Ready Remote 23926 Installation Manual

DesignTech International, Inc. • 7955 Cameron Brown Court • Springfield, Virginia 22153 USA • www.designtech-intl.com • 703-866-2000 or 800-337-4468
PLEASE READ ENTIRE MANUAL COMPLETELY BEFORE BEGINNING INSTALLATION
Congratulations on your purchase of the Ready Remote Car Starter. Ready Remote Car Starter allows you to start the car by remote control from the comfort
of your home or office in order to cool it down in the summer or warm it up in the winter.
Ready Remote Car Starter is for automatic transmission/fuel injected gasoline vehicle only. Please see pages 5-6 for important information on vehicles with
factory anti-theft systems. Ready Remote is an extremely sophisticated system with multiple built-in safety and security features.
• Will start your car by remote control, and run the heater,
defroster, or air conditioner to warm up or cool down the car
from up to 800 feet away!
• Is designed to start the car if it is in park, and only if the
hood is closed.
• Will attempt to start the car for up to six seconds, but no
longer (to avoid damage to the starter motor). Should the
car not start, or if it stalls after starting, the remote starter
will make two further attempts to start it.
• Will not let the car be driven without the key in the ignition.
• Allows you to use one remote to control up to 4 vehicles with
Ready Remote ® Remote Car Starters.
Tools required to install the Ready Remote
Wire Cutters/Strippers
Soldering Iron
Pliers
Test meter
We highly recommend that all connections be soldered for reliability.
Parts List included with the Ready Remote
Remote Starter Receiver Module
Transmitters
Antenna
Control Harness (6 position)
6 Power & Ignition Wires
The following parts are included in the plastic bag:
Alchohol
Alcohol Pad
Pad
Green 30 A Fuse
On/Off Control Switch
Warning Label This car is equipped with a remote control starting device.
Disable before working on car!
AVERTISSEMENT
Co véhicule est équipé d'un systéme de démarrage á distance. Mettez-le hors
fonctuin avant d'eflectuer toule opération d'entretian ou de répanation!
Single Blue Horn Wire
2 Protected by
DesignTech Labels
Ready Remote
Remote Control Car Starter Installation Manual
Ready Remote
®
Electrical Tape
Screwdriver
Drill with
1 / "and
4
drill bits
®
Ring Terminal
Hood Pin Switch Set
2 Cable Ties
WARNING
Yellow Butt Connector
®
Model 23926
® Remote Car Starter:
• Requires the user to "enable" the unit to prevent accidental
starts.
• Shuts itself off automatically after 10 or 15 minutes
(programmable) if you forget to come out to your car.
• Starts the vehicle automatically when ever the temperature
drops below 0
activated
• Will shut off if the brake pedal is pushed, the hood is opened,
or the transmission is shifted out of park - unless the key is
in the ignition and in the "run" position.
• Is quality engineered, microprocessor controlled, and made
in the USA to provide many years of reliable use.
• Comes with a Two Year Limited Warranty.
Unit:
Power Harness
5 / "
16
Unit:
GREEN In Gear Loop
ON/OFF Switch Jack
Control Harness
Color Function
Brown/White Alarm Disarm
Yellow Lights
White/Black Ignition #3
White - Option
Red LED Light
Red - Code Learn
Color
Orange
Purple
Green
* For free vehicle specific wire information consult
our website at www.designtech-intl.com
1
° F (-18 ° C) when the Cold Start™ option is

Wiring Diagram

Color Function
Pink Power (+12V)
White Accessory
Yellow Starter
Blue Ignition 1
Green Ignition 2
Black Ground
Color Function
Blue Horn
Circuit Type Required
(–)400 mA Consult Wiring Guide*
(+) Relay Output No
(–) 400 mA Consult Wiring Guide*
Function Circuit Type Required
Brake (+) Input Yes
Hood Switch (-) Input Yes
Tach (-) Input No
Circuit
Type Required
Input Yes
Relay output Yes
Relay output Yes
Relay output Yes
Relay output Consult Wiring Guide *
Input Yes
Coax
Antenna Jack
Circuit
Type Required
(-)400mA No
v2.2 (2126)
