Infrant Technologies ReadyNAS NV Getting Started Manual page 5

7
Set up ReadyNAS
After powering up the unit, you will see the ReadyNAS system in the RAIDar scan list. When the Setup button becomes
clickable, click Setup to start the Setup Wizard. Use user name
Setup Button
After completing setup, your ReadyNAS is ready for use. Refer to
A
RAID Configuration (Optional)
1
Your ReadyNAS NV comes in one of the following three configurations:
Diskless system with X-RAID (Expandable Volume)
System with pre-installed disks in X-RAID (Expandable Volume)
System with pre-installed disks in RAID 0/1/5 (Flexible Volume)
Follow the steps below to switch between X-RAID Expandable Volume mode and the
RAID 0/1/5 Flexible Volume mode only if you wish to change the above default
configuration. (Please note that it is not necessary to perform this procedure every
time. The device will remain in the selected mode until explicitly changed.)
2
Set RAID mode by performing a Factory Default.
Make sure ReadyNAS is connected to the network and RAIDar is running when
performing the Factory Default.
Factory Default will erase all your data on the hard disks.
admin infrant1
and password
The Info column displays boot
and installation status, or the
OS version when ReadyNAS is
ready to use.
Quick Setup Guide and Users Guide
Legend:
to login.
for details.
RAID Configuration
Number
RAID RAID RAID X-RAID
of disk
0 1 5
Installed
1
2
3
4
Redundancy against single disk of failure.
X-RAID auto volume expansion.
Default RAID setting.
Storage capacity.
