JUKI-752
DX4-100 with LCD/CRT SBC
Version 3.0
User Manual Version 3.0
August 22, 2003
©Copyright 2003 by ICP Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JUKI-752 DX4-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for ICP Electronics JUKI-752 DX4-100

  • Page 1 JUKI-752 DX4-100 with LCD/CRT SBC Version 3.0 User Manual Version 3.0 August 22, 2003 ©Copyright 2003 by ICP Electronics Inc. All Rights Reserved.
  • Page 2 Trademarks JUKI-752 is a registered trademark of ICP Electronics Inc., PC/104 is a trademark of PC/104 Consortium, and IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation.
  • Page 3: Table Of Contents

    Table of Contents Introduction ..............4 Specifications ..................5 Package Contents ................6 Installation..............7 JUKI-752 Layout ................7 CPU Setting for JUKI-752 ..............8 Watchdog Timer ................8 DiskOnChip™ Flash Disk ..............8 Clear CMOS Setup ................9 Serial port 2 RI Pin Setting ..............9 Free IRQ3 and IRQ4 Setting ..............9 Connection ..............
  • Page 4: Introduction

    1 Introduction Thank you for choosing JUKI-752 DX4-100 with LCD/CRT Single Board Computer. JUKI-752 is an ISA with PC/104 form factor board, which comes equipped with ACC Maple Chipset (includes DX4-100 CPU) and advanced high-performance multi-mode I/O, designed for the system manufacturers, integrators, or VARs that want to provide all the performance, reliability, and quality at a reasonable price.
  • Page 5: Specifications

    1.1 Specifications JUKI-752 DX4-100 with LCD/CRT Single Board Computer provides the following specification: • System CPU: ACC Maple, includes DX4-100 CPU DMA channels: 7 Interrupt levels: 15 Real-time clock/calendar: DS12887/BQ3287 or equivalent chip and quartz oscillator, 128B CMOS memory, powered by lithium battery for over 10 years of data retention.
  • Page 6: Package Contents

    Humidity: 5% ~ 95%, non-condense Dimension: 180mm(W) x 122mm(L), standard AT form factor 1.2 Package Contents JUKI-752 package includes the following items: JUKI-752 DX4-100 with LCD/CRT Single Board Computer x 1 RS-232/Printer Cable x 1 FDD/HDD Cable x 1 User Manual x 1...
  • Page 7: Installation

    2 Installation This chapter describes how to install the JUKI-752. The layout of JUKI-752 is shown below. Read carefully the unpacking information, the jumpers and switches setting for the JUKI-752's configuration, such as CPU type selection, system clock setting, and interrupt IRQ setting for serial ports and parallel port. 2.1 JUKI-752 Layout...
  • Page 8: Cpu Setting For Juki-752

    2.2 CPU Setting for JUKI-752 • CPU Speed Setting The system clock is generated by the ICS650, and the different CPU clock frequency can be selected by JP2 and shown as following table: 75MHz 100MHz 2.3 Watchdog Timer Watchdog Timer is enabled by reading port 443H. It should be triggered before the time-out period ends, otherwise it will assume the program operation is abnormal and will issue a reset signal to start again, or activate NMI to CPU.
  • Page 9: Clear Cmos Setup

    2.5 Clear CMOS Setup To clear the CMOS Setup, close JP15 for about 3 seconds, and then open again. Take Set back to normal operation mode take off the jumper. If the RTC Chip is Dallas DS12B887 you should do the procedure when the board is power on. •...
  • Page 10: Connection

    3 Connection This chapter describes how to connect peripherals, switches and indicators to the JUKI-752 board. You can access most of the connectors from the top of the board while it is installed in the chassis. 3.1 Floppy Disk Drive Connector JUKI-752 board comes equipped with a 34-pin daisy-chain driver connector cable.
  • Page 11: Ide Disk Drive Connector

    3.2 IDE Disk Drive Connector You can attach two IDE (Integrated Device Electronics) hard disk drives to the JUKI-752 internal controller. The board comes equipped with a 40-pin flat-cable connector. The detailed pin assignment of the connector is specified as following table: •...
  • Page 12: Serial Ports

    3.4 Serial Ports JUKI-752 offers two high speed NS16C550 compatible UARTs with Read/Receive 16 byte FIFO serial ports. These ports let you connect to serial devices or a communication network. One DB-9 connector and thee 10-pin headers are provided by the JUKI-752. The detailed pin assignments of the connectors are specified below: •...
  • Page 13: Keyboard/Mouse Connector

    3.5 Keyboard/Mouse Connector JUKI-752 provides two keyboard connectors. A 5-pin header connector CN8 supports passive backplane applications. Another one is a 6-pin Mini-DIN connector CN15 on the board-mounting bracket for single board computer applications. • CN8: 5-pin Header Keyboard Connector Description KEYBOARD CLOCK KEYBOARD DATA...
  • Page 14: External Power Connector

    3.7 External Power Connector JUKI-752 has an on-board external power connector CN10. You can connect power directly to the CPU board for some single-board-computer (without passive backplane) application. • CN10: External Power Connector Description +12V -12V GROUND GROUND +12V 3.8 External Speaker JUKI-752 has its own buzzer, which can be connected to the external speaker through the connector CN16: •...
  • Page 15: Lcd Interface Connector

    3.10 LCD Interface Connector JUKI-752 provides a 2x22-pin connector for the LCD flat panel interface. • CN3: LCD Interface Connector Description Description +12V +12V FPVEE SHFCLK ENABLK...
  • Page 16: Ami Bios Setup

    4 AMI BIOS Setup JUKI-752 uses AMI BIOS for system configuration. AMI BIOS setup program is designed to provide maximum flexibility in configuring the system by offering various options which may be selected for end-user requirements. This chapter is written to assist you in the proper usage of these features. 4.1 Getting Started When the system is powered on, BIOS will enter the Power-On-Self-Test routines.
  • Page 17: Appendix A Watchdog Timer

    Appendix A Watchdog Timer Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that caused the CPU to crash. This condition may have occurred by external EMI or a software bug. When the CPU stops working correctly, hardware on the board will either perform a hardware reset (cold boot) or a non-maskable interrupt (NMI) to bring the system back to a known state.
  • Page 18: Appendix B Panel Support List

    Appendix B Panel Support List JUKI-752 supports a wide range of flat panels. The different flat panel will need different LCD drive BIOS. The default setting is for Color DSTN flat panel. The available BIOS for different panels are in the following list. Please note all the BIOS files already included the system BIOS and LCD drive BIOS, customer only need to re-program the BIOS flash chip with the file, and then power on again.
  • Page 19: Appendix C I/O Information

    Appendix C I/O Information IO Address Map I/O address Range Description 000-01F DMA Controller #1 020-021 Interrupt Controller #1, Master 040-05F 8254 timer 060-06F 8042 (Keyboard Controller) 070-07F Real time Clock, NMI (non-maskable interrupt) Mask 080-09F DMA Page Register 0A0-0BF Interrupt Controller #2 0C0-0DF DMA Controller #2...
  • Page 20 IRQ Mapping Chart IRQ0 System Timer IRQ8 RTC Clock IRQ1 Keyboard IRQ9 Unused IRQ2 Cascade to IRQ Controller IRQ10 Unused IRQ3 COM2/COM4 IRQ11 Unused IRQ4 COM1/COM3 IRQ12 PS/2 mouse IRQ5 Unused IRQ13 FPU IRQ6 IRQ14 Primary IDE IRQ7 Printer IRQ15 Unused DMA Channel Assignments DMA Channel Function...
