Dimplex Duo300n Installation Instructions Manual page 10

DO NOT USE 30MM SPACER ON INSIDE OF RADIATOR.
USE ONLY EXTERNALLY - SEE FIG. 11
NOTE: UNDER NO CIRCUMSTANCES SHOULD THESE
SCREWS BE REMOVED WITHOUT FIRST REMOVING
ALL ENERGY RETENTION CELLS FROM THE RADIATOR
10 Once both sides have been successfully positioned
F
screw the radiator fl ush to the wall Fig. 10
Do not fully tighten these screws until the core has
been loaded into the radiator as some settling of the
radiator may occur.
11. SKIRTING BOARD TALLER THAN 100MM
Use the 10mm and 30mm spacers provided (2 x
10mm and 2 x 30mm)
11 If the skirting board is taller than 100mm, the radiator
A
is to be mounted as shown in fi g 11
the wall mounting bracket and reassemble in the
alternative orientation to give a greater spacing
distance from the wall.
11 Place the 30mm spacer to the outside of the radiator
B
and the 10mm to the inside. Drill the holes as detailed
in Section 10. Carefully guide the radiator towards
the drilled hole. When in position screw part way
to the wall to secure the radiator as in Section 10,
remembering not to fully tighten the screws.
Solid brick/High density block walls - Fig. 11
These must be drilled and plugged with the No. 10 size
plastic inserts provided. The correct size of drill (8mm)
should be used and the hole should be drilled to a depth of
15mm greater than the length of the plastic insert so that
the fi xing is made below the plaster layer.
Low density block walls - Fig 11d
A special fi xing, such as Unifi x LB70 should be employed,
following closely the manufacturers instructions.
Panelled internal walls
If possible, locate the studding and use No. 10 size
.
A
woodscrews. Where it is not possible to locate the studding
use type M5 Rawlplug INTERSETS on securely fastened
plasterboard panelling. For other wall materials the wall
panel manufacturer should be consulted for details of
suitable wall fi xing devices.
12.
screws along its top edge Fig. 12
bottom of the front inner panel out of the retaining fl ange
at the base of the radiator, Fig 12
.
F
packaging, Fig. 12
attached.
13.
rotate forwards. Fig. 13.
14.
energy retention cells, placing the two end cells in position
fi rst with the fl at side toward the back. Fit the top row of
cells also with the recess toward the element. Fig. 14
. Remove
15.
A
down through the hole in the base insulation, ensuring the
tab is pointing forward. Fit the front layer of cells with the
fl at side toward the front of the radiator. Ensure that the tab
on the element is captured below the bottom row of cells
and that the element is vertical. Fig. 15
16.
locating its bottom edge behind the front lip of the chassis
and inserting the retaining screws along the top and both
sides. Fig. 16.
17.
wall have been fully tightened. It is essential that all screws
C
are replaced to ensure earth continuity.
Once installed DO NOT attempt
to reposition the radiator without
fi rst unloading the energy retention
cells and obtaining the services of a
competent electrician.
- 10 -
Remove the inner front panel by removing the
taking care not to damage the insulation
C
Lift out the elements from the base insulation and
DO NOT DISCONNECT THE TERMINALS
Carefully fi t the bottom row of the back layer of
Refi t the elements by carefully feeding the tails
Replace the inner front complete with insulation by
Check that the screws securing the radiator to the
. Carefully lift the
A
and remove the internal
B
& 15 .
A B
