Linear Mini-Code 3083 Installation Instructions

months. Linear Corporation warrantees our product only to
our authorized dealers and distributors and not to the end
customer. If you have any questions about our warranty,
please ask your dealer to determine the nature and scope of his
warranty. Linear Corporation does not assume, and is not re-
sponsible for, any real or consequential damages from claims
against the performance of our product, nor is it liable for any
costs related to loss of life, property, or revenue. Further,
Linear Corporation is in no way responsible for installation of
our product, and will assume no costs related to reinstallation or
removal. Linear Corporation's Warranty is in lieu of all other
warrantees, expressed or implied.
PLEASE NOTE
Linear Corporation has devoted a great deal of time and research
in order to provide the most reliable equipment possible. Certain
limitations must be observed.
(1) MULTI-CODE radio components must conform with
FCC Part 15 requirements. For this reason, the range
and power of our radios is within specified limits.
(2) As with all manufacturers, Linear Corporation's
radios must accept all signals that they receive. This
may, in rare instances, create difficulty.
(3) You should test your entire system occasionally in
order to be sure that all components are working in
good order.
(4) Linear Corporation's dealers can provide you with
5
information regarding the use of our radio controls,
and can provide valuable installation and operation
information, when requested.
CAUTION: Any changes or modification in intentional or
unintentional radiators which are not expressly approved by
Linear Corporation could void the user's authority to
operate this equipment. This applies to intentional and
unintentional radiators certified per part 15 of the F.C.C. rules
and regulations.
This device complies with FCC Part 15 and Industry Canada
Rules and Regulations. Operation is subject to the following
two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference
received, including interference that may cause undesired
operation.
LINEAR CORPORATION
2055 Corte del Nogal
Carlsbad, CA 92009
6
®

INSTALLATION INSTRUCTIONS

MODEL 3083
TWO CHANNEL MINI-TRANSMITTER
Congratulations! You have just purchased a Mini-Code Digital
Transmitter, which we believe to be the finest product of its
kind on the market. With a little care this transmitter should
provide you with many years of excellent service. Please take
a moment to read the following instructions and you will find
that setting your new transmitter will be quite an easy matter.
ACCESSING THE CODE SWITCH AND BATTERY
COMPARTMENT
The model 3083 two channel Mini-transmitter case is
composed of 2 halves which are held together by a small
phillips head screw. Removing this screw will allow access to
the code switches and the battery compartment (see diagram
#1).
1
