- Page 1 Model 24921 Owner’s/Installation Guide...
-
Page 3: Congratulations
Congratulations Congratulations and thank you for purchasing one of our state-of-the-art remote start systems. Directed is the world leader in vehicle security, remote start, and keyless entry systems, so yes, you have made the right choice! STOP! Read this First Please make sure you follow all the steps listed below before attempting to install this system in your vehicle. -
Page 4: What's Included
What's Included • Control Module • One 1- Button Remote Control • Control Button (Valet Switch) • Antenna and Cable • Harnesses • Hood Pin Switch • Hardware Kit • Neutral Safety Switch • Bypass Module (24921B only) • Your Warranty Registration Card •... -
Page 5: Important Information
Important Information Government Regulations and Safety Information Read the Government Regulations and Warning! Safety First sections of this guide prior to operating this system. Warning! Failure to heed this information can result in death, personal injury or property damage and may also result in the illegal use of the system beyond its intended purpose. - Page 6 Guide Translations If you want a Spanish or French version of the Installation/Owners Guide, please download it from www.readyremote.com and click on On-Line Tech Support. Estimado Cliente: Si buscas los guías de instalación/del usario, por favor de bajar lo del Soporte Técnico en-línea en el sitio www.readyremote.com Cher consommateur: Si vous désirez une version française ou espagnole du guide...
-
Page 7: Table Of Contents
Contents Congratulations ....................iii STOP! Read this First ..................iii What's Included .................... iv Tools Required ....................iv Important Information ..................v Your Warranty ..................v Replacement Remote Controls ..............v Installation Guide..................v Guide Translations ................... vi Installation Guide ....................2 Wiring Schematic ..................2 Wiring Connections ..................3 Installation Points ....................4... -
Page 8: Installation Guide
Installation Guide Wiring Schematic Antenna Parking Light Jumper Side View Side View LED (Pro Top View indicato Control (Valet S elay Antenn Primary Harness Auxiliary Harness Antenna Antenna Parking Light Parking Light Jumper Jumper Side View Side View LED (Programming Top View Top View indicator) -
Page 9: Wiring Connections
Wiring Connections Primary Harness (H1), 9-pin connector H1/1 LIGHT GREEN BLACK (-) 200mA FACTORY ALARM DISARM H1/2 GREEN/WHITE (-) 200mA FACTORY ALARM REARM H1/3 EMPTY NOT USED H1/4 WHITE/BLUE (-) ACTIVATION INPUT H1/5 EMPTY NOT USED H1/6 EMPTY NOT USED H1/7 EMPTY NOT USED... -
Page 10: Installation Points
Control Button (valet switch), 2-pin connector BLACK INPUT GREY OUTPUT Installation Points Note: The LED referenced within the installation section is the LED (pro- gramming indicator) on the Control Module unless otherwise stated. Virtual Tach Note: Use of Virtual Tach does not require the Tach wire to be con- nected. -
Page 11: Tach Learning
Tach Learning Note: Tach learning requires H3/2 (Violet/White) wire to be con- nected to Tach. If using Virtual Tach, this procedure is not required and should not be used. To learn the tach signal: Start the vehicle with the key. Within 5 seconds, press and hold the Control button. -
Page 12: Remote Start Shutdown Diagnostics
tory default settings. Note: This feature does not delete the remote controls from the system or reset the Virtual Tach setting Virtual Tach Reset: Deletes all previously learned values for Vir- tual Tach, and on the next remote start sequence the unit begins virtual tach initialization. -
Page 13: Programming System Features
4 flashes Transmitter shutdown (or optional push button) 5 flashes (-) Hood Shutdown (H3/4 Gray) 6 flashes (+) Brake Shutdown (H3/3 Brown) 7 flashes (-) Neutral safety shutdown (H3/1 Black/White) 8 flashes Wait-to-start timed out Programming System Features The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of the feature settings (see Feature Menu) using the Control button. - Page 14 The learn routine exits if any of the following occurs: • The ignition is turned On • There is no activity for 30 seconds • The Control button is pressed too many times © 2010 Directed Electronics. All rights reserved.
-
Page 15: Feature Menu
Feature Menu Default settings are in bold type. Feature Feature Opt. 1 Opt. 2 Opt. 3-5+ Engine check- Virtual tach voltage (3) Off, (4) Tachometer Remote Start 12 min 24 min 60 min Engine Runtime Park light Pulsed Constant output Cranking time 0.6 sec. -
Page 16: Remote Control Programming
Remote Control Programming Turn key to the ON position Within 5 seconds, press and release Control button one time. Within 5 seconds, press and hold the Control button. The LED will flash one time to confirm entry into remote programming. Press the button on the remote control. -
Page 17: Owner's Guide
Owner's Guide System Maintenance The system requires no specific maintenance beyond battery replace- ment for the remote control. Your remote is powered by a coin cell battery (3V CR2032) that lasts approximately one year under normal use. When the battery begins to weaken operating range is reduced. Battery Replacement Locate the small slot on the side of the remote control. - Page 18 Sirius Warning! (1) Never remote start your vehicle when the keys are in the ignition, except when performing Valet Take-Over, and (2) Never start the vehicle if it is not in PARK or NEUTRAL To remote start the vehicle: • Press the button on the remote control once (default)*.
-
Page 19: Valet Take-Over
the engine will shut down. While the vehicle is running during remote start operation, the system monitors the ve hi cle and automatically shuts down the engine if it receives any of the following shut-down inputs: • The brake pedal is pressed. •... -
Page 20: Government Regulations
Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. -
Page 21: Warning! Safety First
Warning! Safety First The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must be done properly according to instructions with safety always considered. Failure to properly install this system and its safety features may result in personal injury, property damage or both. -
Page 22: Caution
outlined in this guide. If the vehicle starts when performing the Neutral Safety Shutdown Circuit test, the remote start unit has not been properly installed. The remote start module must be removed or properly reinstalled so that the vehicle does not start in gear. OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. - Page 23 Test the HOOD PIN shutdown circuit: With the vehicle in Park (P), open the hood. Activate the remote start system. The vehicle should not start. If the starter engages, check your hood pin and connections. Note: If programmed for Diesel Mode, the system will turn on the ignition, but the starter should not engage with the hood open.
-
Page 24: Patent Information
Patent Information This product is covered by one or more of the following U.S. patents: 303,223 345,711 4,383,242 5,103,221 5,534,845 5,907,195 333,633 347,190 4,438,426 5,117,217 5,572,185 5,914,667 333,634 348,622 4,553,127 5,132,660 5,646,591 5,945,936 333,635 352,685 4,584,569 5,193,141 5,656,997 5,952,933 333,636 383,689 4,794,368 5,245,694... -
Page 25: Lifetime Consumer Warranty
Lifetime Consumer Warranty For a period of one calendar year from the date of purchase of this auto-security, remote start or keyless entry device, as applicable (hereinafter “Unit”), Directed Electronics (“Di- rected”) promises to the ORIGINAL PURCHASER to repair or replace (at Directed’s election) with a comparable, reconditioned Directed DIY Unit (excluding without limitation, the siren, remote transmitters and associated sensors and accessories) which proves to be defective in workmanship or material under reasonable use PROVIDED the following conditions are... - Page 26 Consumer’s remedy is limited to repair or replacement of the Unit, and in no event shall Directed’s liability exceed the purchase price of the Unit. IN ANY EVENT, DIRECTED SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING, BUT NOT LIMITED TO, ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, PUNITIVE OR CONSEQUENTIAL DAMAGES, LOST PROFITS, DAMAGE TO VEHICLE, LOST SAVINGS, OR, TO THE EXTENT ALLOWED BY APPLICABLE LAW, DAMAGES RESULTING IN DEATH OR INJURY ARISING OUT OF OR IN...
- Page 28 The company behind this system is Directed Elec tron ics Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DIRECTED is ISO 9001 registered.
