ALLURE OUTDOOR
GAS OPEN FIRES
Stainless Steel Fascia
Gunmetal Black Fascia
930 & 730 MODELS
APRIL 2008
INSTALLATION
OPERATION, MAINTENANCE &
WARRANTY INFORMATION
These instructions should be stored in a convenient safe place for ready reference.
Revised 04/04/08
ALLURE Outdoor Install Apr08
Page 1 of 19
Advertisement
Table of Contents
Related Manuals for Yunca Gas 930
Summary of Contents for Yunca Gas 930
-
Page 1: Warranty Information
ALLURE OUTDOOR GAS OPEN FIRES Stainless Steel Fascia Gunmetal Black Fascia 930 & 730 MODELS APRIL 2008 INSTALLATION OPERATION, MAINTENANCE & WARRANTY INFORMATION These instructions should be stored in a convenient safe place for ready reference. Revised 04/04/08 ALLURE Outdoor Install Apr08... -
Page 2: Table Of Contents
Designed and built by: YUNCA GAS 2 Donald Street, Kaikorai Valley PO Box 500, Dunedin 9054. Phone 03 488 4342 03 488 1017 Email dunedin@yunca.co.nz Web www.yunca.co.nz CONTENTS PAGE INTRODUCTION INSTALLATION and SERVICING DIMENSIONS and CLEARANCES 4 - 5 FLUE INSTALLATION... -
Page 3: Introduction
MAINTENANCE YUNCA GAS HIGHLY RECOMMENDS THAT a qualified service person should conduct an annual inspection and undertake any maintenance required on your Yunca Allure. Its venting and installation must be checked to keep it running safely and efficiently. -
Page 4: Dimensions And Clearances
DIMENSIONS and CLEARANCES Diagrams on the following pages are not to scale. All measurements are in millimetres. The Yunca Allure Outdoor flued gas fire is to be installed with clearances equal to, or greater than, those recommended on the following pages, and must comply with NZS 5261:2003/AG601 ZERO CLEARANCE FIREBOX FLUE DIA MODEL... -
Page 5: Flue Installation
CLEARANCES We anticipate that some Allure Outdoor Gas Fires will be installed in situations where clearances are required from combustible surfaces (floors, decks, mantels, side walls, etc). In this situation the following clearances apply: Floor protector – 300mm in front of and 100mm from side of firebox opening. -
Page 6: Weather Covers
WEATHER COVERS. The design of the weather covers are different for each fascia style. GUNMETAL BLACK FASCIA - WEATHER COVER and HOOD A stainless steel hood secures the weather cover in place for the Gunmetal Black Outdoor fire. By the nature of fireplace installation each install is different for the location of this hood. -
Page 7: Placing
PLACING The unit should be bolted to ensure no movement in the event of an earthquake or similar. (FIG 1) Laying of the gas pipes may need to be completed before the fire is finally positioned. (Fig 2.) (6mm dia x 50mm Coach Bolts Supplied). If the appliance is being attached to a concrete floor dyna bolts should be used. -
Page 8: Connection To Gas Supply & Testing Pressures
5.0 kPa (20"w.g.) Max Manifold Operating pressure 0.6 kPa with Burners on HIGH 0.25 kPa with Burners on LOW LPG: Input 930 & 730: 48 MJ Minimum inlet pressure 2.75 kPa (11"w.g.) Maximum inlet pressure 3.5 kPa (14"w.g.) Max Manifold Operating pressure 1.5 kPa with Burners on HIGH... -
Page 9: Gas Pressure Testing
GAS PRESSURE TESTING This fire should be installed in accordance with “Gas Installation Code AG601", and/or any local authority rules. Each Yunca Allure Fire is factory set to the appropriate operating pressure for the gas type that it is factory equipped. If gas pressure requires adjustment, or a gas type conversion is required, the operating pressure can be tested at the test nipple on the side of the BM 733 control. -
Page 10: Removing Panels And Parts For Servicing
REMOVING PANELS 1) GRATE Lift up and out. 2) HEARTH Lift Up and Out. 3) FASCIA FRONT Remove four screws, two are just in from the sides at the top, and two at the bottom left and right. Lift the fascia up and out. 3a) BOTTOM FASCIA STRIP (Not shown) This part may be fitted along the base of a regular three-sided fascia (shown... - Page 11 REMOVING PARTS FOR SERVICE (FIRST TURN OFF THE GAS SUPPLY) 1) Coals, Logs = Remove with care. 2) Grate = Lift out. 3) Hearth = Lift up and out. 4) Front Tray = Remove screw from centre hole and lift out. 5) Rear Tray = Remove screw from right and left side, lift out.
-
Page 12: Coal And Log Layout
LAYOUT FOR COALS: 930 & 730 MODELS Layout shown is for the 930 model using 13 coals per row. The 730 model uses 10 coals per row, layout as shown below, from left to right). Bottom Rear Row: Bottom Front Row:... - Page 13 13 x No1, 13 x No2 10 x No1, 10 x No2 Layout shown is for the 930 model using 13 coals per row. The 730 model uses 10 coals per row, layout as shown below, from left to right).
-
Page 14: Operation And Commissioning
Commissioning When installed the installer should operate the YUNCA ALLURE OUTDOOR to ensure that all features are operating correctly, refer below. Turning on your YUNCA ALLURE OUTDOOR fire The markings mentioned below are imprinted on the Control Panel Grill and are visible when the hearth panel is lifted out (NB. You do not need to remove the hearth panel to light the fire). -
Page 15: Fault Finding Guide
Appendix A Fault Finding SYMPTOM PROBLEM CORRECTIVE ACTION Will not light No spark at pilot Check connection between electrode in pilot burner. assembly and lead from control Poor or no spark Clean any build up (Carbon) on or around the Spark electrode. -
Page 16: Spare Parts List
Appendix B: Yunca Allure Outdoor – Spare parts: 730 model LPG MAIN JETS: 930 model LPG MAIN JETS: 930 and 730 models - Natural Main Jets ALL 1.2 mm dia. NAME PART NUMBER BM733 Control Valve 6505 Pilot Assembly 6500L Pilot Jet LPG 0.23 dia... -
Page 17: Warranty And Maintenance
ALLURE OUTDOOR series fires are specifically designed for OUTDOOR USE ONLY and CANNOT be used indoors. If you are in any doubt please contact the manufacturer: Yunca Gas, Dunedin 03 488 4342 N.B. DUE TO ADVERSE CONDITIONS (e.g. salt air) the ALLURE OUTDOOR fire will NOT be covered under warranty for fires situated closer than 500m to the shoreline. - Page 18 This page intentionally blank. Revised 04/04/08 ALLURE Outdoor Install Apr08 Page 18 of 19...
-
Page 19: Warranty Registration
City. Postcode Telephone Where Purchased. Installed By. Date. Manufactured by: Yunca Gas Dunedin PO Box 500 DUNEDIN 9054 Telephone (03) 488 4342 Email yuncagas@southnet.co.nz Cut here and return MANUFACTURER COPY This section must be returned within 10 days of purchase.
