SPECIAL NOTICE
This product is now licensed to Anodyne Electronics Manufacturing (AEM) from Northern
Airborne Technology (NAT). AEM is responsible for all matters related to this product, including
sales, support and repair services.
Please note the transition to convert product manuals and supporting documentation is an
ongoing process and is being addressed on an 'as needed' basis.
All references to NAT product part numbers (and associated images) are equivalent to AEM
product part numbers.
Contact info:
Anodyne Electronics Manufacturing Corp.
#15-1925 Kirschner Road
Kelowna B.C. Canada
V1Y 4N7
Email:
support@aem-corp.com
Toll Free: 1-888-763-1088
Phone: 1-250-763-1088
Fax: 1-250-763-1089
www.aem-corp.com
Advertisement
Table of Contents
Related Manuals for AEM AA82 InterMUSIC
Summary of Contents for AEM AA82 InterMUSIC
- Page 1 SPECIAL NOTICE This product is now licensed to Anodyne Electronics Manufacturing (AEM) from Northern Airborne Technology (NAT). AEM is responsible for all matters related to this product, including sales, support and repair services. Please note the transition to convert product manuals and supporting documentation is an ongoing process and is being addressed on an ‘as needed’...
- Page 2 SM09-1 AA82 InterMUSIC™ Stereo Intercom System INSTALLATION AND OPERATION MANUAL REV 2.00 April 16, 2012 Anodyne Electronics Manufacturing Corp. 15-1925 Kirschner Road Kelowna, BC, Canada. V1Y 4N7 Telephone (250) 763-1088 Facsimile (250) 763-1089 Website: www.aem-corp.com © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
- Page 3 AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual COPYRIGHT STATEMENT © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved This publication is the property of AEM and is protected by Canadian copyright laws. No part of this document may be reproduced or transmitted in any form or by any means including electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AEM.
- Page 4 AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual Prepared By: Checked By: Approved By: Tony Pearson Tom Betzelt Loen Clement Product Support Designer Designer Manager Apr 16, 2012 May 24/12 May 28, 2012 The status of this installation and operation manual is controlled by issue shown on the title page. The status of each section is controlled by revision shown in the footer of each page.
-
Page 5: Table Of Contents
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual Table of Contents Section Title Page Description Introduction Purpose of Equipment Design Features Specifications 1.4.1 Electrical Specifications 1.4.2 Physical Specifications 1.4.3 Environmental Specifications Installation Introduction Unpacking and Inspection 2.2.1 Warranty... -
Page 6: Description
Each is linked via the ICS Tie Line to the crew audio system. The AA82 InterMUSIC™ Stereo Intercom offers the passengers full control of their intercom and entertainment functions. The front panel controls permit adjustment of Intercom level, VOX threshold and Music level. -
Page 7: Specifications
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual The AA82’s ICS Tie Line is fully compatible with existing AEM products, making it possible to chain multiple systems together (3 units max). The unit has overvoltage and reverse voltage protection to insure operability in severe aircraft environments. -
Page 8: Physical Specifications
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual 4 microphone ‘carbon equivalent’, 250 mVrms for full Inputs (AA82-060) output, 150 Ω input impedance 6 ICS keylines (active ground) for all users 2 music inputs compatible (left & right), configurable for... -
Page 9: Installation
All Anodyne Electronics Manufacturing Corp. (AEM) products are warranted for 2 years. See the website www.aem-corp.com/warranty for complete details. Continued Airworthiness Maintenance of the AA82 InterMUSIC™ Stereo Intercom System is ‘on condition’ only. Periodic maintenance of this product is not required. Installation Procedures 2.4.1... -
Page 10: Cautions
2.4.4 Mounting The AA82 InterMUSIC™ Stereo Intercom can be mounted in either a vertical or horizontal orientation. Place the adhesive backed drill template in an appropriate place on the instrument panel and drill through the indicated locations. The mounting nuts on the faceplate controls should not be removed at any time. -
Page 11: Post Installation Checks
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual 2.4.5 Post Installation Checks 2.4.5.1 Voltage/Resistance Checks Do not attach the AA82-xxx until the following conditions are met. Check the following for the AA82-001: a) Check pin 1 for +11 to +32 Vdc relative to ground. -
Page 12: Setting Up Music And Muting
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual 2.5.2 Setting Up Muting and Music Rotate the front panel VOX potentiometer until the VOX indicator is off. The music audio can now be heard. Adjust the music to a comfortable level with the front panel potentiometer. If the music is louder in one ear than the other, the side panel MUSIC BAL control may need adjusting, although this could be a problem with your music source, as this adjustment should be correct from the factory. -
Page 13: Music Selection (Aa82-060 Only)
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual To test KEYED ICS operation of the AA82-060, be sure the VOX potentiometer is set fully clockwise and all ICS audio is shut off. Keying the ICS switches should activate the specific microphone involved. -
Page 14: Accessories Required
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual Accessories Required Installation kit p/n AA82-001-IKC (25 pin D-min Female Crimp) is required to complete the installation. The kit includes AEM Part No. D25SL-IKC. AA82-001-IKC consists of: Quantity Description AEM Part No. -
Page 15: Installation Drawings
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual Installation Drawings Use of the "#" symbol in the REV. column indicates that the document is listed elsewhere in the manual. Refer to the applicable AEM Part No. to locate the referenced document. - Page 18 Confidential and Proprietary to NAT...
- Page 19 Confidential and Proprietary to NAT...
- Page 23 Confidential and Proprietary to NAT...
-
Page 24: Operation
SM09-1 Installation and Operation Manual Section 3.0 Operation Introduction Information in this section consists of functional and operational procedures for the AA82 InterMUSIC™ Stereo Intercom System. General Information The AA82 is available in two models, the AA82-001 and AA82-060. Both are designed for passenger entertainment and communications. -
Page 25: Stereo & Intercom Special Features
AA82 InterMUSIC™ Stereo Intercom System SM09-1 Installation and Operation Manual 3.3.1 Stereo & Intercom Special Features The stereo music audio is muted during intercom operation and when radio receive audio is detected, permitting greater intelligibility of incoming transmissions. The AA82 Muting adjustment ranges from complete music muting to gentle background music on command, with a fast attack and slow level return for optimum user comfort.
