  • Page 1 ADE-9021 ® ® ® Intel LGA775 Pentium 4/Celeron 915GV ATX Board User’s Manual Rev. 1.0 2007/6/27 P/N: 600C002902110...
  • Page 2 ADE-9021 User’s Manual Copyright All rights reserved. The information contained in this guide has been validated and reviewed for accuracy. No patent liability is assumed with respect to the use of the information contained herein. While every precaution has been taken in the preparation of this guide, the Manufacturer assumes no responsibility for errors or omissions.
  • Page 3 ADE-9021 User’s Manual How to Use This Manual This manual is written for the system integrator, PC technician and knowledgeable PC end user. It describes how to configure your system board to meet various operating requirements. The user’s manual is divided into four chapters, with each chapter addressing a basic concept and operation of the server board.

  • Page 4: Table Of Contents

    ADE-9021 User’s Manual Table of Content Introduction.........................7 Description......................7 Packing Check List....................8 Specifications ......................9 System Architecture..................11 Dimensions ......................12 Hardware Configuration Setting................14 Board Layout .....................14 Jumpers & Connectors ..................15 2.3.1 BIOS write protection setting: JP1..............16 2.3.2 Watchdog Timer setting select: JP2 .............16 2.3.3...
  • Page 5 ADE-9021 User’s Manual 2.3.23 Front panel connector: CN23 ...............19 2.3.24 Internal USB 4/5 connector: CN24 ...............19 2.3.25 COM3/COM4 serial port connector: CN25/CN26 .........19 2.3.26 Chassis fan connector: CN27...............19 2.3.27 Serial ATA connectors: SATA1/2/3/4 .............19 2.3.28 Floppy disk connector: FDD .................20 2.3.29...
  • Page 6 ADE-9021 User’s Manual CHAPTER 1 6 / 49...

  • Page 7: Introduction

    ATX power function, and a feature of CPU overheat protection will provide user more security and stability. Coming with all the popular capabilities, ADE-9021 ATX Mother Board are those right solutions for KIOSK, medical equipment, industrial automation, financial automation, process control, semiconductor equipment, and network security markets.

  • Page 8: Packing Check List

    ADE-9021 User’s Manual Packing Check List The ADE-9021 package includes the following basic items accompany with this manual. One ADE-9021 ATX main board One Installation Guide for ADE-9021 One 40-pin IDE cable One 34-pin FDD cable Two Serial ATA cable...

  • Page 9: Specifications

    ADE-9021 User’s Manual Specifications System ® ® ® Intel Pentium 4 / Celeron D Processor in the LGA775 package 800/533 MHz BIOS Award BIOS with 4 Mb Flash ROM ® System Chipset Intel 915GV + ICH6 ® I/O Chip Winbond...
  • Page 10 ADE-9021 User’s Manual Audio ® AC97 Codec Realtek ALC655 5.1CH audio codec Audio Interface Line in, Line out, Mic phone jack, CD-in, Line out Ethernet ® Dual Marvell 88E8053 PCI Express Gigabit Ethernet Chipset controllers Ethernet Interface IEEE 802.3 10BASE-T/100BASE-TX/1000BASE-T Mechanical &...

  • Page 11: System Architecture

    ADE-9021 User’s Manual System Architecture All of details operating relations are shown in ADE-9021 system block diagram. 11 / 49...

  • Page 12: Dimensions

    ADE-9021 User’s Manual Dimensions 12 / 49...
  • Page 13 ADE-9021 User’s Manual CHAPTER 2 13 / 49...

  • Page 14: Hardware Configuration Setting

    ADE-9021 User’s Manual Hardware Configuration Setting This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on the board are in the proper position. The default settings shipped from factory are marked with an asterisk ( ).

  • Page 15: Jumpers & Connectors

    ADE-9021 User’s Manual Jumpers & Connectors JUMPERS FUNCTION REMARK BIOS write protection select 1 x 2 header Watchdog Timer setting select 1 x 3 header COM4 port setting select 2 x 7 header COM3 port setting select 2 x 7 header...

  • Page 16: Bios Write Protection Setting: Jp1

    ADE-9021 User’s Manual 2.3.1 BIOS write protection setting: JP1 2.3.2 Watchdog Timer setting select: JP2 PIN No. Description PIN No. Description Write-protection Open Disabled Reset System 2.3.3 COM4/COM3 port setting select: JP3/JP4 PIN No. RS-232 RS-422 RS-485 ON(Term) ON(Term) ON(Term)

  • Page 17: Parallel Port Connector: Cn3

    ADE-9021 User’s Manual 2.3.8 Parallel port connector: CN3 2.3.9 Audio connector: CN4 PIN No. Description PIN No. Description PIN No. Description Line-In Blue Auto Feed Line-Out Green PD 0 Error Pink Mic-In PD 1 Initialize PD 2 Select 2.3.10 PS/2 mouse connector: CN5...

  • Page 18: Cd-In Connector: Cn9

    ADE-9021 User’s Manual 2.3.15 CD-In connector: CN9 2.3.16 External K/B & M/S connector: CN10 PIN No. Description PIN No. Description MS Clock Left CD_IN MS Data Ground KB Clock Ground KB Data Right CD_IN Ground Dual_5V 2.3.17 Power fan connector: CN11 2.3.18 ATX 12V power connector: CN12...

  • Page 19: Front Panel Connector: Cn23

    ADE-9021 User’s Manual 2.3.23 Front panel connector: CN23 2.3.24 Internal USB 4/5 connector: CN24 Description PIN No. PIN No. Description Description Description VCC5V VCC5V IRDA RESET USBP4- USBP5- RESET+ USBP4+ USBP5+ IR_CRX RESET- Ground Ground IP_RX SPEAKER Ground SPEAKER IR_TX...

  • Page 20: Floppy Disk Connector: Fdd

    ADE-9021 User’s Manual 2.3.28 Floppy disk connector: FDD 2.3.29 Primary IDE connector: IDE Description Description Description Description Ground Reset IDE- Ground PDD 7 PDD 8 Ground PDD 6 PDD 9 Ground PDD 5 PDD 10 Ground Index- PDD 4 PDD 11...
  • Page 21 ADE-9021 User’s Manual CHAPTER 3 21 / 49...

  • Page 22: System Installation

    ADE-9021 User’s Manual System Installation This chapter provides you with instructions on how to setup your system. The additional information shows you how to install CPU/ FAN and memory. ® Intel LGA775 Processor ® ® ® 3.1.1 Installing Intel Pentium...

  • Page 23: Installing Intel ® Lga 775 Cpu Fan, And Heat Sink

    ADE-9021 User’s Manual ® 3.1.2 Installing Intel LGA 775 CPU Fan, and Heat Sink • ® The Intel LGA 775 CPU heat sink and fan assembly comes in a push-pin design and requires no tool to install. • Place the fan with heat sink right above the CPU and make sure four pins matching the holes of the board.

  • Page 24: Main Memory

    ADE-9021 User’s Manual Main Memory ADE-9021 provides 2 DIMMs (240-pin Dual In-line Memory Module) to support 1.8V DDRAM (Synchronized DRAM) as on-board main memory. The maximum memory size is 256 MB ~ 2GB. Supports up to 2 double sided DIMMs at DDR2 533/400MHz. The memory architecture adopts 128-bit data interface to support for x8 and x16 DDRAM(DDR2) device width.

  • Page 25: Installing The Atx Mother Board

    ADE-9021 User’s Manual Installing the ATX Mother Board To install your ADE-9021 into standard chassis or proprietary environment, you need to perform the following steps: 1. Check all jumpers setting on proper position 2. Install and configure CPU and memory module on right position 3.
  • Page 26 ADE-9021 User’s Manual CHAPTER 4 26 / 49...

  • Page 27: Bios Setup

    ADE-9021 User’s Manual BIOS Setup Entering Setup PHOENIX-AWARD™ has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM whose power is supplied by a battery so that it can retain the setup information even when the power is turned off. Press the key “Delete”...

  • Page 28: Standard Cmos Features

    ADE-9021 User’s Manual 4.2.1 Standard CMOS Features 4.2.1.1 Date (mm/date/year) Set the system date. Note that the ‘Day’ automatically changes when you set the date. 4.2.1.2 Time (hh/mm/ss) Set the system time. 4.2.1.3 IDE Channel 0 / 1 Master Press <Enter> to enter the sub menu of detailed options.

  • Page 29: Advanced Bios Features

    ADE-9021 User’s Manual 4.2.1.8 Base Memory Displays the amount of conventional memory detected during boot up. 4.2.1.9 Extended Memory Displays the amount of extended memory detected during boot up. 4.2.1.10 Total Memory Displays the total memory available in the system.
  • Page 30 ADE-9021 User’s Manual 4.2.2.1 CPU Feature 4.2.2.1.1 Delay Prior to Thermal Select this item allows the delay prior to thermal time. The Choice: Auto, 4, 8, 16, 32Min. 4.2.2.1.2 Thermal Management It shows you the thermal Monitor. 4.2.2.1.3 LIMIT CPUID MaxVal This item should be disabled for WinXp, but enabled for NT4.0.
  • Page 31 ADE-9021 User’s Manual 4.2.2.4 CPU L1/L2 /L3 Cache These categories speed up memory access. However, it depends on CPU/chipset design. The choice: Enabled, Disabled. 4.2.2.5 Hyper-Threading Technology When you install a CPU featuring Hyper-Threading Technology, this item will allow you to enable or disable the Hyper-Threading technology.
  • Page 32 ADE-9021 User’s Manual 4.2.2.15 Typematic Delay (Msec) Sets the delay time after the key is held down before it begins to repeat the keystroke. The choice: 250, 500, 750 and 1000. 4.2.2.16 Security Option Select whether the password is required every time the system boots or only when you enter setup.

  • Page 33: Advanced Chipset Features

    ADE-9021 User’s Manual 4.2.3 Advanced Chipset Features 4.2.3.1 DRAM Timing Selectable Select the operating system that is selecting DRAM timing, so select SPD for setting SDRAM timing by SPD. The Choice: Manual, By SPD. 4.2.3.2 CAS Latency Time When synchronous DRAM is installed, the number of clock cycles of CAS latency depends on the DRAM timing.
  • Page 34 ADE-9021 User’s Manual 4.2.3.6 System Memory Frequency You can use this item to select operating frequency for the main system memory. 4.2.3.7 SLP_S4# Min. Assertion Width The item allows you to select the assertion width of SLP_S4# The choice: 4 to 5 Sec, 3 to 4 Sec, 2 to 3 Sec, 1 to 2 Sec 4.2.3.8 System BIOS Cacheable...

  • Page 35: Integrated Peripheral

    ADE-9021 User’s Manual 4.2.3.11.1 PCI Express Port 1 / 2 / 3 / 4 This item allows you to active PCI Express. The choice: Auto, Enabled, Disabled. 4.2.3.11.2 PCI-E Compliancy Mode This item allows you to choose PCI-E Compliancy Mode.
  • Page 36 ADE-9021 User’s Manual 4.2.4.1 Onchip IDE Device 4.2.4.1.1 IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.
  • Page 37 ADE-9021 User’s Manual 4.2.4.1.5 IDE Primary/Secondary Master/Slave UDMA Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the operating environment includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/33, select “Auto”...
  • Page 38 ADE-9021 User’s Manual 4.2.4.3.1 USB / USB 2.0 Controller Select “Enabled” if your system contains a USB/USB2.0 controller and you have USB peripherals. The choice: Enabled, Disabled. 4.2.4.2.2 USB Keyboard / Mouse Support Select “Enabled” if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard / USB Mouse.
  • Page 39 ADE-9021 User’s Manual 4.2.4.3.2 KB Power ON Password You can set password to limit operating KB Power On system. 4.2.4.3.3 Hot Key Power ON The choice: Ctrl-F1~Ctrl-F12. 4.2.4.3.4 Onboard FDC Controller Select “Enabled” if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it.

  • Page 40: Power Management Setup

    ADE-9021 User’s Manual 4.2.4.3.13 EPP Mode Select Select EPP port type 1.7 or 1.9 The choice: EPP1.7, 1.9. 4.2.4.3.14 ECP Mode Use DMA Select a DMA channel for the parallel port for use during ECP mode. The choice: 3, 1.
  • Page 41 ADE-9021 User’s Manual 4.2.5.1 ACPI Function This function enables PCs to implement Power Management functions through Operating System and also provides the opportunity to integrated the interface for controlling power management and Plug-n-Play features on system devices. 4.2.5.2 Power Management...
  • Page 42 ADE-9021 User’s Manual 4.2.5.9 Sort-Off by PWR-BTTN Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung. The choice: Delay 4 Sec, Instant-Off. 4.2.5.10 CPU THRM-Throttling An input signal from PME on the PCI card awakens the system from a soft off state.

  • Page 43: Pnp/Pci Configurations

    ADE-9021 User’s Manual 4.2.6 PnP/PCI Configurations 4.2.6.1 Init Display First This item allows you to decide to active whether PCI Slot or Onboard/AGP first. 4.2.6.2 Reset Configuration Data Normally, you leave this field Disabled. Select “Enabled” to reset Extended System...

  • Page 44: Pc Health Status

    ADE-9021 User’s Manual 4.2.6.5 DMA Resources This item allows you to determine the DMA assigned to the ISA bus and is not available to any PCI slot. Legacy ISA for devices compliant with the original PC AT bus specification, PCI/ISA PnP for devices compliant with the Plug and Play standard whether designed for PCI or ISA bus architecture.

  • Page 45: Frequency/Voltage Control

    ADE-9021 User’s Manual 4.2.7.2 Current System / CPU Temperature Show you the current system/CPU temperature. 4.2.7.3 CPU / POWER / CHASSIS FAN Speed Show you the current CPU/System/ Power FAN operating speed. 4.2.7.4 VDIMM / Vcore The voltage level of the DRAM/CPU (Vcore).

  • Page 46: Load Fail-Safe Default

    ADE-9021 User’s Manual 4.2.8.3 Spread Spectrum This is to adjust extreme value of the pulse for EMI test. 4.2.8.4 CPU Host/PCI Clock This item allows you to select CPU Host/PCI Clock. 4.2.9 Load Fail-Safe Default When you press <Enter> on this item you get a confirmation dialog box with a...

  • Page 47: Exit Selecting

    ADE-9021 User’s Manual To disable a password, just press <Enter> when you are prompted to enter the password. A message will confirm the password will be disabled. Once the password is disabled, the system will boot and you can enter Setup freely.
  • Page 48 ADE-9021 User’s Manual Appendix 48 / 49...

  • Page 49: Appendix A: Watchdog Timer Programming

    ADE-9021 User’s Manual Appendix A: Watchdog Timer Programming The Watchdog Timer (WDT) is a special hardware device that monitors the computer system during normal operation. The WDT has a clock circuit that times down from a set number to zero. If a monitored item occurs before that timer reaches zero, the WDT resets and counts down again.
