Feature and Specification Summary

Input Power:
Headset Power:
VOX Operation:
Indicators:
Mounting:
Controls:
Modes:
Inputs:
April 30, 2012 Rev: 5.00
ENG-FORM: 800-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
AA80 InterVOX Intercom Systems
SM08 Installation and Operation Manual
11-32 Vdc. Typical current 180mA (full o/p) 250mA maximum. May be
battery operated.
Typical 80 mW into each headset (150 Ohm David Clark Headset, or
similar). 4 headsets total, each with short-circuit protection. Total output
power 320 mW typical. 60 mW typical with 6 headsets total.
Voice band trigger circuit with adjustable threshold on front panel. "Live"
or hot mic operation by rotating VOX control to extreme counter-
clockwise position.
Two-color LED indicates:
Vertical or Horizontal through-panel, or standard clock hole. All plates
included. Optional mounting plate for standard instrument hole.
Front Panel:
Internal:
InterVOX
Pilot Isolation
Emergency
AA80-001:
4 standard "carbon equivalent" microphones, 250 mVrms for full output,
600 ohm input impedance.
2 Music inputs (1K input impedance) 2.5 Vrms
1 Radio input (1K input impedance) 2.5 Vrms
AA80-020:
4 standard "carbon equivalent" microphones, 250 mVrms for full output,
600 ohm input impedance.
1 Music input (1K input impedance) 2.5 Vrms
1 Radio input (1K input impedance) 2.5 Vrms
1 ICS Key input (ground seeking)
1 ICS Tie Line (for IC expansion)
TX – Green
RX (SQ) – Orange
ICS Volume
VOX Threshold
Sidetone (artificial)
RX Volume
Music Level
ATC Muting
All hear the same audio an ICS.
Pilot connected directly
passengers remain on the ICS and music bus.
Loss of power puts pilot directly on radio bus.
to the radios,
Page 1-2
