Industrial Computers ADE-6050 User Manual

Intel core duo/solo 945gme mini itx board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADE-6050/6052
Intel Core Duo/Solo
945GME Mini ITX Board
User's Manual
Rev. 1.1
2008/04/28
P/N: 600C002605011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE-6050 and is the answer not in the manual?

Questions and answers

Related Manuals for Industrial Computers ADE-6050

Summary of Contents for Industrial Computers ADE-6050

  • Page 1 ADE-6050/6052 Intel Core Duo/Solo 945GME Mini ITX Board User’s Manual Rev. 1.1 2008/04/28 P/N: 600C002605011...
  • Page 2 ADE-6050/ADE-6052 User’s Manual Copyright All rights reserved. The information contained in this guide has been validated and reviewed for accuracy. No patent liability is assumed with respect to the use of the information contained herein. While every precaution has been taken in the preparation of this guide, the Manufacturer assumes no responsibility for errors or omissions.
  • Page 3 ADE-6050/ADE-6052 User’s Manual How to Use This Manual This manual is written for the system integrator, PC technician and knowledgeable PC end user. It describes how to configure your system board to meet various operating requirements. The user’s manual is divided into four chapters, with each chapter addressing a basic concept and operation of the server board.

  • Page 4: Table Of Contents

    CPU Fan Connector: CN15 ................20 2.3.17 ATX power Connector: CN16 ...............20 2.3.18 COM3 / COM4 Connectors: CN18/CN19 .............20 2.3.19 8-bit Digital I/O Connector: CN20 (ADE-6050 only)........21 2.3.20 Front Panel Connector: CN21 ..............21 2.3.21 Primary IDE Connector: IDE1...............21 2.3.22 Serial ATA Connectors: SATA1, SATA2 ............21...
  • Page 5 PnP/PCI/PCI-E Configurations ..............47 4.2.7 PC Health Status ..................49 4.2.8 Load Fail-Safe Default..................49 4.2.9 Load Optimized Defaults ................50 4.2.10 Supervisor/User Password Setting...............50 4.2.11 Exit Selecting....................51 Appendix A: Watchdog Timer Programming ..............53 Appendix B: GPI/O Programming (ADE-6050 only) ............54 5 / 54...
  • Page 6 ADE-6050/ADE-6052 User’s Manual Revision History Revision Date Comment Rev.1.0 Jan. 2007 Initial released Rev.1.1 Apr. 2008 1. DVI pin assignment modified 2. BIOS for ADE-6052 inserted 3. WDT & GPIO programming inserted 6 / 54...
  • Page 7 ADE-6050/ADE-6052 User’s Manual CHAPTER 1 7 / 54...

  • Page 8: Introduction

    ADE-6050/ADE-6052 User’s Manual Introduction Description ® The ADE-6050/ADE-6052 all-in-one Mini-ITX is designed to fit a high performance Intel Core Duo based processor and compatible for high-end computer system applications with PCI bus architecture to meet today’s demanding pace and keep complete compatibility with hardware and software designed.

  • Page 9: Packing Check List

    ADE-6050/ADE-6052 User’s Manual Packing Check List The ADE-6050/ADE-6052 package includes the following basic items accompany with this manual. One ADE-6050/ADE-6052 Mini ITX One Installation Guide for ADE-6050/ADE-6052 One 40-pin IDE cable One Serial ATA cable One USB cable One Serial port for RS232 cable...

  • Page 10: Specifications

    ADE-6050/ADE-6052 User’s Manual Specifications System ® ® Intel Core™ Duo / Solo and Celeron M processor (Yonah Core) ® Intel Core™ 2 Duo Mobile processor on Napa refresh (Merom/Socket M) FSB 533/667 MHz BIOS Award BIOS with 4 Mb Flash ROM ®...
  • Page 11 ADE-6050/ADE-6052 User’s Manual Audio ® AC97 Codec Realtek ALC655 5.1CH 3D audio codec Audio Interface Line in, Line out, Mic in by jack, CD-in by pin header Ethernet ® Chipset Dual Marvell 88E8053 PCI-E Gigabit Ethernet controllers Ethernet Interface IEEE 802.3 10/100/1000 BASE-TX Mechanical &...

  • Page 12: System Architecture

    ADE-6050/ADE-6052 User’s Manual System Architecture All of details operating relations are shown in ADE-6050/ADE-6052 system block diagram. CRT2 for ADE-6052 only Intel 945GME ADE-6050 only 12 / 54...

  • Page 13: Dimensions

    ADE-6050/ADE-6052 User’s Manual Dimensions 1.5.1 ADE-6050 Unit: mm 13 / 54...

  • Page 14: Ade-6052

    ADE-6050/ADE-6052 User’s Manual 1.5.2 ADE-6052 Unit: mm 14 / 54...
  • Page 15 ADE-6050/ADE-6052 User’s Manual CHAPTER 2 15 / 54...

  • Page 16: Hardware Configuration Setting

    ADE-6050/ADE-6052 User’s Manual Hardware Configuration Setting This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on the board are in the proper position. The default settings shipped from factory are marked with an asterisk ( ).

  • Page 17: Jumpers & Connectors

    COM1/2 RS232 serial port connectors PS/2 mouse & keyboard connectors D-sub 15-pin VGA & DVI connector (DVI-D for ADE-6050, DVI-I for ADE-6052) USB 2, 3 & LAN 2 connectors USB 0, 1 & LAN 1 connectors External keyboard & mouse connector...

  • Page 18: Jumpers- Setting & Connectors Description

    ADE-6050/ADE-6052 User’s Manual Jumpers- Setting & Connectors description 2.3.1 LCD power setting select: JP1 2.3.2 Clear CMOS setting select: JP2 PIN No. Description PIN No. Description Normal operation 3.3V Clear CMOS 2.3.3 Auto power on select: JP3 2.3.4 BIOS write protection setting: JP4 PIN No.

  • Page 19: Lan 1 + Usb 0/1 & Lan 2 + Usb 2/3 Connectors: Cn6 & Cn5

    ADE-6050/ADE-6052 User’s Manual 2.3.9 LAN 1 + USB 0/1 & LAN 2 + USB 2/3 Connectors: CN6 & CN5 LAN 1/2 USB 0/1/2/3 PIN No. Description PIN No. Description PIN No. Description PIN No. Description MDI0+ MDI2+ +5 V (fused)

  • Page 20: Line Out Connector: Cn9

    ADE-6050/ADE-6052 User’s Manual 2.3.13 Line out Connector: CN9 2.3.14 LVDS Connector: CN10 PIN No. Description Description PIN. PIN. Description LOUT_L Ground Ground Ground Ground LVDS_YAM1 LVDS_YAM0 LOUT_R LVDS_YAP1 LVDS_YAP0 Ground Ground LVDS_CLKAM LVDS_YAM2 LVDS_CLKAP LVDS_YAP2 Ground Ground LVDS_YBM0 LVDS_YBP0 Ground...

  • Page 21: 8-Bit Digital I/O Connector: Cn20 (Ade-6050 Only)

    ADE-6050/ADE-6052 User’s Manual 2.3.19 8-bit Digital I/O Connector: CN20 2.3.20 Front Panel Connector: CN21 (ADE-6050 only) Description Description Description Description IRDA RESET EXT_VDD RESET+ RESET- IRRX SPEAKER Ground SPEAKER EXT_VSS IRTX BUZZ HDD LED Ground HDLED+ HDLED- PW_ LED TB LED...
  • Page 22 ADE-6050/ADE-6052 User’s Manual CHAPTER 3 22 / 54...

  • Page 23: System Installation

    ADE-6050/ADE-6052 User’s Manual System Installation This chapter provides you with instructions on how to setup your system. The additional information shows you how to install CPU / FAN and memory. Socket 478 Processors 3.1.1 Installing CPU Check and confirm that you are going to install correctly CPU type and pin numbers.

  • Page 24: Main Memory

    ADE-6050/ADE-6052 User’s Manual Main Memory The figures display the notch marks and what they should look like on your SO-DIMM memory module. SO-DIMM has 200-pins and two notches, that will match with the onboard SO-DIMM socket. Memory modules are installed by placing the chip firmly into the socket at a parallel angle and pressing straight down until it fits tightly into the SO-DIMM socket.
  • Page 25 ADE-6050/ADE-6052 User’s Manual CHAPTER 4 25 / 54...

  • Page 26: Bios Setup

    ADE-6050/ADE-6052 User’s Manual BIOS Setup Entering Setup PHOENIX-AWARD™ has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM whose power is supplied by a battery so that it can retain the setup information even when the power is turned off. Press the key “Delete”...

  • Page 27: Standard Cmos Features

    ADE-6050/ADE-6052 User’s Manual 4.2.1 Standard CMOS Features 4.2.1.1 Date (mm/date/year): Set the system date. Note that the ‘Day’ automatically changes when you set the date. 4.2.1.2 Time (hh/mm/ss): Set the system time. 4.2.1.3 IDE Channel 0 / 1 Master: Press <Enter> to enter the sub menu of detailed options.
  • Page 28 ADE-6050/ADE-6052 User’s Manual 4.2.1.10 Total Memory: Displays the total memory available in the system. 28 / 54...

  • Page 29: Advanced Bios Features

    ADE-6050/ADE-6052 User’s Manual 4.2.2 Advanced BIOS Features 4.2.2.1 CPU Feature 29 / 54...
  • Page 30 ADE-6050/ADE-6052 User’s Manual 4.2.2.1.1 Delay Prior to Thermal: Select this item allows the delay prior to thermal time. The Choice: Auto, 4, 8, 16, 32Min. 4.2.2.1.2 Execute Disable Bit: Select when disable, forces the XD feature flag to always return 0.
  • Page 31 ADE-6050/ADE-6052 User’s Manual 4.2.2.11 APIC Mode This item allows you to enable or disable APIC Mode. The choice: Enabled, Disabled. 4.2.2.12 MPS Version Control For OS Select the operating system that is Multi-Processors Version Control for OS. The choice: 1.4, 1.1.
  • Page 32 ADE-6050/ADE-6052 User’s Manual 4.2.2.13 OS Select For DRAM > 64MB Select the operating system that is running with greater than 64MB of RAM on the system. The choice: Non-OS2, OS2. 4.2.2.14 Cache Setup 4.2.2.14.1 CPU L1& L2 Cache These two categories speed up memory access. However, it depends on CPU/chipset design.
  • Page 33 ADE-6050/ADE-6052 User’s Manual 4.2.2.15 Boot Seq & Floppy Setup 4.2.2.15.1 Hard Disk Boot Priority Press Enter and It shows Bootable add-in Card. 4.2.2.15.2 First/Second/Third Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items.

  • Page 34: Advanced Chipset Features

    ADE-6050/ADE-6052 User’s Manual 4.2.3 Advanced Chipset Features For ADE-6050 For ADE-6052 34 / 54...
  • Page 35 ADE-6050/ADE-6052 User’s Manual 4.2.3.1 DRAM Timing Selectable Select the operating system that is selecting DRAM timing, so select SPD for setting SDRAM timing by SPD. The Choice: Manual, By SPD. 4.2.3.2 CAS Latency Time When synchronous DRAM is installed, the number of clock cycles of CAS latency depends on the DRAM timing.
  • Page 36 ADE-6050/ADE-6052 User’s Manual 4.2.3.10 PCI Express Root Port Function 4.2.3.10.1 PCI Express x1 Slot This item allows you to active PCI Express. The choice: Auto, Enabled, Disabled. 4.2.3.10.2 PCI-E Compliancy Mode This item allows you to choose PCI-E Compliancy Mode.
  • Page 37 ADE-6050/ADE-6052 User’s Manual 4.2.3.16 Panel Scaling This item allows you to enable or disable the Scaling function. The choice: AUTO, ON, OFF. 4.2.3.17 Panel Number This item allows you to select the panel resolution that will be displayed depending on the LCD panel (LFP).

  • Page 38: Integrated Peripheral

    ADE-6050/ADE-6052 User’s Manual 4.2.4 Integrated Peripheral 4.2.4.1 Onchip IDE Device 38 / 54...
  • Page 39 ADE-6050/ADE-6052 User’s Manual 4.2.4.2.1. IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.
  • Page 40 ADE-6050/ADE-6052 User’s Manual 4.2.4.2.7. SATA Ports Speed Settings This item allows you set the SATA Ports Speed. The choice: Disabled, Force GEN I, Force GEN II. 4.2.4.2.8. PATA IDE Mode This function allows to select PATA IDE mode. 40 / 54...
  • Page 41 ADE-6050/ADE-6052 User’s Manual 4.2.4.2 Onboard Device 4.2.4.2.1. Onboard Giga Lan 2 Select “Enabled” if your system has a LAN device installed on the system board and you wish to use it. The choice: Auto, Enabled, Disabled. 4.2.4.2.2. USB Controller Select “Enabled” if your system contains a Universal Serial Bus (USB) controller and you have USB peripherals.
  • Page 42 ADE-6050/ADE-6052 User’s Manual 4.2.4.2.5. USB Mouse Support Select “Enabled” if your system contains a Universal Serial Bus (USB) controller and you have a USB mouse. The choice: Enabled, Disabled. 4.2.4.2.6. Azalia/AC97 Audio Select This item allows you to select the chipset family to support AC97 Audio The choice: Auto, Azalia, AC97 Audio only, All disabled.
  • Page 43 ADE-6050/ADE-6052 User’s Manual 4.2.4.3 Super IO Device 4.2.4.2.1. Onboard Serial Port 1/2 Select an address and corresponding interrupt for the first and second serial ports. The choice: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled and Auto. 4.2.4.2.2. UART Mode Select This item allows you to determine which Infra Red (IR) function of onboard I/O chip.

  • Page 44: Power Management Setup

    ADE-6050/ADE-6052 User’s Manual 4.2.5 Power Management Setup 4.2.5.1 ACPI Function This function enables PCs to implement Power Management functions through Operating System and also provides the opportunity to integrated the interface for controlling power management and Plug-n-Play features on system devices.
  • Page 45 ADE-6050/ADE-6052 User’s Manual 4.2.5.4 Video Off Method This determines the manner in which the monitor is blanked. V/H SYNC+Blank: This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the video buffer.
  • Page 46 ADE-6050/ADE-6052 User’s Manual 4.2.5.14 FDD,COM,LPT Port System can be awaked by Floppy Drive, COM or LPT port. 4.2.5.15 PCI PIRQ[A-D]# This function will cause the system waking up completely from the power management mode. 46 / 54...

  • Page 47: Pnp/Pci/Pci-E Configurations

    ADE-6050/ADE-6052 User’s Manual 4.2.6 PnP/PCI/PCI-E Configurations 4.2.6.1 Init Display First This item allows you to decide to active whether PCI Slot or on-chip VGA first. 4.2.6.2 Reset Configuration Data Normally, you leave this field Disabled. Select “Enabled” to reset Extended System...
  • Page 48 ADE-6050/ADE-6052 User’s Manual 4.2.6.4 PCI/VGA Palette Snoop This function determines if the graphics card should allow VGA palette snooping by a fixed function display card. It is only useful if a fixed-function display card using that requires a VGA-compatible graphics card to be present. Otherwise, leave the setting as default Disabled.

  • Page 49: Pc Health Status

    ADE-6050/ADE-6052 User’s Manual 4.2.7 PC Health Status 4.2.7.1 VDIMM The voltage level of the DRAM. 4.2.7.2 Vcore The voltage level of CPU (Vcore). 4.2.7.3 +3.3V/+5V/+12V/-12V/5Vsb Show you the voltage of +3.3V/+5V/+12V/-12V. 4.2.7.4 Voltage Battery Show you the voltage level of the battery.

  • Page 50: Load Optimized Defaults

    ADE-6050/ADE-6052 User’s Manual 4.2.9 Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N)? N Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations.

  • Page 51: Exit Selecting

    ADE-6050/ADE-6052 User’s Manual 4.2.11 Exit Selecting Save & Exit Setup Pressing <Enter> on this item asks for confirmation: Save to CMOS and EXIT (Y/N)? Y Pressing “Y” stores the selections made in the menus in CMOS – a special section of memory that stays on after you turn your system off.
  • Page 52 ADE-6050/ADE-6052 User’s Manual Appendix 52 / 54...

  • Page 53: Appendix A: Watchdog Timer Programming

    ADE-6050/ADE-6052 User’s Manual Appendix A: Watchdog Timer Programming The Watchdog Timer (WDT) is a special hardware device that monitors the computer system during normal operation. The WDT has a clock circuit that times down from a set number to zero. If a monitored item occurs before that timer reaches zero, the WDT resets and counts down again.

  • Page 54: Appendix B: Gpi/O Programming (Ade-6050 Only)

    ADE-6050/ADE-6052 User’s Manual Appendix B: GPI/O Programming (ADE-6050 only) The General Purpose I/O pins are provided for custom system design. The pin programming as input mode or output mode is depending on the configuration. The pin definitions are as the following table:...
