WARNING: Changes or modifi cations not expressly approved by the manufacturer could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC)
rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
USA & Canada (800) 421-1587 & (800) 392-0123
(760) 438-7000 - Toll Free FAX (800) 468-1340
www.nortekcontrol.com
Copyright © 2019 Nortek Security & Control LLC
PRINTER'S INSTRUCTIONS:
®
INSTALLATION INSTRUCTIONS
MICRO-TRANSMITTER MODEL MCS1082
Congratulations! You have just purchased a Micro-Code Digital Transmitter,
which we believe to be the fi nest product of its kind on the market. With a
little care this transmitter should provide you with many years of excellent
service. Please take a moment to read the following instructions and you will
fi nd that setting your new transmitter will be quite an easy matter.
ACCESSING THE CODE SWITCH AND BATTERY
COMPARTMENT
The model MCS1082 Micro-Transmitter case is composed of two halves that
can be opened by inserting a small coin in the slot provided. A twisting
motion of the coin will cause the two halves to separate. Once opened, you
will have access to both the code setting switch and the battery compartment
(See Diagram #1).
