ALLURE OUTDOOR
GAS OPEN FIRE
Stainless Steel Fascia
930 & 730 MODELS
May 2010
INSTALLATION,
OPERATION, MAINTENANCE &
WARRANTY INFORMATION
These instructions should be stored in a convenient safe place for ready reference.
Also available to download online at www.yunca.co.nz
Revised 27/05/10
ALLURE Outdoor Install May2010
Page 1 of 17
Advertisement
Table of Contents
Related Manuals for Yunca Gas ALLURE OUTDOOR 930
Summary of Contents for Yunca Gas ALLURE OUTDOOR 930
- Page 1 ALLURE OUTDOOR GAS OPEN FIRE Stainless Steel Fascia 930 & 730 MODELS May 2010 INSTALLATION, OPERATION, MAINTENANCE & WARRANTY INFORMATION These instructions should be stored in a convenient safe place for ready reference. Also available to download online at www.yunca.co.nz Revised 27/05/10 ALLURE Outdoor Install May2010 Page 1 of 17...
-
Page 2: Fault Finding Guide
Designed and built by: YUNCA GAS 2 Donald Street, Kaikorai Valley, Dunedin 9011 PO Box 500, Dunedin 9054. Phone 03 488 4342 Fax 03 488 1017 Email dunedin@yunca.co.nz Web www.yunca.co.nz CONTENTS PAGE INDEX, INTRODUCTION CAUTIONS, MAINTENANCE INSTALLATION and SERVICING DIMENSIONS and TIMBER FRAMING... -
Page 3: Maintenance
Stainless Steel cleaners available from your local hardware store. MAINTENANCE YUNCA GAS HIGHLY RECOMMENDS THAT a qualified service person should conduct an annual inspection and undertake any maintenance required on your Yunca Allure. Its venting and installation must be checked to keep it running safely and efficiently. -
Page 4: Dimensions And Clearances
DIMENSIONS and CLEARANCES Diagrams on the following pages are not to scale. All measurements are in millimetres. The Yunca Allure Outdoor flued gas fire is to be installed with clearances equal to, or greater than, those recommended on the following pages, and must comply with NZS 5261:2003/AG601 ZERO CLEARANCE FIREBOX FLUE DIA... -
Page 5: Weather Cover
CLEARANCES We anticipate that some Allure Outdoor Gas Fires will be installed in situations where clearances are required from combustible surfaces (floors, decks, mantels, side walls, etc). In this situation the following clearances apply: Floor protector – 300mm in front of and 100mm from side of firebox opening. - Page 6 PLACING The unit should be bolted to ensure no movement in the event of an earthquake or similar. (FIG 1) Laying of the gas pipes may need to be completed before the fire is finally positioned. (Fig 2.) (6mm dia x 50mm Coach Bolts Supplied). If the appliance is being attached to a concrete floor dyna bolts should be used.
-
Page 7: Gas Supply
CONNECTION TO GAS SUPPLY AND TESTING PRESSURES GAS SUPPLY: Burn only the fuel for which the appliance is equipped. The data plate affixed to the base of the appliance specifies the gas type, which the appliance is factory equipped for. CONNECTION: The gas inlet is a 3/8”... -
Page 8: Gas Pressure Testing
GAS PRESSURE TESTING This fire should be installed in accordance with “Gas Installation Code AG601", and/or any local authority rules. Each Yunca Allure fire is factory set to the appropriate operating pressure for the gas type with which it is factory equipped. If gas pressure requires adjustment, or a gas type conversion is required, the operating pressure can be tested at the test nipple on the side of the BM 733 control. -
Page 9: Removing Panels
REMOVING PANELS 1) GRATE Lift up and out. 2) HEARTH Lift up and out. 3) FASCIA FRONT Remove four side screws, two are just in from the sides at the top, and two at the bottom. Lift the fascia up slightly and pull forward. 3a) BOTTOM FASCIA STRIP (Not shown) This part may be fitted along the base of a regular three-sided fascia (shown above) to... - Page 10 REMOVING PARTS FOR SERVICE (FIRST TURN OFF THE GAS SUPPLY) 1) Coals, Logs = Remove with care. 2) Grate = Lift out. 3) Hearth = Lift up and out. 4) Front Tray = Remove screw from centre hole and lift out. 5) Rear Tray = Remove screw from right and left side, lift out.
- Page 11 LAYOUT FOR COALS: 930 & 730 MODELS Layout shown is for the 930 model using 13 coals per row. The 730 model uses 10 coals per row, layout as shown below, from left to right). Bottom Rear Row: Bottom Front Row: Top Rear Row: Top Front Row: 930 = 26 x No1 Coals...
- Page 12 LAYOUT FOR COALS & LOGS: 930 & 730 MODELS Coals 13 x No1, 13 x No2 10 x No1, 10 x No2 Layout shown is for the 930 model using 13 coals per row. The 730 model uses 10 coals per row, layout as shown below, from left to right).
-
Page 13: Warranty
ALLURE OUTDOOR series fires are specifically designed for OUTDOOR USE ONLY and CANNOT be used indoors. If you are in any doubt please contact the manufacturer: Yunca Gas, Dunedin 03 488 4342 N.B. DUE TO ADVERSE CONDITIONS (e.g. salt air) the ALLURE OUTDOOR fire will NOT be covered under warranty for fires situated closer than 500m to the shoreline. -
Page 14: Appendix A Fault Finding
Appendix A Fault Finding SYMPTOM PROBLEM CORRECTIVE ACTION Will not light No spark at pilot Check connection between electrode in pilot burner. assembly and lead from control Poor or no spark Clean any build up (Carbon) on or around the Spark electrode. -
Page 15: Appendix B: Yunca Allure Outdoor - Spare Parts
Appendix B: Yunca Allure Outdoor – Spare parts: 930 and 730 models - LPG Main Jets ALL 0.8mm dia. 930 and 730 models - Natural Main Jets ALL 1.2mm dia. PART NUMBER PART NAME 6500L Injector (Pilot Jet) LPG 0.23 dia 6500N Injector (Pilot Jet) NAT 0.35 dia 6599GOA... -
Page 16: Customer Copy
Purchasers’ Name. Purchase Date Purchasers’ Address City. Postcode Telephone Where Purchased. Installed By. Date. Manufactured by: Yunca Gas Dunedin PO Box 500 DUNEDIN 9054 Telephone (03) 488 4342 Email dunedin@yunca.co.nz Revised 27/05/10 ALLURE Outdoor Install May2010 Page 16 of 17...
