About ReadyNAS NV
A B C D
Backup Act
1 2 3 4
ReadyNAS TM NV
F G
3
Install Hard Disks (Optional - only if you purchased a diskless unit)
Backup
1 2
1
1
Remove disk tray from the Unit:
1
- Open the door.
3
- Pull the tray out.
E H I J K
SYS RST
LAN
ReadyNAS NV
P/N: RNV1-S2-0000-01
S/N (MAC)
Infrant Technologies, Inc. AC 90 ~ 264 V
California, USA 50 / 60 Hz
Made in Taiwan
L M N O
Act
1 2 3 4
3
2
3 4
ReadyNAS TM NV
2
- Press to pop out the latch.
A - USB Port (1)
Programmable Backup Button
B -
Disk LEDs. Lights up green for disk online
C -
Activity LED. Blinking for disk access activities
D -
Power Button with Indication LED
E -
Disk Tray Door
F -
Disk Tray Door Access
G -
Unit Handle
H -
System Reset Switch Pin Hole
I -
USB Port (2) and Port (3)
J -
Ethernet Port (RJ45)
K -
Cooling Fan
L -
Power Connector (100~240VAC, 50/60Hz)
M -
Label (with Serial number, MAC address)
N -
Kensington Lock Security Hole
O -
A
Unlocked (Default position)
To open the tray, press the round button.
B
Locked (the lower position)
To open the tray insert a paper clip into
the pin hole of the round button.
2
Set the lock before installing
the hard disk into the tray. (Optional)
