2 Camera Test Camera test...
  • Page 40 Page 40 of 91 Doc. Title Sapphire Service Manual Test Procedure How to select test item: Using navigation button -"Up" or "Down" to select the test items How to execute the test program: Press “Action” button to start each of test items.
  • Page 41 AX02 Revised Date 2009/01/14 Page 41 of 91 Doc. Title Sapphire Service Manual SD card Test Insert the SD card and follow the system instruction to do the test. If success, press Action key to next or return to Function test menu.
  • Page 42 Revised Date 2009/01/14 Page 42 of 91 Doc. Title Sapphire Service Manual Display Test (Green / Blue pattern) Press Action key to continue the next test pattern. Display Test ( Black / White pattern) Press Action key to continue the next test pattern.
  • Page 43 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 43 of 91 Doc. Title Sapphire Service Manual LED Test Press Action key and follow the instruction on screen to perform the LED inspection test (Green, Red, Blue, UI LED and Key LED) Press Action key to next or return to Function test menu.
  • Page 44 2008/12/29 AX02 Revised Date 2009/01/14 Page 44 of 91 Doc. Title Sapphire Service Manual Sliding Test Press Action key to select Sliding Test on Function test menu. Follow the instruction on screen to open and close the key pad. perform III.
  • Page 45 AX02 Revised Date 2009/01/14 Page 45 of 91 Doc. Title Sapphire Service Manual Headset Audio Test Press “B” key or select Headset Audio Test on Function test menu. Insert the headset and speaking. III. You can hear the sound output from the headset.
  • Page 46 2008/12/29 AX02 Revised Date 2009/01/14 Page 46 of 91 Doc. Title Sapphire Service Manual Android Test Test Requirement: - 3G SIM card - Google account Sign in Insert the 3G SIM card. Signing in the Google account and enter to the system.
  • Page 47 Revised Date 2009/01/14 Page 47 of 91 Doc. Title Sapphire Service Manual USB Test Select to use your memory card as USB mass storage when your phone is connected to your computer (selected by default or press Menu>Settings>SD card & phone storage>Use for USB storage)
  • Page 48 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 48 of 91 Doc. Title Sapphire Service Manual GPS Test Press Menu button and tap the icon “Settings”. Select “Security & location”. III. Select My Location settings to “GPS satellites”. IV. Tap the application tab and press the Maps icon to enter to the Google Map.
  • Page 49 2008/12/29 AX02 Revised Date 2009/01/14 Page 49 of 91 Doc. Title Sapphire Service Manual WLAN Test Press Menu button and tap the icon “Settings”. Select “Wireless controls” > select the “Mobile networks” > select “USE only 2G networks” check box.
  • Page 50 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 50 of 91 Doc. Title Sapphire Service Manual RF Test Press Call Button to dial for performs the RF test. Also you can test by mobile tester. Erase all test data Before shipping you should erase all test data on the phone.

  • Page 51: Power Measurement Test

    2009/01/14 Page 51 of 91 Doc. Title Sapphire Service Manual Power measurement test 4.2 Main board leakage current Test Procedure This is a quick method to measure if any abnormal leakage current on main board which caused high power consumption compare to GOOD main board.
  • Page 52 Connect control box and jig through 4 colors cable Set up each button by row A~D according to product specification Following is an example for Sapphire It means, press button A=0,B=8,C=X,D=0 (X=Don’t care, the Dream battery only 3 pins) HTC CONFIDENTIAL...
  • Page 53 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 53 of 91 Doc. Title Sapphire Service Manual Install the jig to device Start testing Turn on control box power button Press power button to turn on the Device HTC CONFIDENTIAL SM-TP008-1125...

  • Page 54: Idle Current Test

    AX02 Revised Date 2009/01/14 Page 54 of 91 Doc. Title Sapphire Service Manual Idle current test 1. Set the device to airplane mode. 2. Set the brightness to minimum(Press MENU>Settings>Sound & display>Brightness) Measure the idle mode current. The idle current value must under 70mA.
  • Page 55 2009/01/14 Page 55 of 91 Doc. Title Sapphire Service Manual Conclusion: If current consumption is passed at both of flight and power off mode, it means M/B is GOOD. If there is any item FAILED at flight or power off mode, it means M/B is failed, please replace M/B for repair.

  • Page 56: Battery Rundown Test Procedure

    Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 56 of 91 Doc. Title Sapphire Service Manual 4.3 Battery rundown test procedure Battery Test Turn the device power off and insert Diagnostic SD card. Press and hold Capture button, then press...
  • Page 57 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 57 of 91 Doc. Title Sapphire Service Manual After one hour, check the test result. VI. If the capacity is under 70%, please replace a new battery. HTC CONFIDENTIAL SM-TP008-1125...

  • Page 58: Cosmetic Inspection Criteria

    2009/01/14 Page 58 of 91 Doc. Title Sapphire Service Manual 5 Cosmetic Inspection Criteria 5.1 Classes definition of inspective area Class A area => The front side of main unit involve all buttons and LED lens except LCD. Class C area => 4 sides and back views of main unit.

  • Page 59: Display Inspection

    Revised Date 2009/01/14 Page 59 of 91 Doc. Title Sapphire Service Manual IT IS GENERIC COSMETIC INSPECTION CRITERIA FOR ALL PRODUCTS IF THERE HAVE ANY CONFLICT WITH THESE GENERIC CRITERIONS; PLEASE FOLLOW THE PRODUCT INSPECTION CRITERIA RESPECTIVELY. Description D: Diameter / L: Length / W: Width / N: Number of defects/ S: Distance from dot to dot Inspecting distance: 30 ±...
  • Page 60 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 60 of 91 Doc. Title Sapphire Service Manual HTC CONFIDENTIAL SM-TP008-1125...

  • Page 61: Main Unit Inspection

    Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 61 of 91 Doc. Title Sapphire Service Manual 5.3 Main unit inspection GAP & STEP INSPECTIONS Accept Criteria Description Gap between ME parts. 1.5 (mm) Stylus assembly protruding, loose, missing, falling and Stylus deformed is not allowed.

  • Page 62: Generic Troubleshooting

    2009/01/14 Page 62 of 91 Doc. Title Sapphire Service Manual 6 Generic Troubleshooting 1 Main Unit Does Not Respond to Power Button (1) Connect the AC adapter, maybe the battery pack is exhaust and wait few minutes for battery recharging.
  • Page 63 2009/01/14 Page 63 of 91 Doc. Title Sapphire Service Manual 4 Unusual Vertical / Horizontal lines or partial display (1) Check the connection of LCM FPC whether is properly connected. (2) Try to cold boot the unit then tries again.
  • Page 64 2009/01/14 Page 64 of 91 Doc. Title Sapphire Service Manual 7 PC Connection not possible (1) If test result is NFF, it is possible caused by user connect cradle to computer before ActiveSync is installed. (2) Check whether “Connection Settings” in the MS ActiveSync is properly set.
  • Page 65 Page 65 of 91 Doc. Title Sapphire Service Manual 10 Battery Pack does not recharge (1) Make sure the Battery Pack takes fully charge with AC Adapter. (2) Check whether the condition of Battery Charging status is correct. Charge should be done no more than 4 hours.
  • Page 66 2009/01/14 Page 66 of 91 Doc. Title Sapphire Service Manual 13 Wireless connection (WLAN/BT) not functioning (1) Make sure the wireless environment is OK before connecting to WLAN. (2) Make sure the wireless connection setting has properly set. (3) Make a life connection with Internet or another device.

  • Page 67: Generic Labeling Plan

    Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 67 of 91 Doc. Title Sapphire Service Manual 7 Generic Labeling Plan Main unit 7.1Agency label_SAPP100_Black The brand name is shown on Bezel. HTC P/N: 77H00693-00M Size: 41.2 X 39.00mm HTC P/N...
  • Page 68 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 68 of 91 Doc. Title Sapphire Service Manual 7.2 Agency label_SAPP100_Gray The brand name is shown on Bezel. HTC P/N: 77H00693-02M Size: 41.2 X 39.00mm HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 69 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 69 of 91 Doc. Title Sapphire Service Manual 7.3 Agency label_SAPP200_Black The brand name is shown on Bezel. HTC P/N: 77H00693-01M Size: 41.2 X 39.00mm HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 70 Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 70 of 91 Doc. Title Sapphire Service Manual 7.4 Agency label_SAPP200_Gray The brand name is shown on Bezel. HTC P/N: 77H00693-03M Size: 41. 2 X 39.00mm HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 71 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 71 of 91 Doc. Title Sapphire Service Manual 7.5 Agency label_SAPP300_Black The brand name is shown on Bezel. HTC P/N: 77H00693-04M Size: 41.2 X 39.00mm HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 72 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 72 of 91 Doc. Title Sapphire Service Manual 7.6 Agency label_SAPP300_Gray The brand name is shown on Bezel. HTC P/N: 77H00693-05M Size: 41.2 X 39.00mm HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 73 Doc. Title Sapphire Service Manual 7.7 Unit label location explanation Water sensitive label HTC P/N: 77H00668-00M Qty: 1 Tamper evident label HTC P/N: 77H00460-01M(Black) for Sapphire with black housing 77H00460-01M(White) for Sapphire with white/gray housing Qty: 1 HTC CONFIDENTIAL SM-TP008-1125...
  • Page 74 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 74 of 91 Doc. Title Sapphire Service Manual 7.8 Screen protector HTC P/N: 76H10040-00M Size: 51.2 x 84.6mm HTC CONFIDENTIAL SM-TP008-1125...
  • Page 75 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 75 of 91 Doc. Title Sapphire Service Manual 7.9 Battery label SAPP160_1340mAh_TWS HTC P/N: 35H00119-00M (Black) 35H00119-04M (Gray) HTC CONFIDENTIAL SM-TP008-1125...
  • Page 76 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 76 of 91 Doc. Title Sapphire Service Manual HTC CONFIDENTIAL SM-TP008-1125...
  • Page 77 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 77 of 91 Doc. Title Sapphire Service Manual 7.10 SAPP160_1340mAh_Welldone HTC P/N: 35H00119-01M (Black) 35H00119-05M (Gray) HTC CONFIDENTIAL SM-TP008-1125...
  • Page 78 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 78 of 91 Doc. Title Sapphire Service Manual HTC CONFIDENTIAL SM-TP008-1125...
  • Page 79 HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 79 of 91 Doc. Title Sapphire Service Manual 7.11. MFG packing label single box label (not confirmed) HTC P/N: 77Hxxxxx-xxM Size: xx.0 x xx.0mm HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 80 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 80 of 91 Doc. Title Sapphire Service Manual 12 in 1 carton label (not confirmed) HTC P/N: 77HXXXXX-00M Size: 4 X 6 inches HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 81 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 81 of 91 Doc. Title Sapphire Service Manual pallet label HTC P/N: 77H30026-00M Size: 4 X 6 inches HTC P/N Description HTC CONFIDENTIAL SM-TP008-1125...
  • Page 82 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 82 of 91 Doc. Title Sapphire Service Manual Incomplete pallet label HTC P/N: 77H30026-00M Size: 4 X 6 inches HTC CONFIDENTIAL SM-TP008-1125...

  • Page 83: Generic Spare Part List And Photos

    HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 83 of 91 Doc. Title Sapphire Service Manual Parts P/N and Photos for 8 Generic Spare Part List and Photos RC/ASP to identify. 8.1 SPL for Repair Item Description Substitute NOTE:...
  • Page 84 Revised Date 2009/01/14 Page 84 of 91 Doc. Title Sapphire Service Manual Picture for SPL 80H Kernel and Accessories (Part no on picture is for Generic version only, please check SPL for detail per customer) Part No. XXXXXXXXX-XXX Part No.

  • Page 85: Board Level 2.5 Repairs

    Revised Date 2009/01/14 Page 85 of 91 Doc. Title Sapphire Service Manual 8.2 Board Level 2.5 Repairs Basic Repair Instructions for Component Replacement: Step 1 Place the solder-proof tape to cover the surrounding area of the components which being replaced.
  • Page 86 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 86 of 91 Doc. Title Sapphire Service Manual 51HXXXXXXXX PCBA-MAIN BOARD(Side A) Item Description Location Substitute COAXIAL CONNECTOR,RF,WITH 75H00248-00M WCON_SW1 SWITCH,SMD,MM8430-2600RA1,MURATA 75H00276-00P Connector RF,5.8*5.4*3.9,Female,MS-147(06),4pin,HRS WECON1 75H00465-01M Connector I/O,Reverse,11P,0.4mm Pitch,MJE21-11K7P21,ACON...
  • Page 87 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 87 of 91 Doc. Title Sapphire Service Manual SIDE A PHOTO AND COMPONENT LOCATION RFSW1 SW13 CON5 PCON1 BCON1 PCG1 CON9 CON1 AMIC1 CON3 HTC CONFIDENTIAL...
  • Page 88 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 88 of 91 Doc. Title Sapphire Service Manual 51HXXXXXXXXX PCBA-MAIN BOARD(Side B) Item Description Location Substitute COAXIAL CONNECTOR,RF,WITH 75H00248-00M WCON_SW1 SWITCH,SMD,MM8430-2600RA1,MURATA 75H00276-00P Connector RF,5.8*5.4*3.9,Female,MS-147(06),4pin,HRS WECON1 75H00465-01M Connector I/O,Reverse,11P,0.4mm Pitch,MJE21-11K7P21,ACON...

  • Page 89: Fru M/Badditional Parts Location

    Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 89 of 91 Doc. Title Sapphire Service Manual 8.3 FRU M/B additional parts location This chapter is about locations and P/N of additional parts (Mylar, Gasket, tape, etc…) for MB. HTC CONFIDENTIAL SM-TP008-1125...

  • Page 90: Rf Antenna Specification

    Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 90 of 91 Doc. Title Sapphire Service Manual RF Antenna Specification HTC CONFIDENTIAL SM-TP008-1125...
  • Page 91 Doc. No. DOC-00051810 REV. HTC Corporation. Issued Date 2008/12/29 AX02 Revised Date 2009/01/14 Page 91 of 91 Doc. Title Sapphire Service Manual HTC CONFIDENTIAL SM-TP008-1125...
