Avantgarde TBWC-46S Instruction Manual page 21

Procedure for reversing door opening
Step 9
Remove screws from
opposite side (bottom)
Step 11
Remove screws from
opposite side (top)
12/21/2010
Step 10
• Re-install bottom hinge assembly using
screws removed in Step 9.
• Put in the levelling rings from Step 8
Note: All parts needed for rev erse door swing
assembly are included in the component
bag inside the unit along with the owner's
manual and the key.
Step 12
Reverse door 180° and re-install
•
Re-install top hinge assembly . Make
•
sure that the door is properly
aligned w ith the cabinet before
tightening the screws.
22
