ADE-6040
®
Intel
Core™ 2 Duo Desktop
Q965 Mini ITX
User's Manual
Rev. 1.0
2007/02/13
P/N: 600C002604010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE-6040 and is the answer not in the manual?

Questions and answers

Related Manuals for Industrial Computers ADE-6040

Summary of Contents for Industrial Computers ADE-6040

  • Page 1 ADE-6040 ® Intel Core™ 2 Duo Desktop Q965 Mini ITX User’s Manual Rev. 1.0 2007/02/13 P/N: 600C002604010...
  • Page 2 ADE-6040 User’s Manual Copyright All rights reserved. The information contained in this guide has been validated and reviewed for accuracy. No patent liability is assumed with respect to the use of the information contained herein. While every precaution has been taken in the preparation of this guide, the Manufacturer assumes no responsibility for errors or omissions.
  • Page 3 This manual is written for the system integrator, PC technician and knowledgeable PC end user. It describes how to configure your ADE-6040 to meet various operating requirements. The user’s manual is divided into four chapters, with each chapter addressing a basic concept and operation of the server board.

  • Page 4: Table Of Contents

    ADE-6040 User’s Manual Table of Content Introduction.........................8 Description......................8 Packing Check List....................9 Specifications ....................10 System Architecture..................12 Dimensions ......................13 Hardware Configuration Setting................15 Board Layout .....................15 Jumpers & Connectors ..................16 Jumpers/Connectors Setting................17 2.3.1 RTC CMOS Clear Select (JP1) ..............17 2.3.2 Internal Audio for Chassis (AUDIO1)............17 2.3.3...
  • Page 5 ADE-6040 User’s Manual System Installation ....................21 ® Intel µFC-LGA775 Processor................21 ® ® ® 3.1.1 Installing Intel Core™ 2 Duo / Pentium 4 / Celeron D CPU ......21 ® Installing 1 U Cooler for Intel µFC-LGA775 Processor........22 Main Memory......................23 Installing the Mini-ITX..................24 3.4.1...
  • Page 6 ADE-6040 User’s Manual Revision History Revision Date Comment Rev.1.0 Apr. 2007 Initial released 6 / 55...
  • Page 7 ADE-6040 User’s Manual CHAPTER 1 7 / 55...

  • Page 8: Introduction

    ATX power function, and a feature of CPU overheat protection will provide user more security and stability. Combing with these outstanding features in the Mini-ITX form factor, ADE-6040 is definitely the most excellent choice for embedded applications like Network, Point of Sales (POS), automated KIOSKs, security products, medical instruments, and gaming machines.

  • Page 9: Packing Check List

    ADE-6040 User’s Manual Packing Check List The ADE-6040 Series package includes the following basic items accompany with this manual. One ADE-6040 series Mini ITX One Quick Installation Guide for ADE-6040 Two Serial ATA cables One Serial port cable for COM2 One USB 2.0 cable...

  • Page 10: Specifications

    ADE-6040 User’s Manual Specifications System ® ® ® Intel Core™ 2 Duo Desktop / Pentium 4 / Celeron D processor in the LGA775 package (E6000, 600, 500, 300 sequences) 1066/800/533 MHz BIOS AMI BIOS with 8 Mb SPI Flash EEPROM ®...
  • Page 11 ADE-6040 User’s Manual Audio HDAC Realtek ALC883 7.1 + 2 CH audio interface Audio Interface Mic in, Line in, CD Audio in, Line out, Rear out and Center/Subwoofer out Ethernet Chipset Dual Marvell® 88E8053 PCI Express™ Gigabit Ethernet controllers Ethernet Interface IEEE 802.3 10BASE-T/100BASE-TX/1000BASE-T...

  • Page 12: System Architecture

    ADE-6040 User’s Manual System Architecture All of details operating relations are shown in ADE-6040 series system block diagram. 12 / 55...

  • Page 13: Dimensions

    ADE-6040 User’s Manual Dimensions Unit: mm 13 / 55...
  • Page 14 ADE-6040 User’s Manual CHAPTER 2 14 / 55...

  • Page 15: Hardware Configuration Setting

    This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on ADE-6040 series are in the proper position. The default settings shipped from factory are marked with an asterisk ( ).

  • Page 16: Jumpers & Connectors

    ADE-6040 User’s Manual Jumpers & Connectors JUMPERS FUNCTION REMARK RTC CMOS clear select 3 x 1 header CONNECTORS FUNCTION REMARK AUDIO1 Internal audio for chassis 2 x 5 header Audio connector Audio jack x 3 AUDIO2 Auxiliary fan connector 1 x 3 wafer...

  • Page 17: Jumpers/Connectors Setting

    ADE-6040 User’s Manual Jumpers/Connectors Setting 2.3.1 RTC CMOS Clear Select (JP1) 2.3.2 Internal Audio for Chassis (AUDIO1) PIN No. Description PIN No. Description MIC2-L Clear CMOS Ground Normal operation MIC2-R +3.3V LINE2-R Ground Front I/O sense LINE2-L Ground 2.3.3 Audio Connector (AUDIO2) 2.3.4 Auxiliary/CPU/System Connectors...

  • Page 18: Gpio Connector (Gpio1)

    ADE-6040 User’s Manual 2.3.7 GPIO Connector (GPIO1) 2.3.8 PS/2 Keyboard & Mouse (KBMS1) PIN No. Description PIN No. Description Keyboard Data +3.3V General Purpose I/O bit 27 Mouse Data Ground General Purpose I/O bit 8 General Purpose I/O bit 28...

  • Page 19: Internal Speaker Connector (Spk1)

    ADE-6040 User’s Manual 2.3.13 Internal Speaker Connector (SPK1) 2.3.14 LAN 1/2 & USB 1/2/3/4 Connectors (USB2LAN1, USB2LAN2) PIN No. Description LAN 1/2 SPK Active# PIN No. Description PIN No. Description SPK Active# MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+ MDI1- MDI3- USB 1/2/3/4 PIN No.
  • Page 20 ADE-6040 User’s Manual CHAPTER 3 20 / 55...

  • Page 21: System Installation

    ADE-6040 User’s Manual System Installation This chapter provides you with instructions on how to setup your system. The additional information shows you how to install CPU/ FAN and memory. ® Intel µFC-LGA775 Processor ® ® ® 3.1.1 Installing Intel Core™ 2 Duo / Pentium...

  • Page 22: Installing 1 U Cooler For Intel

    ADE-6040 User’s Manual ® Installing 1 U Cooler for Intel µFC-LGA775 Processor Cooler Thermal bracket paste 1. Unpacked the cooler with 1 U Cooler Fan 2. Place Cooler Bracket under the board to & the Thermal paste enclosed. make the bracket holes right to the board holes, then smear the Thermal paste on the top of CPU.

  • Page 23: Main Memory

    ADE-6040 User’s Manual Main Memory ADE-6040 series provide 2 DIMMs (240-pin Dual In-line Memory Module) to support 1.5V DDRAM (Synchronized DRAM) as on-board main memory. The maximum memory size is 256 MB ~ 4 GB with using 256MB/512MB/1GB/2GB technology. Supports up to 2 double sided DIMMs at DDR2 800 MHz.

  • Page 24: Installing The Mini-Itx

    ADE-6040 User’s Manual Installing the Mini-ITX To install your ADE-6040 series into standard chassis or proprietary environment, you need to perform the following steps: 1. Check all jumpers setting on proper position 2. Install and configure CPU and memory module on right position 3.
  • Page 25 ADE-6040 User’s Manual CHAPTER 4 25 / 55...

  • Page 26: Bios Setup

    ADE-6040 User’s Manual BIOS Setup Entering Setup AMI BIOS has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM whose power is supplied by a battery so that it can retain the setup information even when the power is turned off. Press Delete when you Power on or Reboot the computer system.

  • Page 27: Advanced Setting

    ADE-6040 User’s Manual 4.1.2 Advanced Setting 27 / 55...
  • Page 28 ADE-6040 User’s Manual 4.1.2.1 CPU Configuration The CPU Configuration setup screen varies depending on the installed processor. 4.1.2.1.1 Max CPUID Value Limit The Intel® Processor Identification Utility requires the 'Max CPUID Value Limit' in the system BIOS to be disabled for proper processor identification. Once processor identification has taken place, the option can be re-enabled if desired.
  • Page 29 ADE-6040 User’s Manual 4.1.2.1.5 Intel® SpeedStep (tm) tech. Intel (R) SpeedStep(tm) tech. is Intel’s new power saving technology. Processor can switch between multiple frequency and voltage points to enable power savings. If you select [Auto], you need to set the “Power Schemes” as “Portable/Laptop” to enable this function. This option will be hidden if the current CPU does not support Intel SpeedStep(tm) tech..
  • Page 30 ADE-6040 User’s Manual 4.1.2.2 IDE Configuration 4.1.2.2.1 SATA#1 Configuration Option: [Disabled], [Enhanced]. 4.1.2.2.2 Configure SATA#1 as Option: [IDE], [RAID] 4.1.2.2.3 Primary/Secondary/Third/Fourth IDE Master/Slave Select one of the hard disk drives to configure it. Press <Enter> to access the sub menu.
  • Page 31 ADE-6040 User’s Manual 4.1.2.2.6 ATA(PI) 80Pin Cable Detection Set this option to select the method used to detect the ATA (PI) 80 pin cable. The Optimal and Fail-Safe setting is Host & Device. Item Description Set this value to use both the motherboard onboard IDE controller and IDE disk drive to detect the Host &...
  • Page 32 ADE-6040 User’s Manual 4.1.2.3 Super IO Configuration 32 / 55...
  • Page 33 ADE-6040 User’s Manual 4.1.2.3.1 Serial Port1/2 Address This option specifies the base I/O port address and Interrupt Request address of serial port 1/2. The Optimal setting is 3F8/IRQ4. The Fail-Safe default setting is Disabled. Item Description Set this value to prevent the serial port from accessing any system resources. When Disabled this option is set to Disabled, the serial port physically becomes unavailable.
  • Page 34 ADE-6040 User’s Manual 4.1.2.4 Hardware Health Configuration 4.1.2.4.1 CPU FAN PWM Control Enable CPU Fan mode. 4.1.2.4.2 CPU FAN PWM Control This item allows you to set CPU FAN PWM Control mode. 34 / 55...
  • Page 35 ADE-6040 User’s Manual 4.1.2.5 ACPI Configuration 4.1.2.5.1 ACPI Aware O/S Set this value to allow the system to utilize the Intel ACPI (Advanced Configuration and Power Interface) specification. Item Description This setting should be set if the operating system in use does not comply with the ACPI (Advanced Configuration and Power Interface) specification.
  • Page 36 ADE-6040 User’s Manual 4.1.2.6 APM Configuration 4.1.2.6.1 Power Management/APM Set this value to allow Power Management/APM support. 4.1.2.6.2 Video Power Down Mode This option specifies the length of time the system waits before it enters suspend mode. The options: Disabled, 1, 5, 10 Min.
  • Page 37 ADE-6040 User’s Manual 4.1.2.6.6 Keyboard & PS/2 Mouse Monitor KBC Ports 60/64. 4.1.2.6.7 Power Button Mode This option specifies how the externally mounted power button on the front of the computer chassis is used. The options: On/Off, Standby, Suspend. 4.1.2.6.8 Resume On Ring Disable/Enable RI to generate a wake event.
  • Page 38 ADE-6040 User’s Manual 4.1.2.7 MPS Configuration Select MPS Revision. 38 / 55...
  • Page 39 ADE-6040 User’s Manual 4.1.2.8 Remote Access Configuration 4.1.2.8.1 Remote Access You can disable or enable the BIOS remote access feature here. 39 / 55...
  • Page 40 ADE-6040 User’s Manual 4.1.2.9 USB Configuration 4.1.2.9.1 Legacy USB Support Legacy USB Support refers to the USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.

  • Page 41: Advanced Pci/Pnp Setting

    ADE-6040 User’s Manual 4.1.3 Advanced PCI/PnP Setting 41 / 55...
  • Page 42 ADE-6040 User’s Manual 4.1.3.1 Clear NVRAM Clear NVRAM during System Boot. 4.1.3.2 Plug & Play O/S Set this value to allow the system to modify the settings for Plug and Play operating system support. Item Description The No setting is for operating systems that do not meet the Plug and Play specifications.
  • Page 43 ADE-6040 User’s Manual 4.1.3.9 DMA Channel 0/1/3/5/6/7 Set this value to allow the DMA setting to be modified. Item Description Available This setting allows the specified DMA to be used by PCI/PnP device. Reserved This setting allows the specified DMA to be used by a legacy ISA device.

  • Page 44: Boot Settings

    ADE-6040 User’s Manual 4.1.4 Boot Settings 4.1.4.1 Boot Settings Configuration 4.1.4.1.1 Quick Boot The Optimal and Fail-Safe default setting is Disabled. Allow to set this value to allow the BIOS to skip certain POST tests to boot faster or disabled to perform all POST tests.
  • Page 45 ADE-6040 User’s Manual 4.1.4.1.2 Quiet Boot Set this value to allow the boot up screen options to be modified between POST messages or OEM logo. The Optimal and Fail-Safe default setting is Enabled. 4.1.4.1.3 AddOn ROM Display Mode Set this option to display add-on ROM (read-only memory) messages.

  • Page 46: Security Settings

    ADE-6040 User’s Manual 4.1.5 Security Settings 4.1.5.1 Change Supervisor Password Indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays. 4.1.5.2 Change User Password Indicates whether a user password has been set. If the password has been installed, Installed displays.

  • Page 47: Advanced Chipset Settings

    ADE-6040 User’s Manual 4.1.6 Advanced Chipset Settings 47 / 55...
  • Page 48 ADE-6040 User’s Manual 4.1.6.1 North Bridge Configuration You can use this screen to select options for the North Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 49 ADE-6040 User’s Manual 4.1.6.1.5 Internal Graphics Mode Select Select the amount of system memory used by the internal graphics device. 4.1.6.1.6 PEG Port This item allows you to control the PEG or on-chip VGA. The choice: [Auto], [Disabled]. 4.1.6.1.7 Video Function Configuration 4.1.6.1.7.1...
  • Page 50 ADE-6040 User’s Manual 4.1.6.2 South Bridge Configuration You can use this screen to select options for the South Bridge Configuration. South Bridge is a chipset on the motherboard that controls the basic I/O functions, USB ports, audio functions, modem functions, IDE channels, and PCI slots. Use the up and down <Arrow>...
  • Page 51 ADE-6040 User’s Manual 4.1.6.2.4 CPU/PCI clock Spread Spectrum This feature is used to set the CPU/PCI clock Spread Spectrum to be center spread type or down spread type. The options are: Enabled, Disabled 4.1.6.2.5 SLP_S4# Min. Assertion Width The item allows you to select the assertion width of SLP_S4#.

  • Page 52: Exit Options

    ADE-6040 User’s Manual 4.1.7 Exit Options 4.1.7.1 Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect. 4.1.7.2 Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration.
  • Page 53 ADE-6040 User’s Manual Appendix 53 / 55...

  • Page 54: Appendix A: Watchdog Timer Programming

    ADE-6040 User’s Manual Appendix A: Watchdog Timer Programming The Watchdog Timer (WDT) is a special hardware device that monitors the computer system during normal operation. The WDT has a clock circuit that times down from a set number to zero. If a monitored item occurs before that timer reaches zero, the WDT resets and counts down again.

  • Page 55: Appendix B: Gpi/O Programming

    ADE-6040 User’s Manual Appendix B: GPI/O Programming The General Purpose I/O pins are provided for custom system design. The pin programming as input mode or output mode is depending on the configuration. The pin definitions are as the following table: GPIOBASE Address: 480h Pin No.
